Cooler Master MasterAir MA620P RGB Air CPU Cooler #MAP-D6PN-218PC-R1

Product Id: 55.02.460.49

Brand Cooler Master

Regular Price Tk 0
Special Price Tk 0

This item is discontinued.

Quick Overview

  • Cooler Type - Air CPU Cooler
  • Fan Speed - 1800 RPM
  • LED Color - RGB
  • Supported Socket - Intel - LGA1200/ LGA1155/ LGA1150/ LGA1151/ LGA1156/ LGA1366/ LGA2011/ LGA2011-V3/ LGA2066/ LGA775, AMD - AM4/ AM3+/ AM3/ AM2+/ AM2/ FM2+/ FM2/ FM1
  • Fan Size (Height) - 120mm
General
Brand
Cooler Master

Model
Cooler Master MasterAir MA620P RGB

Cooler Type
Air CPU Cooler

Series
MasterAir

Part No
MAP-D6PN-218PC-R1


Fan Details
Number of Fans
2

Fan Size (Height)
120mm

Fan Speed
1800 RPM

Fan Noise Level
31 dBA (Max)

Fan Air Flow
53.4 CFM +- 10%

Fan Air Pressure
1.65mm H2O +- 10%

Fan Power Connector
4-Pin PWM

Fan Rated Current
0.30A

Fan Rated Voltage
12VDC

Fan Dimensions
120 x 120 x 25 mm


Heat Sink & Radiator Details
Heat Sink Material
6 Heat Pipes, CDC 2.0, Aluminum Fins

Dimension (Heat Sink/Radiator)
116 x 110.1 x 165 mm

Heat Sink Weight
850 gm

Heat Pipe Dimensions
6 mm


Technical Info
Theme Display
No

LED Color
RGB

PWM Mode
Yes

MTTF
160,000 Hours

Supported CPU Socket Brand
Intel & AMD

Supported Socket
Intel - LGA1200/ LGA1155/ LGA1150/ LGA1151/ LGA1156/ LGA1366/ LGA2011/ LGA2011-V3/ LGA2066/ LGA775, AMD - AM4/ AM3+/ AM3/ AM2+/ AM2/ FM2+/ FM2/ FM1


Power
Approx. Power Consumption
10W

Started Voltage
12V DC


Physical Description
Body Color
Black


Warranty
Warranty
2 Year

Warranty Details
2 year


Additional Info
Feature
The dual tower heatsink has a combination of 2 sets of heatsink towers with 2 sets of MasterFan MF120R RGB. The uniquely designed heatsink allows bigger and more spread out surface area, while the MF120R RGB fans give added air pressure from the outside and inside the heatsink to generate massive cooling performance.

Specialty
SUPERCHARGED COOLING PERFORMANCE, RGB CONTROLLER, DUAL TOWER HEATSINKS & FANS, 2X MASTERFAN MF120R RGB

Others
Fan Speed: 600 - 1,800 RPM (PWM) +- 10%, Heat Sink Material: 6 Heatpipes / CDC 2.0 / Aluminum Fins, Heat Sink Weight: 850gm, Fan MTTF: 160,000 hours, Fan Connector: 4-Pin (PWM), Fan Rated Voltage: 12 VDC, Fan Rated Current: 0.30 A, Fan Safety Current: 0.37 A

Country Of Origin
Taiwan

Made in/ Assemble
China


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
