Hikvision DS-D5A86RB-A3 86 Inch 16GB RAM (8GB+8GB Virtual) 128GB ROM Android 16 4K UHD Touch Interactive Flat Panel

Item: Hikvision DS-D5A86RB-A3 86 Inch 16GB RAM (8GB+8GB Virtual) 128GB ROM Android 16 4K UHD Touch Interactive Flat Panel
Rating: 5
Author: Verified Buyer

Product Id: 118.01.485.50

Special Price
Tk 350,000

Regular Price

Tk 379,750

EMI TK 31,646

Delivery in 45 days

Quick Overview

Country Of Origin - China
Display Size - 86 Inch
Resolution - 3840 x 2160
Number of Touch - 50 Point
Embedded OS - Android 16
Storage (MB/GB/TB) - 128GB
Speaker Details - Built-in 2 x 20W
Body Color - Gray

Avail EMI Offer

EMI starts from Tk 42,194/months

Payment Method Shipping & Charge Order Procedure

Brand

Hikvision

Model

Hikvision DS-D5A86RB-A3

Technology

4K UHD Interactive Flat Panel

Display Size

86 Inch

Resolution

3840 x 2160

Panel Type

IPS

Number of Touch

50 Point

Touch Resolution

32768 x 32768

Refresh Rate (Hz)

60Hz

Camera (Built-in)

Processor

Quad-core Cortex-A72 x 4 (2.2 GHz) and quad-core Cortex-A53 x 4 (1.8 GHz)

RAM

16GB

Storage (MB/GB/TB)

128GB

Speaker (Built-in)

Yes

HDMI Input

USB Port

USB 3.0 x 2 (Front x 2), USB 2.0 x 2 (Rear x 2), Type-C x 1 (Front x 1) Supports USB 3.0, 15 W charging functions)

Lan Port

2 x RJ45

Power (Watt)

<=0.5W, <160W (Average)

Embedded OS

Android 16

Wall Mounting

800 x 600mm

Body Color

Gray

Dimensions

2157.0 x 1345.0 x 223.0mm

Weight

52.38 kg

Accessories In The Box

Hikvision DS-D5A65RB/A3, Wall mount bracket, hook, user manual, touch writing pen, packing list, power cable, remote control.

Warranty

3 year

General

Brand

Hikvision

Model

Hikvision DS-D5A86RB-A3

Technology

4K UHD Interactive Flat Panel

Display

Display Size

86 Inch

Resolution

3840 x 2160

Supported Display Resolutions

3840 x 2160

Display Area

1895.04 x 1065.96mm

Anti-Glare

Yes

Panel Type

IPS

Panel Bit

10bit (8 bit + FRC)

Aspect Ratio

16:9

Brightness (cd/m2)

400cd/m2

Colors

1.07 Billion

Light Source Type

DLED

Light Life

50000 hours

Color Gamut

72% NTSC (CIE1931) (Typ.)

Refresh Rate (Hz)

60Hz

Contrast Ratio

1200:1 (Static), 15,000:1 (Dynamic)

Response Time (ms)

5ms

Viewing Angle.

178 Degree (H & V)

Surface

9H (Pencil), 7 (Mohs)

Number of Touch

50 Point

Touch Resolution

32768 x 32768

Hardware

Processor

Quad-core Cortex-A72 x 4 (2.2 GHz) and quad-core Cortex-A53 x 4 (1.8 GHz)

RAM

16GB

Storage (MB/GB/TB)

128GB

GPU

Mali-G52 MC3

Technical Info

Camera (Built-in)

Camera Technology

Not Applicable

Connectivity

Input Ports

Ram Details: 16GB (8GB+8GB Virtual), HDMI 2.1 TMDS x 3, Audio x 1, TOUCH-USB 2.0 x 1 (Front x 1), TOUCH-USB 2.0 x 1 (Rear x 1), RS232 x 1 (Rear), LAN (1000 Mbps) x 2 (Rear), Wi-Fi AP & Station, 2.4 G/5 G, Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 x 2 MIMO (2.4 GHz and 5 GHz) authentication, protocols WEP, WPA, WPA2, PSK and 802.1X EAP, USB 3.0 x 2 (Front x 2), USB 2.0 x 2 (Rear x 2), Type-C x 1 (Front x 1) Supports USB 3.0, 15 W charging functions), TF-Card Slot 1 (Rear x 1).

Output Ports

Audio x 1

HDMI Input

USB Port

USB 3.0 x 2 (Front x 2), USB 2.0 x 2 (Rear x 2), Type-C x 1 (Front x 1) Supports USB 3.0, 15 W charging functions)

RS232 Input/Output

Lan Port

2 x RJ45

Audio

Speaker (Built-in)

Yes

Speaker Details

Built-in 2 x 20W

Audio In

Audio Out

Electrical

Power (Watt)

<=0.5W, <160W (Average)

Power (AC) Input

100 to 240 VAC, 50/60 Hz

Environmental

Operating Temperature

0 Degree C to 40 Degree C

Operating Humidity

10%~90% RH

Physical Description

RF (NFC Reader/Writer)

Yes

Wall Mounting

800 x 600mm

Body Color

Gray

Dimensions

2157.0 x 1345.0 x 223.0mm

Weight

52.38 kg

Accessories In The Box

Hikvision DS-D5A65RB/A3, Wall mount bracket, hook, user manual, touch writing pen, packing list, power cable, remote control.

Software

Embedded OS

Android 16

OS Supported

Android

Warranty

3 year

Additional Info

Others

Pixel Pitch 0.164 (H) x 0.493 (V) mm, Surface Haze 25% Haze, Glass Bonding Method Zero Lamination, Working Duration 7 x 16 H, Transmittance 88% -/+3, Type Infrared Touch Screen, Touch Point Up to 50-point multi-touch, Touch Response Time <= 5 ms, Minimum Touch Object >= 1.5 mm (>= 90% touching area), Touch Precision -/+ 0.5 mm (>= 90% touching area), HDCP Version 2.3 & 2.0 & 1.4, Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4, 13.56 MHz, (ISO 14443A/ ISO 14443B), Light Sensor.

Feature

Built-in Android 16 system, EDLA certified. Anti-glare and anti-blocking design to ensure smooth interaction. Quick response, up to 50-point touch control, and a smooth writing experience. Built-in network switch chip eliminates the need for an external network switch. Multi-button front design, convenient for classroom use. All-in-one design with tempered glass and intelligent temperature control, making it environmentally friendly and safe.

Country Of Origin

China

Made in/ Assemble

China
