Brand

Dahua

Model

Dahua DHI-ASI3204E-DW

Type

Access Control

Function

Face, Fingerprint, Card, Password, Remote

Standard Function

Face, Fingerprint, Card, Password, Remote

Display

Yes

Display Size (Inch)

2.4

Fingerprint Sensor

Yes

Camera

Yes

Face Detection Camera

Yes

Fingerprint Capacity

3000

RF Card Capacity

3000

Face Capacity

1000

Logs Capacity

100000

ID Card Capacity

3000

User Capacity

1000PCS

Record Capacity

100000

Interface(s)

WiFi, RJ-485, USB, Wiegand

Power Supply

12V - 2A

Power Adapter

Not Included

Battery.

Body Material

ABS + PC

Dimensions

184.9 x 76.2 x 20.5mm

Weight (Kg)

0.6 kg (Gross)

Color

Black

Warranty

2 Year (Without Adapter)

General

Brand

Dahua

Model

Dahua DHI-ASI3204E-DW

Type

Access Control

Technical Info

Function

Face, Fingerprint, Card, Password, Remote

Standard Function

Face, Fingerprint, Card, Password, Remote

Time Attendance

Yes

Display

Yes

Display Size (Inch)

2.4

Display Details

2.4-inch display screen, Non-touchscreen, 320 x 240

Main Features

Fingerprint Sensor

Yes

Camera

Yes

Camera Details

2MP CMOS HD Dual Cameras

Face Detection Camera

Yes

Facial Recognition Distance

0.3m - 1.5m

Verification Speed

<0.5 Sec. (Fingerprint)

Fingerprint Capacity

3000

RF Card Capacity

3000

Face Capacity

1000

Logs Capacity

100000

ID Card Capacity

3000

User Capacity

1000PCS

Record Capacity

100000

Interface

Interface(s)

WiFi, RJ-485, USB, Wiegand

Wiegand Signal

1 port (reuse the RS-485 port)

Software

Authentication

Face, Fingerprint, Card

Power Info

Power Supply

12V - 2A

Power Adapter

Not Included

Battery.

Operating Temperature

-10 to 45 degree C

Operating Humidity

0% - 90% (RH), non-condensing

Physical Description

Body Material

ABS + PC

Dimensions

184.9 x 76.2 x 20.5mm

Weight (Kg)

0.6 kg (Gross)

Color

Black

Warranty

2 Year (Without Adapter)

Additional Info

Feature

Comes with a 2.4 inch LCD with a resolution of 320 (H) x 240 (V), 2-MP CMOS dual-lens camera with IR illumination and DWDR, Multiple unlock methods including face, ID card, password and fingerprint. You can configure scheduled unlock methods, or combine them to create your own personal unlock methods, Supports 1,000 users, 1,000 faces, 3,000 fingerprints, 3,000 cards, 1,000 passwords, 50 administrators, and 100,000 record, Recognizes faces 0.3 m to 1.5 m away (0.98 ft-4.92 ft) at an accuracy of 99.9%, and compares 1 face with N faces at the speed of 0.2 seconds per person, Supports security extension modules for access control, preventing doors from being forcefully opened, Supports Web attendance management and exporting local attendance reports. Supports doorbell, TCP/IP and Wi-Fi connection, Provides power to the electromagnetic lock and card reader (max 12 V, 1 A).

