TP-Link MC111CS WDM Media Converter

Item: TP-Link MC111CS WDM Media Converter
Rating: 5
Author: jashim

12 reviews

Product Id: 29.09.091.166

Regular Price

Tk 0

Out Of Stock

Quick Overview

Ports - 1 x 100M SC/UPC, 1 x 100M RJ45
Type - Media Converter

Payment Method Shipping & Charge Order Procedure

Additional Info

Brand

TP-Link

Model

TP-Link MC111CS

Type

Media Converter

Ports

1 x 100M SC/UPC, 1 x 100M RJ45

Standards and Protocols

IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Wave Length

1310nm Rx, 1550nm Tx

LED Indicators

Yes

Power Supply

External Power Adapter

Approx. Power Consumption

2.49W

Dimensions

94.5 x 73.0 x 27.0mm

Others

Basic Function: Adopts WDM technology, Half/Full-Duplex transfer mode for FX port, Full Duplex Flow Control (IEEE 802.3x), Half Duplex Flow Control (Backpressure), Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely, Extends fiber distance up to 20km, WDM TX 1550nm, WDM RX 1310nm, Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100 STP (maximum 100m), Network Media 100BASE-T: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100 STP (maximum 100m), Network Media 100BASE-FX: Single-mode Fiber, Safety & Emission: FCC, CE, RoHS, Package Contents: Media Converter MC111CS, Power Adapter, Installation Guide, Environment: Operating Temperature: 0 to 40 Degree C, Storage Temperature: -40 to 70 Degree C, Operating Humidity: 10%-90% non-condensing, Storage Humidity: 5%-90% non-condensing.

Warranty Details

1 year

Country Of Origin

China

Made in/ Assemble

China

Details

Features of TP-Link MC111CS Media Converter In Bangladesh

omplies with 802.3u 10/100Base-TX, 100Base-FX standards
Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
Adopts WDM technology, transmitting and receiving data on one single fiber

The MC111CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM technology, MC111CS takes only one fiber cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on transferring data and at 1310nm on receiving data. So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data. Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS.

Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´ system chassis, Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers.

What is the price of TP-Link MC111CS Media Converter In Bangladesh?

The price of TP-Link MC111CS Media Converter not mentioned for stock unavailability. The price may vary due to your customization and product availability. You can buy TP-Link MC111CS Media Converter from our website or visit our showrooms nearby.
