Antec ATOM B550 550W Non Modular 80 Plus Bronze Certified Black Power Supply

Item: Antec ATOM B550 550W Non Modular 80 Plus Bronze Certified Black Power Supply
Rating: 5
Author: Verified Buyer

Product Id: 55.01.457.65

Out Of Stock

See similar model

Quick Overview

PSU Category - Non Modular
Type - Unmentioned
Maximum Power - 550 Watt
Efficiency - Unmentioned
Efficiency Rating - 80 Plus Bronze
Protection - OPP, OVP, UVP, SCP
Color - Black
Warranty Info - 6 Year

Payment Method Shipping & Charge Order Procedure

Brand

Antec

Model

Antec ATOM B550 550W

Series

ATOM

PSU Category

Non Modular

Type

Unmentioned

Maximum Power

550 Watt

Fan Size

120mm

Lighting Effect

Efficiency Rating

80 Plus Bronze

Form Factor

Unmentioned

Color

Black

Warranty

6 Years (Instant Replacement with Burn Case)

General

Brand

Antec

Model

Antec ATOM B550 550W

Series

ATOM

PSU Category

Non Modular

Type

Unmentioned

Cooling & Lighting

Fan Size

120mm

Lighting Effect

Performance

Efficiency

Unmentioned

Efficiency Rating

80 Plus Bronze

Protection

OPP, OVP, UVP, SCP

Over Voltage Protection (OVP)

Yes

Over Power Protection (OPP)

Yes

Over Temperature Protection (OTP)

Short Circuit Protection (SCP)

Yes

Under Voltage Protection (UVP)

Yes

Connectors

EPS Connectors

PCIe Connectors

SATA Power Connectors

Power

Min. Power (Approx.)

470W

Maximum Power

550 Watt

Physical Description

Form Factor

Unmentioned

Color

Black

Warranty

6 Years (Instant Replacement with Burn Case)

Additional Info

Others

1 x molex connector, 1 x 24-pin main connector. 200 - 240 Vac, 6.3A, 50Hz. FLAT Cable. Thermal Manager - An advanced fan control for optimal heat & noise management. Active Power Factor Correction (APFC).

Country Of Origin

USA

Made in/ Assemble

China

Details

Features of Antec ATOM B550 550W Power Supply In Bangladesh

Brand - Antec, Model - Antec ATOM Series V550, PSU Category - Non Modular, Type - ATX 12V, Maximum Power - 550 Watt, Input Voltage - 230VAC, Input Frequency Range - 47-63Hz, Input Current - 4A, Fan Size - 120mm, Protection - OPP/ OVP/ UVP/ SCP, Over Voltage Protection (OVP) - Yes, Over Power Protection (OPP) - Yes, Over Current Protection (OCP) - No, Over Temperature Protection (OTP) - No, Short Circuit Protection (SCP) - Yes, Under Voltage Protection (UVP) - Yes, ATX Main Connectors - 1, EPS Connectors - 1, PCIe Connectors - 2, SATA Power Connectors - 5, 4-Pin Peripheral Connectors - 2, Floppy Connectors - 1, Form Factor - ATX, Dimension (W/H/D) - 140 x 150 x 86mm, Color - Black, Others - Power Output: 3.3V - 18A - 120W, 5V - 16A - 120W, 12V - 42A - 504W, -12V - 0.3A - 3.6W, 5Vsb - 2.5A - 12.5W., Specialty - CircuitShield, Thermal Manager, 120 mm Silent Fan., Warranty - 2 Year with Burn Case, Country of Origin - USA, Made in/ Assemble - China

What is the price of Antec ATOM B550 550W Power Supply In Bangladesh?

The price of Antec ATOM B550 550W Power Supply not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Antec ATOM B550 550W Power Supply from our website or visit our showrooms nearby.
