Asus RS300-E11-PS4 Intel Xeon E-2336 1U Rack Server

Product Id: 85.02.006.15

Brand Asus

Regular Price Tk 0
Special Price Tk 0
Out Of Stock

Quick Overview

  • Processor Model - Intel Xeon E-2336
  • Number of Processor - 1
  • RAM - 16GB
  • Hard Disk Drive (HDD) - 2 x 1TB
  • Installed HDD Type - SATA
  • Solid-State Drive (SSD) - 7200
General
Brand
Asus

Model
Asus RS300-E11-PS4

Part No
90SF01Y1-M00360


Processor
Processor Model
Intel Xeon E-2336

Number of Processor
1

Processor Clock Speed
2.90GHz - 4.80GHz

Processor Base Frequency
2.90GHz

Processor Max Turbo Frequency
4.80GHz

Total Cores
6

Total Threads
12

Processor Cache
12MB

Bus Speed
8 GT/s

TDP
65W

Chipset
Intel C252


Memory
RAM
16GB

Installed RAM Details
1 x 16GB Removable

RAM Type
DDR4

RAM Bus
3200 MHz

RAM Slots
4

Empty/Expansion RAM Slot
3

Max. RAM Support
128GB

DRAM Type
UDIMM

RAM Feature
DDR4 3200MT/s UDIMM ECC


Storage
Hard Disk Drive (HDD)
2 x 1TB

Installed HDD Type
SATA

HDD RPM
7200

HDD Details
7.2K RPM SATA 6Gbps ENTERPRISE 3.5in Hard Drive

Solid-State Drive (SSD)
7200

Bays
2

M.2/SSD Expansion Slot
1

SSD Details
Not Applicable


Graphics
Integrated Graphics
Yes

Graphics
Aspeed AST2600 with 64MB VRAM Graphics

Graphics Memory Accessibility
Integrated


Audio
Speaker
No


Ports & Slots
Optical Drive
DVD RW

I/O Ports & Connectivity
Front: 1 x VGA port, 2 x USB 3.2, Rear: 2 x USB 3.2, 1 x VGA, 1 x HDMI, 1 x COM, 3 x RJ-45

USB Ports
Front: 2 x USB 3.2, Rear: 2 x USB 3.2

Expansion Slots
3 PCI-e Expansion Slots


Network & Connectivity
LAN Card
4 x Gigabit

Networking Details
Quad Port Intel I210AT & 1 x Management LAN

Remote Management
ASUS ASMB10-iKVM


Software
Operating System
No OS


Physical Description
Body Color
Black & Silver

Form Factor
Rack

Density (1u =1.75 Inch)
1U

Dimensions
497 x 439.5 x 44 mm

Weight (Kg)
13.47 Kg


RAID
Raid Type
Hardware

Raid Model
2G Hardware RAID

Supporting RAID Level
0,1,10,5,6,50 & 60


Power Supply
Number of PSU
2

PSU Capacity
450W

PSU Type
80 PLUS Platinum


Additional Info
Monitor
No Monitor

Keyboard
No

Mouse
No

Others
Dual Intel I210AT Gigabit Ethernet with teaming support, Without Rails Kit, Ubuntu not supported.

Specialty
Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED, AST2600 controller Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency

Country Of Origin
Taiwan

Made in/ Assemble
China


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
