Features of C-Data FD504G-X-R410 Optical Network Unit (ONU) In Bangladesh
Brand - C-Data, Model - C-Data FD504G-X-R410, PON Type - EPON, PON Interface - 1 x EPON Optical, PON Port Connector Type - 1000BASE-PX20 plus, PON Port Speed - Symmetric 1.25Gbps upstream/downstream SC/UPC single-mode fiber, PON Port Interface Type - SC/UPC, PON Port Max. Splitting Ratio - 1:64, PON Port Transmission Distance - 20KM, PON Port Wavelength - Tx 1310nm, Rx 1490nm, PON Port TX Power - 0 - 4dBm, PON Port Rx Sensitivity - -27dBm, PON Port Saturation Optical Power - -3dBm, Data Transmission PON Throughput - Downstream 980 Mbps; Upstream 950 Mbps, Ethernet Interface - 4 x 1000Mbps RJ45 LAN, Ethernet Interface Transmission Distance - 100 Meter, Data Transmission Ethernet - 1000 Mbps, Power Interface - 12V DC power supply, Data Transmission Packet Loss Ratio - <1 x 10E-12, Data Transmission Latency - <1.5ms, Network Management - OAM, WEB, Telnet, Management Function - Status monitor, Configuration management, Alarm management, Log management, Power Supply - <4.5W, 12V/0.5A power supply adapter, Operating Temperature - 0 - 40 degree C, Operating Humidity - 10% - 90% (Non-condensing), Dimension - 160 x 112 x 28.5mm, Weight (Kg) - 0.198 kg, Specialty - FD504G-X-R410 XPON ONU is passive optical network terminal produced by C-Data for broadband access market based on XPON technology. Its are used together with XPON OLT to provide a complete broadband access solution. XPON technology is an emerging technology which takes advantage of PON technology and Ethernet technology. Its also points to multi-point network technology, and combined with single-fiber bidirectional technology. OLT device interconnected with multiple ONU through the passive optical network. XPON network system can use fewer fiber cable to meet the multi-user access needs of operators. FD504G-X-R410 fully meets IEEE802.3ah and CTC3.0 standard protocol. It has good compatibility to work with the third party OLT. It supports 1Gbps transmission rate up and down and provides users with good quality of service (QoS), flexible bandwidth allocation of Ethernet data service., Others - User Ethernet Interface Detail: 4 x 10/100/1000M auto-negotiation Full Duplex / Half-Duplex, RJ45 Connector Auto MDI/MDI-X, Warranty - 2 Year (Adapter No Warranty)
What is the price of C-Data FD504G-X-R410 Optical Network Unit (ONU) In Bangladesh?
The price of C-Data FD504G-X-R410 Optical Network Unit (ONU) not mentioned for stock unavailability.The price may vary due to your customization and product availability.
You can buy C-Data FD504G-X-R410 Optical Network Unit (ONU) from our website or visit our showrooms nearby.
