Others
Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light, Angle Adjustment: Pan: 0 Degree to 360 Degree, tilt: 0 Degree to 90 Degree, rotate: 0 Degree to 360 Degree, Aperture: F1.0, Depth of Field: 2.8 mm: 3.1 m to Infinity, DORI: 2.8 mm, D: 58.2 m, O: 23.1 m, R: 11.6 m, I: 5.8 m, Supplement Light Type: White light, Supplement Light Range: Up to 60 m, Video Bit Rate: 32 Kbps to 8 Mbps, H.264 Type: Baseline Profile/Main Profile/High Profile, H.265 Type: Main Profile, Bit Rate Control: CBR/VBR, Scalable Video Coding (SVC): H.265 and H.264 encoding, Region of Interest (ROI): 1 fixed region for main stream and sub-stream, Audio Compression: G.711ulaw/ G.711alaw/ G.722.1/ G.726/ MP2L2/ PCM/ MP3/ AAC-LC, Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC), Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz, API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, User/Host: Up to 32 users. 3 user levels: administrator, operator and user, Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR), microSD/microSDHC/microSDXC card (512 GB) local storage Together with high-end Hikvision memory card, memory card encryption and health detection are supported, Client: iVMS-4200, Hik-Connect, Hik-Central, Web Browser: Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+, Image Enhancement: BLC, HLC, 3D DNR, On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB, Built-in Speaker: 2 W, 10 cm: 97 dB, Audio: 1 input (line in), two-core terminal block , max. input amplitude: 3.3 Vpp, input impedance: 4.7 Kohm, interface type: non-equilibrium, 1 output (line out),two-core terminal block , max. output amplitude: 3.3 Vpp, output impedance: 100 ohm, interface type: non-equilibrium, Alarm: Visual alarm, 1 input, 1 output (max. 24 VDC/24 VAC, 1 A), Environment: CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006.
Specialty
Smart Supplement Light, Environment Noise Filtering, Image Parameters Switch, Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser, Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception, Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)) Scene change detection, Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning, trigger alarm output, Face Capture,
