Feature
AI by Recorder: Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus, AI by Camera: Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring, AcuPick AI by Camera + Recorder: Max. 64-channel, 1 combined event per channel, Perimeter Performance AI by Recorder (Number of Channels): Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode, Perimeter Performance of AI by Camera (Number of Channels): All channels (64 targets/s), Face Attributes: Gender; age group; glasses; expressions; face mask; beard, Face Detection Performance of AI by Recorder (Number of Channels): imultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode, Face Detection Performance of AI by Camera (Number of Channels): 64 channels, Face Database Capacity: Up to 40 face databases with 300,000 images, with a total capacity of 48 G. Face Recognition Performance of AI by Recorder (Number of Channels): channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode, Face Recognition Performance of AI by Camera (Number of Channels): 64 channels, SMD Plus by Recorder: 32-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change, SMD Plus by Camera: All channels (128 targets/s), Disk Group, Hot Swapping.
Others
Operating Interface: Web, Local GUI, Metadata Performance of AI by Recorder (Number of Channels): 8 channels, Metadata Performance of AI by Camera (Number of Channels): 64 channels, People Attributes: 9 human body attributes, Human Attributes: Top color, top type, hat, bag, age, gender and umbrella, Motor Vehicle Attributes: License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling,, Non-motor Vehicle Attributes: Vehicle model, vehicle color, number of persons, helmet. ANPR by Camera (Number of Channels): All channels (64 targets/s), License Plate Database Capacity: Blocklist and allowlist: 20,000, Network Bandwidth: AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing, AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing, Decoding Capability: AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps 128-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps, 80-channel D1@30 fps, Multi-screen Display: Main screen: 1/4/8/9/16/25/36/64, Sub screen: 1/4/8/9/16/25/36, Interoperability: ONVIF (Profile S/profile T/Profile G); CGI; SDK, Browser: Chrome, IE 9 or later, Firefox, Network Mode: Multi-address mode, load balance, fault tolerance and other network port binding modes, Multi-channel Playback: Up to 16 channels, Record Mode: Backup Method: Portable hard drive, eSATA disk, burner, USB device and network: Playback Mode: 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame, 2. Full screen, backup (cut/file), partially enlarge, audio on/off, RAID 0/1/5/6/10, General Alarm: Motion detection; video tampering; video loss; scene changing, PIR alarm, IPC external alarm, Anomaly Alarm: Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan, Intelligent Alarm: Face detection; face recognition; perimeter protection (intrusion and tripwire); SMD Plus alarms; ANPR; people counting; stereo analysis; crowd distribution; heat map, Alarm Linkage: Record; snapshot; IPC external alarm output; buzzer; log, preset; email, Alarm Input: 16 channels, Alarm Output: 8 channels, 1 x RS-232, 1 x A/B RS-485, 4 x HDMI, 2 x VGA, Operating Temperature: -10 Degree C to +55 Degree C, Storage Temperature: 0 Degree C to +40 Degree C, Operating Humidity: 10%-93% (RH), non-condensing.
