Others
Channel Spacing: Configurable on 5 MHz increments, Frequency range: 5 GHz: 4910 - 5970 MHz (exact frequencies as allowed by local regulations), Channel Width: 5 | 10 | 20 | 40 MHz, MAC (Media Access Control): Layer Cambium Proprietary, Physical Layer: 2x2 MIMO/OFDM, Ethernet Interface: 10/100/1000BaseT, Compatible with Cambium PoE pinouts (V+ = 7 & 8, Return = 4 & 5) and Standard PoE pinouts (V+ = 4 & 5, Return = 7 & 8), Protocols Used: IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH, Network Management: IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro, VLAN: 802.1Q with 802.1p priority, ARQ: Yes, Nominal Receive sSnsitivity (w/FEC) 200MHz Channel: MCS0 = -93 dBm to MCS15 = -72 dBm (per branch), Nominal Receive Sensitivity (w/FEC) @ 40MHz Channel: MCS0 = -90 dBm to MCS15 = -69 dBm (per branch), Modulation Levels (Adaptive): MCS0 (BPSK) to MCS15 (64QAM 5/6), Quality of Service: Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority, Transmit Power Range: -17 to +30 dBm (combined, to regional EIRP limit) (1 dB interval), Integrated Antenna Peak Gain: 16dBi, Maximum Transmit Power: 30 dBm combined (subject to regional regulatory restrictions), Wind Survival: 145 km/hour (90 mi/hour) with antenna, Input Voltage: 10 to 30V, CERTIFICATIONS: (FCCID Z8H89FT0015 Industry Canada Cert 109W-0015 CE 5.4 GHz: EN 301 893 V2.1.1 5.8 GHz: EN 302 502 V2.1.1), 3db Beamwidth-Azimuth: 15 degree, 3db Beamwidth-Elevation: 30 degree, Polarization(s): Dual Linear, H/ V, Front-to-Back Isolation: >20 dB, Cross Polarization: 15 dB.
Specialty
The ePMP Force 180 is the second generation of ePMP Integrated Radio Modules. It has the exceptional reliability and quality that users have come to expect from the ePMP product line and adds some significant performance enhancements, GROWTH AND SCALABILITY The ePMP 1000 delivers high capacity and reliable connectivity right from the start. As a providers business grows, it can expand its network while ensuring resiliency and increasing profitability, QUALITY OF SERVICE (QOS) allows you to confidently offer triple play services VoIP (Voice over IP), video and data. Providing your customers with excellent service quality ensures their continued loyalty and transforms them into advocates, helping WISPs and enterprises expand their business, PROVEN RELIABILITY has created an unsurpassed connectivity standard in many industries that depend on fixed wireless broadband. Our products undergo rigorous testing and are made from high-quality components, POWERFUL FEATURES The Cambium Networks ePMP Force 180 delivers more than 200 Mbps of real user throughput. Using 2x2 MIMO- OFDM technologies, ePMP deployments achieve industry leading data rates, The ePMP Force 180 Integrated Radio can be configured as a Subscriber Module, an unsynchronized Access Point or a Backhaul radio. This radio will function as a client to an ePMP GPS Synchronized Radio in either a Point-to- Multipoint (PMP) or Point-to-Point (PTP) deployment forming a GPS Synchronized solution.
