Gigabyte Z490 VISION D (Wi-Fi 6) DDR4 10th Gen Intel LGA1200 Socket Motherboard
Product Id: 02.01.018.305
Brand
Gigabyte
Regular Price
Tk 0
Quick Overview
- Chipset - Intel Z490
- Sockets Supported - LGA1200
- Supported CPU - 10th Generation Intel Core i9 / i7 / i5 / i3 / Pentium / Celeron Processors
- Generation - 10th
- Memory Slot - 4
- Memory Max. - 128GB
- Back-Connect Design - No
Brand
Gigabyte
Model
Gigabyte Z490 VISION D
Chipset
Intel Z490
Sockets Supported
LGA1200
Built-in Processor
No
Generation
10th
Back-Connect Design
No
Memory Type
DDR4
Memory Slot
4
Memory Max.
128GB
Optane Memory Support
Yes
Graphics
Integrated
Graphics Chipset
Integrated With Processor
M.2/SSD Expansion Slot
3
WiFi
Yes
Bluetooth
Bluetooth 5.1
Form Factor
ATX
Supported Operating System
Windows 10
Body Color
Black
Warranty Details
3 year
N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
Details
Features of Gigabyte Z490 VISION D Motherboard In Bangladesh
Gigabyte Z490 VISION D
Bring your creative designs to life by including the Gigabyte Z490 Vision D LGA 1200 ATX Motherboard in your desktop computer system build. Designed for creative professionals, this ATX motherboard is powered by the Intel Z490 chipset and supports 10th generation Intel processors with the LGA 1200 socket. It takes full advantage of the PCIe 3.0 data bandwidth, with support for PCIe 4.0 CPUs, to deliver high performance for tasks such 3D rendering, video editing, and more. Up to 128GB of dual-channel DDR4 RAM, reaching 4400 MHz when overclocked, can be installed across four memory slots. The motherboard also features advanced cooling and supports up to three M.2 SSDs and six SATA III storage drives with Intel Optane, which can be put into RAID 0, 1, 5, or 10 configuration. Its three PCIe 3.0 x16 slots are designed to support professional-grade graphics cards and can accommodate 2-Way and Quad-GPU NVIDIA SLI and AMD CrossFireX configurations to maximize frame rates, connecting 4K monitors, and accelerate video rendering times. Alternatively, the built-in HDMI port allows you to take advantage of integrated CPU graphics. An additional PCIe 3.0 x1 slot is available for compatible expansion cards.
You can also daisy chain compatible monitors, external storage drives, and other devices to the Thunderbolt 3 ports for a maximum data transfer rate of 40 Gb/s. The DisplayPort input allows you to connect external graphics cards to external monitors and high-end drawing tablets through the Thunderbolt 3 port. The USB 3.2 Gen 2 Type-A and Type-C ports allow you to transfer data from compatible peripherals at up to 10 Gb/s. Enjoy fast network connections using the Gigabit and 2.5 Gigabit Ethernet ports in addition to the built-in 802.11ax Wi-fi, which can wirelessly transfer data at up to 2.4 Gb/s with compatible devices. The Z490 Vision D also delivers vibrant 7.1-channel surround sound Realtek ALC1220-VB audio codec. You can customize your computing experience using the addressable RGB headers to connect light strips, which can be synced with other Gigabyte RGB Fusion 2.0-compatible peripherals such as mice and keyboards using the desktop software or mobile app. Windows 10 64-bit is required to take advantage of all the motherboard's features.
Storage and Memory
- Three M.2 slots are available, supporting up to type 22110 SATA and PCIe NVMe SSDs.
- Six SATA III headers are available for hard drives and 2.5" SSDs.
- RAID 0, 1, 5, and 10 configurations are supported.
- Intel Optane memory modules are supported, which enhance storage drives by caching frequently accessed data.
- Up to 128GB of dual-channel DDR4-4400(OC) memory can be installed across four slots.
Performance Features
- The PCIe slots are designed to support PCIe 4.0 CPUs.
- The Z490 Vision D features a digital PWM controller and DrMOS with 12+1 power stages that can handle up to 600A of current total.
- A double copper layer PCB design efficiently delivers power to critical components at lower temperatures.
Thunderbolt 3
Thunderbolt 3 is a hardware interface that utilizes the reversible USB Type-C connector. Doubling the speed of its predecessor, Thunderbolt 3 features a maximum throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB 3.1 at up to 10 Gb/s, and dual-bandwidth DisplayPort 1.2 allows you to connect up to two 4K displays simultaneously. Additionally, you can daisy chain up to six devices from a single Thunderbolt 3 port.
DisplayPort Input
The DisplayPort input allows you to connect external graphics cards to external monitors and high-end drawing tablets through the Thunderbolt 3 port.
USB 3.2 Gen 2
Doubling the speed of its predecessor, USB 3.2 Gen 2 features a maximum throughput of 10 Gb/s when used with compatible devices.
DAC-UP 2 Technology
Gigabyte's USB DAC-UP 2 ports are designed to provide dedicated clean, isolated, low-noise power to connected devices and automatically compensates for voltage drops, making it ideal for devices such as virtual reality headsets, external storage drives, and more.
Enhanced Cooling
- The Gigabyte multi-cut heatsink, direct-touch heatpipe, and thick thermal pad work to deliver lower MOSFET temperatures.
- Thermal guards help to quickly dissipate heat from the M.2 solid-state drives to avoid speed throttling.
Designed for Durability
- Solid plated ATX 24-pin and 8-pin power connectors deliver a stable power supply to key components.
- Diagnostic LEDs help to quickly troubleshoot problems.
- This motherboard features resistors with an anti-sulfur layer that help prevent sulfur compounds in the air from causing electrical malfunctions.
- With the Q-Flash Plus feature, you can update the BIOS without having to install a CPU or video card. Simply copy the new BIOS file to a USB flash drive, insert it into the designated port, then press the Q-Flash button.
NVIDIA SLI / AMD CrossFireX Support
Installing multiple graphics cards will enhance the computer's performance for demanding tasks such as CAD, 3D rendering, video editing, and more. This motherboard supports Quad-GPU and 2-Way NVIDIA SLI and AMD CrossFireX configurations.
Immersive Audio
- The Realtek ALC1220-VB audio codec provides vibrant 7.1-channel surround sound to your speakers.
- 120 dBA headphone SNR.
- 110 dBA microphone SNR.
- High-grade capacitors are used for feedback signal processing.
Network Performance
- The Gigabit and 2.5 Gigabit Ethernet ports provide fast network connection with high-speed data transfers using compatible devices.
- Built-in 802.11ax dual-band Wi-Fi transfers up to 2.4 Gb/s of data over compatible wireless networks.
- The cFosSpeed network traffic management application to automatically allocate bandwidth so that the highest network priority goes to games or specified applications.
- Bluetooth 5 offers a faster transmission rate and 4X the range of Bluetooth 4.2.
RGB Fusion 2.0 Lighting
With Gigabyte's RGB Fusion 2.0 technology, you can customize your computer by installing RGB lighting strips alongside compatible components and peripherals for incredible effects. Lighting profiles that cover your entire system, including the motherboard, video card, and CPU can be configured and controlled using the Gigabyte RGB Fusion 2.0 desktop software or mobile app.
What is the price of Gigabyte Z490 VISION D Motherboard In Bangladesh?
The price of Gigabyte Z490 VISION D Motherboard not mentioned for stock unavailability. The price may vary due to your customization and product availability. You can buy Gigabyte Z490 VISION D Motherboard from our website or visit our showrooms nearby.
