BXB EDC-2051 Conference System Central Unit

Item: BXB EDC-2051 Conference System Central Unit
Rating: 5
Author: Verified Buyer

7 reviews

Product Id: 10.03.951.01

Out Of Stock

See similar model

Quick Overview

Channel - Not Applicable
Connectivity Mode - Wired
Memory Card Slot - No
USB Port - No
Remote Control - No
FM Radio - No
Color - Black

Payment Method Shipping & Charge Order Procedure

Brand

BXB

Model

BXB EDC-2051

Type

Conference System Central Unit

Speaker Type

Wired

Channel

Not Applicable

Connectivity Mode

Wired

RMS/Channel (Watt)

Not Applicable

RMS/Subwoofer (Watt)

Output Power

Unmentioned

Memory Card Slot

USB Port

Microphone

Remote Control

FM Radio

Lighting Effect

Dimensions

430 x 100 x 310mm

Weight (Kg)

4.54kg

Color

Black

Warranty Details

No warranty

General

Brand

BXB

Model

BXB EDC-2051

Type

Conference System Central Unit

Speaker Type

Wired

Audio Details

Channel

Not Applicable

RMS/Channel (Watt)

Not Applicable

RMS/Subwoofer (Watt)

Output Power

Unmentioned

Signal to Noise Ratio (dB)

>-90dB

Frequency (Hz - KHz)

250 Hz-15K Hz( +-2dB)

Connectivity

Connectivity Mode

Wired

USB Port

Slots

Memory Card Slot

Technical Info

Microphone

FM Radio

Input Interface

4x RJ-45 , 1x XLR Plug (MONO)

Performance

Lighting Effect

Waterproof

Dustproof

Shockproof

Power

PA System

Yes

AC Input Power

AC90-264V

Physical Description

Remote Control

Dimensions

430 x 100 x 310mm

Weight (Kg)

4.54kg

Color

Black

Warranty

Warranty Details

No warranty

Additional Info

Others

Total Harmonic :<- 0.15%. Storage Temperature: -15 Degree C -55 Degree C Operation Temperature: 0 Degree C- 40 Degree C, Relative Humidity: 45%-70% (non-condensing), Output Voltage: DC 18V, Output Rated: 6.9A, Current Output Rated Power: 124W, Standby Current: 180mA@DC18V

Specialty

Equipped 4-chain RJ45 ports: each port enables the max. of 15 units; the total is 50 units. Via BXB extension power supply, it enables the max. of 265-unit connection. 4x20 digits LCD screen: shows system status, conferencing modes, the qty. of connected units, m ic rophone s volume and other configurations. Multiple operating modes: Normal/Chairman/Override. Equipped with RS-232 interface: connects with BXB HDS720 IP Network AV Controller, camera, and other environmental control equipment for system integration Equipped XLR plug, enabling the connection with other recording and audio equipmen. Microphone auto-scanning ensures the status of each microphone before meeting. Microphone auto-on/off setting (30/45 seconds). Open-mic mode or activates the max. of 9 microphones at the same time.

Country Of Origin

China

Made in/ Assemble

China

Details

Features of BXB EDC-2051 Speaker In Bangladesh

The BXB EDC-2051 Conference System Central Unit is the main hub that powers and manages a conference system. It’s like the brain of the entire setup, ensuring that all the microphones, speakers, and control units work together seamlessly during meetings or conferences.

Main Features

Central Control: The EDC-2051 is designed to connect and manage multiple delegate and chairman units in a conference. It keeps everything running smoothly by coordinating the audio and control signals between all the connected devices.
Easy Setup: This central unit is user-friendly, making it easy to set up and connect to other units. It helps organize the whole system so that meetings can start without any technical hassles.
High Capacity: The unit can support a large number of delegate and chairman units, making it suitable for small meetings as well as large conferences. It ensures that everyone’s microphone and speaker are working properly.
Clear Audio Management: The EDC-2051 processes and controls the audio signals to ensure clear sound quality for all participants. It reduces noise and feedback, so everyone can hear and be heard clearly.
Multiple Control Options: The central unit allows the meeting organizer to control the system, including who can speak and when. This helps keep the meeting orderly and makes sure that the discussion stays on track.
Reliable Power Supply: It provides a stable power supply to all connected units, ensuring that the system runs smoothly without interruptions.
Expandable System: The EDC-2051 can be expanded to accommodate more units as needed, making it flexible for different meeting sizes and types.

Why It’s Essential

The BXB EDC-2051 Conference System Central Unit is crucial for any organized and efficient conference or meeting setup. It acts as the core of the system, ensuring that all participants can communicate effectively. Whether you’re hosting a small meeting or a large conference, this central unit makes sure that everything runs smoothly, with clear audio and easy control over the entire system.