Others

Main Processor Embedded Processor, Button Type Mechanical, Network Protocol IPv4;RTSP;UDP;P2P;IPv6;RTP;TCP, OSDP Protocol Yes, Interoperability ONVIF;CGI, SDK and API Yes, Product Type Standalone, Display Screen 2.4-inch display screen, Screen Type Non-touchscreen, Screen Resolution 320 (H) x 240 (V), Camera 2 MP CMOS HD Dual Cameras, WDR DWDR, Light Compensation Auto IR, Voice Prompt Yes, Speaker Yes, Casing Material PC + ABS, Verification Method Card/remote/password/fingerprint/face unlock, Card Type ID card, Period List 128 periods, Holiday Period 128 periods, Network Update Yes, First User Unlock Yes, Remote Verification Yes, Restricted List/Trusted List Yes, Wi-Fi Yes, Wireless Standard IEEE802.11b/802.11g/802.11n, Wireless Frequency Range 2.4 G, Peripheral Card Reader One RS-485 card reader or one Wiegand card reader, Multi-user Authentication Yes, Real-time Monitoring Yes, Multi-factor Authentication Yes, Capture Function Yes, Web Configuration Yes, Auto Registration Yes, Card Reading Distance 0 cm to 3 cm, Face Recognition Height Range 1.2 m to 2.0 m (3.94 ft to 6.56 ft), Face Recognition Distance 0.3 m to 1.5 m (0.98 ft to 4.92 ft), Face Recognition Accuracy 99.9%, Face Recognition Time 0.2 s, Fingerprint Sensor Type Optical fingerprint, Fingerprint Verification Mode 1:N, Fingerprint Comparison Time 1.5 s, Fingerprint Recognition Time 0.5 s, User (Card) Type Common users, VIP users, patrol users, visitor users, blocklist users, other users, custom users 1 and custom users 2, RS-485 1 port (reuse the Wiegand port), Wiegand 1 port (reuse the RS-485 port), USB 1 x USB 2.0 port, Network Port 1 x 10/100 Mbps Ethernet port, Doorbell 1, Exit Button 1, Door Status Detection 1, Lock Control 1, Power Output Port 1 (12 V, 1.0 A), Anti-pass Back Yes, Tamper Alarm Yes, Duress Alarm Yes, Door Sensor Timeout Yes, Intrusion Yes, Illegal Card Exceeding Threshold Yes, Duress Fingerprint Yes, Operating Environment Indoor, Installation: Wall Mount.

Country Of Origin

China

Made in/ Assemble

China

Details

Features of Dahua DHI-ASI3204E-DW Access Control In Bangladesh

The Dahua DHI-ASI3204E-DW Door Access Control is a smart security solution designed for modern entry management. Secure access control is essential for protecting offices, institutions, and commercial spaces. Multiple verification methods, including face, fingerprint, card, password, and remote acces,s provide flexible authentication. The 2.4-inch display offers clear and user-friendly interaction. Built-in face detection cameras enhance security with accurate identification. Support for 1000 face users and 3000 fingerprint or card users makes this device suitable for growing organizations. Record capacity of 100000 logs ensures detailed tracking of entry history. WiFi and multiple interface options support easy integration into network systems. Slim black design adds a professional appearance to entry points.

What Makes The Dahua DHI-ASI3204E-DW Door Access Control Special?

This Dahua DHI-ASI3204E-DW Door Access Control stands out with advanced multi-biometric authentication. Face detection cameras improve security with quick recognition. Fingerprint sensor ensures accurate identity verification. Support for card and password access increases flexibility for different users. The remote access feature allows convenient management. Large storage capacity of 100000 records ensures reliable attendance and access tracking. WiFi, RJ-485, USB, and Wiegand interfaces enhance connectivity options. A compact body made of ABS and PC material ensures durability and modern styling. Balanced design supports both security and convenience.

Who Should Buy The Dahua DHI-ASI3204E-DW Door Access Control

This Dahua DHI-ASI3204E-DW Door Access Control is ideal for offices, corporate buildings, schools, and residential complexes. Businesses that require multi-level security verification can benefit from combined face and fingerprint features. Organizations managing employee attendance and entry logs will find this device highly useful. Property managers seeking reliable and modern access systems can confidently choose this model. Institutions that require network-based access control integration will appreciate flexible interface support. Anyone looking for advanced biometric access management can consider this device.

Is The Dahua DHI-ASI3204E-DW Door Access Control Worth Buying?

Yes, this Dahua DHI-ASI3204E-DW Door Access Control is worth buying. This Access Control offers advanced multi-mode authentication, strong storage capacity, and reliable connectivity options for professional security environments. Built-in face detection and fingerprint verification enhance overall protection. Flexible interface support ensures smooth system integration. Durable construction and modern design make this access control system a smart investment for secure and efficient entry management. If you're looking to buy the Dahua DHI-ASI3204E-DW Door Access Control in Bangladesh, Ryans Computers offers the best price in the market.

What is the price of Dahua DHI-ASI3204E-DW Access Control In Bangladesh?

The price of Dahua DHI-ASI3204E-DW Access Control starts from 9,000 . The price may vary due to your customization and product availability. You can buy Dahua DHI-ASI3204E-DW Access Control from our website or visit our showrooms nearby.
