Hikvision DS-8116HQHI-K8 16 Channel HD 1080p Turbo HD DVR

Product Id: 127.02.485.300

Brand Hikvision

Regular Price Tk 74,870 Monthly EMI Tk 6,239
Special Price Tk 70,000

Delivery in 1 days

Quick Overview

  • Dual Stream Support - Yes
  • Number HDD Interface (SATA) - 8 SATA
  • Max. Storage Support - 80TB
Brand
Hikvision

Model
Hikvision DS-8116HQHI-K8

Type
DVR

Video Input Channel (BNC)
1.0 Vp-p, 75 ohm

Video Compression/Format
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Video Output (VGA)
1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60hz

Video Output (HDMI)
1-ch, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz

Max. Video Recording Res.
1080p

Video Bit Rate
32 Kbps to 6 Mbps

IP Video Input
8-ch (up to 24-ch), Up to 6 MP resolution, Support H.265+/H.265/H.264+/H.264 IP camera

Analog & HD-TVI Video Input
16-ch, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p6

Audio Input Channel (RCA)
16-ch, RCA (2.0 Vp-p, 1 k ohm)

Audio Compression
G.711u

Audio Output Channel
2-ch, RCA (Linear, 1 K ohm)

Two way Audio
1-ch, RCA (2.0 Vp-p, 1 K ohm) (independent)

Audio Bit Rate
64 Kbps

Frame Rate
Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF @25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/WD1/4CIF/VGA/CIF@15fps For 1080p stream access: 1080p/720p@15fps; WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p lite/WD1/4CIF/VGA /CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF@15fps For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

Stream Type
Video, Video & Audio

Dual Stream Support
Yes

Synchronous Playback
16-ch

Network Protocol
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF

Number HDD Interface (SATA)
8 SATA

Max HDD Support (GB,TB)
10 TB for a single HDD

Max. Storage Support
80TB

eSATA
Yes

Network Interface (RJ45)
2 x RJ45 10M/100M/1000M self-adaptive Ethernet interface

Serial Interface
RS-232, RS-485 (full-duplex), Keyboard

USB Port
Front panel: 2 x USB 2.0, Rear panel: 1 x USB 3.0

Remote Connections
128

CVBS Input
PAL/NTSC

Power Supply
100 to 240 VAC, 50 to 60 Hz, 1.3 A

Approx. Power Consumption
=< 45 W

Dimensions
440 x 470 x 90mm

Weight (Kg)
=< 10 kg

Feature
Support H.265 Pro+/H.265 Pro/H.265 video compression, Support HDTVI/AHD/CVI/CVBS/IP video inpu, Max 12/24 IP cameras input (up to 6 MP), Max 800 m for 1080p and 1200 m for 720p HDTVI signal, Up to 10 TB capacity per HDD. Support POS triggered recording and POS information overlay.

Others
AHD input - 4 MP, 1080p25, 1080p30, 720p25, 720p3, HDCVI input - 1080p25, 1080p30, 720p25, 720p30, Alarm in/out - 16/8.

Warranty Details
1 year

Country Of Origin
China

Made in/ Assemble
China


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
