1/2.8" progressive scan CMOS
Up to 1920 × 1080 30fps resolution
Min. illumination:
Color: 0.005 Lux (F1.6, AGC ON)
B/W: 0.001 Lux (F1.6, AGC ON)
0 Lux with IR
25× optical zoom, 16× digital zoom
WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
Up to 150 m IR distance
24 VAC & Hi-PoE
Support H.265+/H.265 video compression
Audio input/output
Alarm input/output
Effective Pixels: 1920(H)x1080(V)
Signal System: PAL/NTSC
Minimum Illumination: Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001Lux @(F1.6, AGC ON)0 Lux with IR
AGC: Auto/Manual
BLC: ON/OFF
HLC: Support
Smart defog: Support
WDR: 120dB
Shutter Time: 1-1/10,000s
Day& Night: ICR
Digital Zoom: 16X
Privacy Masking: 24 programmable privacy masks; optional multiple colors and mosaics
Auto Focus: Auto / Semi-automatic / Manual
Focal Length: 4.8 mm to 120 mm, 25× optical zoom
Zoom Speed: Approx. 3.6 s (optical lens, wide-tele)
Angle of View: Horizontal field of view: 57.6° to 2.5° (Wide-Tele)
Vertical field of view: 34.4° to 1.4° (Wide-Tele)
Diagonal field of view: 64.5° to 2.9° (Wide-Tele)
Minimum Working Distance: 10-1,500mm(Wide-Tele)
Aperture Range: F1.6 to F3.5
Pan Range: 360°endless
Pan Speed: Configurable, from 0.1°/s to 120°/s
Preset speed: 120°/s
Tilt Range: -15°-90° (Auto Flip )
Tilt Speed: Configurable, from 0.1°/s to 80°/s Preset Speed: 80°/s
Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset: 300
Patrol: 8 patrols, up to 32 presets per patrol
Pattern: 4 pattern scans, record time over 10 minutes for each scan
Power loss recovery: Support
PTZ Position Display: ON/OFF
IR Distance: 150m
IR irradiation angle: Adjustable by zoom
Ethernet: 10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution: 1920×1080
Main Stream: 50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)
Sub Stream: 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)
Third Stream: 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)
Video Compression: Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
ROI encoding: Support 4 areas with adjustable levels
Audio Compression: G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Mode: OFF/Audio input/Audio output
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
No. of Simultaneous Users: Up to 20 channels
Three-Stream: Support
Mini SD Card: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
User/Host Level: Up to 32 users, 3 levels: Administrator, Operator and User
Security Measures: User authentication (ID and PW), host authentication (MAC address)
Menu Language: English
Power Supply: 24 VAC & Hi-PoE
Power Consumption: Max.: 30 W (Max. 10 W for IR)
Working Temperature/Humidity: -30 ℃-65℃(-22℉-149℉)(outdoor)90% or less
Protection Level: IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection
Mounting: Various mounting modes optional
Material: ADC 12, PC, PC+10%GF
Dimensions: Φ 208 mm × 345 mm (Φ 8.19" × 13.58")
Weight (approx.): Approx. 3.3 kg (7.28 lb)
