Features of Asrock SPC621D8U-2T Motherboard In Bangladesh
Brand - Asrock, Model - Asrock SPC621D8U-2T, Chipset Brand - Intel, Chipset - Intel C621A, CPU Sockets - LGA4189 - Server, Built-in Processor - No, Supported CPU - 3rd Gen Intel Xeon Scalable processors, Generation - 3rd, Back-Connect Design - No, Cable Management - Front, Memory Type - DDR4 Server RAM, Memory MHz - 3200MHz, Memory Slot - 8, Memory Slot (Additional Info) - 8 x DIMM Slot (1DPC), Memory Max. - 256GB, Memory Max. (Additional Info) - RDIMM up to 64GB, RDIMM-3DS up to 256GB, LRDIMM up to 128GB, LRDIMM-3DS up to 256GB, Optane Memory Support - Yes, Graphics - Integrated, Graphics Chipset - Integrated with Processor, PCI Express Slot - 4 x PCIe4.0 x16, Storage Interface - 6Gb/s, M.2 Slot - 1 x M.2 (Supports 2280 PCIe3.0 x4 or SATA 6Gb/s, M-key), M.2/SSD Slot Gen - Up to Gen 3, LAN Chipset - Realtek RTL8211E, LAN Speed (Mbps) - 0/100/1000/10000Mbps, Wi-Fi - No, Bluetooth - No, USB Port - 2 x USB3.2 Gen1 Type-A, VGA Port - 1, DVI Port - No, HDMI Port - No, DisplayPort (DP) - No, SATA Port - 2, BIOS Type - 256Mb SPI Flash ROM, BIOS Model - AMI UEFI BIOS, Heatsink - No, CrossFire Support - No, Sli Support - No, Raid Support - 0/1/5/10, Thunderbolt - No, RGB Support - No, Approx. Power Consumption - 60W, Form Factor - Micro-ATX, Supported Operating System - Windows Server 2016/2019/2022 (64 bit), Linux: Red Hat Enterprise Linux Server 7.9 (64 bit) / 8.3 (64 bit), CentOs 7.9 (64 bit) / 8.3 (64 bit), SUSE Enterprise Linux Server 15 SP2 (64 bit) / 15 SP3 (64 bit), Ubuntu 20.04.3 (64 bit) / 21.04 (64 bit). Hypervisor: VMWare ESXi 6.7.0 U3 / vSphere 6.7.0 U3, VMWare ESXi 7.0U3 / vSphere 7.0U3, Hyper-V Windows Server 2016/2019., Body Color - Green, Special Features - Micro-ATX (9.6 x 9.6 inch), 8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, and Intel Optane Persistent Memory. Up to 11 SATA 6Gb/s, 2 RJ45 (10GbE) by Intel X710-AT2, Supports ATX PSU or 12V DC-in, Remote management (IPMI)., Others - Dimensions: 243.84 x 243.84mm, Single Socket P+ (LGA 4189), PCH Built-in Storage: Intel C621A (Up to 11 SATA 6Gb/s; RAID 0/1/5/10): 2 Mini-SAS HD, 2 SATA 7-pin, 1 M.2. Additional GbE Controller: 2 RJ45 (10 GbE) by Intel X710-AT2, BMC Controller: ASPEED AST2500: IPMI2.0 with iKVM and vMedia support, IPMI Dedicated GLAN: 1 RJ45 Dedicated IPMI LAN port by Realtek RTL8211E, Graphics Controller: ASPEED AST2500: 1 DB15 (VGA). Rear I/O: 1 UID button w/ LED, 1 DB15 (VGA), 2 Type-A (USB3.2 Gen1), 2 RJ45 (10GbE), 1 dedicated IPMI. Internal Connector/Headers: Power Connector-1 Mirco-Fit (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 2 (8-pin, ATX 12V) support 12V DC-in, Other Power Connectors-1 Mirco-Fit (6-pin) for HDD power when using 12V DC-in power source, Auxiliary Panel Header-1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2 activity LED, locate, SMBus, System Panel-1 (9-pin): power switch, reset switch, system power LED, HDD activity LED, COM Header-1, Fan Header-4 (4-pin), TPM Header-1 (17-pin, LPC), 1 (13-pin, SPI), VROC header-1, HSBP-1, SMBus header-1, PMBus header-1, IPMB Header-1, Clear CMOS-1(contact pads), USB 3.2 (Gen1) Header-1 (19-pin, 2 USB3.2 Gen1), NMI Header-1. LED Indicators: Standby PWR LED 5vsb-1, Fan Fail LED-4, BMC heartbeat LED-1. BIOS Features: Plug and Play (PnP), ACPI 4.0 and above compliance wake up events, SMBIOS 3.3 and above, ASRock Rack Instant Flash. Temperature: CPU, PCH, MB, Card side Temperature Sensing. Fan Tachometer, CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature), Fan Multi-Speed Control. Voltage: CPU1-PVCCIN, PVDDQ-ABCD, PVDDQ-EFGH, 1.05V-PCH, 1.8V-PCH, +BAT, PVNN-PCH 3.3V, 5V, 12V, 3.3VSB, 5VSB., Compatible Products - 3rd Gen Intel Xeon Scalable processors, Warranty - 3 Year, Country of Origin - Taiwan, Made in/ Assemble - China
What is the price of Asrock SPC621D8U-2T Motherboard In Bangladesh?
The price of Asrock SPC621D8U-2T Motherboard not mentioned for stock unavailability.The price may vary due to your customization and product availability.
You can buy Asrock SPC621D8U-2T Motherboard from our website or visit our showrooms nearby.
