Feature
Video Output Resolution (BNC): PAL: 704 x 576@25 Hz, NTSC: 704 x 480@30 Hz, Loading Capacity for Video Output to LED, Single port load: 2600000, Width: 144 - 4096, Height: 144 - 2160, Width must be a multiple of 2 and height must be a multiple of 2, Video Decoding Resolution Up to 32 MP, Video Decoding Channel(s)256, Video Decoding Capability: 1) H.264/H.265 format: Support decoding 8-channel 32 MP/24 MP, 16-channel 12 MP, 32-channel 8 MP, 40-channel 6 MP, 64-channel 4 MP, 128-channel 1080p, 256-channel 720p and lower resolution in real time. Every four output ports (HDMI output ports 1 to 4, 5 to 8, 9 to 12, and 13 to 16) form a group and 4 groups share the decoding capabilities. Each group supports up to 4-channel smart decoding or 4-channel encrypted stream decoding. The smart decoding allows the device to decode the smart alarm events from the network cameras. 2) MJPEG format: 16-channel of 1080p and lower resolution, 3) HIK264 format: 8-channel of 720p and lower resolution, Audio Output Interface(s)16, Audio Output Interface Type Embedded HDMI audio output port or independent DB15-to-BNC audio output port
Others
Alarm In Interface No.: 8 channels of alarm input, Alarm Out Interface No.: 8 channels of alarm output, Video Walls: 1, Video Wall Scale: <-16, Split Window: Supported, Layers Per Screen: 4 x 1080p or 2 x 4K, Layers per Device: Layers Per Screen x Output Interface(s), Scenes 64, Plans: 100 view groups on the HCP client, Working Temperature -10 Degree C to 55 Degree C, Working Humidity 0% RH to 90 % RH, Audio Input Interfaces: 2, Audio Input Interface Type Embedded HDMI, Video Input Interfaces: 2, Video Input Interface Type: HDMI 1.4, Max. Input Resolution: 4K (only in odd-numbered port), Video Input Resolution: 3840 x 2160@30 Hz, 1920 x 1200@60 Hz, 1920 x 1080@60 Hz, 1920 x 1080@50 Hz, 1280 x 720@60 Hz, 1280 x 720@50 Hz, 1600 x 1200@60 Hz, 1280 x 960@60 Hz, 1680 x 1050@60 Hz, 1440 x 900@60 Hz, 1366 x 768@60 Hz, 1280 x 1024@60 Hz, 1024 x 768@60 Hz, Supports custom resolution.: For 60 Hz input, width ranges from 800 to 1920, and height ranges from 600 to 1200. For 30 Hz input, width ranges from 800 to 3840, and height ranges from 600 to 2160. Width: 4 alignment, height: 2 alignment. Video Encoding Channels 2, Video Encoding Capability 1 channel of 4K@30 Hz or 2 channels of 1080p@60 Hz, Video Output Interface Type HDMI 1.4, Video Output Interface(s) 16, Max. Output Resolution 4K, Video Output Resolution: 3840 x 2160@30 Hz, 2560 x 1440@30 Hz, 1920 x 1200@60 Hz, 1920 x 1080@60 Hz, 1920 x 1080@50 Hz, 1680 x 1050@60 Hz, 1600 x 1200@60 Hz, 1280 x 1024@60 Hz, 1280 x 720@60 Hz, 1280 x 720@50 Hz, 1024 x 768@60 Hz
