Wall mount bracket, hook, user manual, stylus x 2, packing list,1.5 m power cable (European standard), remote controller
Warranty Details
3 year
General
Brand
Hikvision
Model
Hikvision DS-D5B75RB/EL
Technology
4K UHD Interactive Flat Panel
Display
Display Size
75 Inch
Resolution
3840 x 2160
Supported Display Resolutions
3840 x 2160
Display Area
1649.66 x 927.94 mm
Anti-Glare
Yes
Panel Type
IPS
Panel Bit
10 bit
Aspect Ratio
16:9
Display Orientation
Landscape
Brightness (cd/m2)
400cd/m2 (Typical)
Colors
1.07G
Light Source Type
DLED
Light Life
50,000 Hours
Color Gamut
72% NTSC (CIE1931) (Typ.)
Refresh Rate (Hz)
60Hz
Contrast Ratio
1200:1 (Static), 15,000:1 (Dynamic)
Response Time (ms)
5ms
Viewing Angle.
178 Degree (H & V)
Surface
Surface
25% Haze
Number of Touch
40 Point
Touch Interface
TOUCH-USB 2.0 x 1
Touch Resolution
32767 x 32767
Hardware
Processor
Cortex-A55 x 4 (1.92GHz)
RAM
8GB
Storage (MB/GB/TB)
64GB
GPU
Mali-G52 MP2 (2EE)
Technical Info
Camera (Built-in)
No
Tempered Glass
3.2mm Glass
Connectivity
Control
Remote Control
Connectivity
Wi-Fi & Bluetooth
Input Ports
HDMI In (HDMI 2.0) x 2, Audio In x 1
Output Ports
Audio Out x 1
HDMI Input
2
USB Port
USB 3.0 x 3, USB 2.0 x 2, Type-C x 1
RS232 Input/Output
1
Lan Port
2 x RJ45
OPS Included
No
OPS Slot
Yes
Audio
Speaker (Built-in)
Yes
Speaker Details
2 x 20W
Microphone (Built-in)
No
Audio In
1
Audio Out
1
Electrical
Power (Voltage)
100 to 240 VAC, 50/60 Hz
Approx. Power Consumption
217W (Max.), 175W (Average), <- 0.5W (Standby)
Environmental
Operating Temperature
0 Degree C to 40 Degree C
Operating Humidity
10%~90% RH
Physical Description
Body Color
Black
Dimensions
1713.23 x 1025.53 x 82.5mm
Weight
49.15 kg
Accessories In The Box
Wall mount bracket, hook, user manual, stylus x 2, packing list,1.5 m power cable (European standard), remote controller
Software
Embedded OS
Android 13
OS Supported
Android
Warranty
Warranty Details
3 year
Additional Info
Others
Pixel Pitch0.143 (H) mm x 0.430 (V) mm, Working Duration7 x 16H, Surface Hardness: 9H (Pencil), 7 (Mohs), Transmittance: 88% +/- 3, Type: Infrared Touch Screen, Minimum Touch Object>- 2 mm (>- 90% touching area), Touch Precision +/- 1 mm (>- 90% touching area) , HDCP Version: Support 1.4/2.2/2.3, Speaker Frequency: 200-20Khz, Bluetooth: Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.2, NFC: Support card reader, Light Sensor: Yes, WIFI AP&Station: 2.4G/5G, WIFI AP: IEEE 802.11 a/b/g/n/ac 2 x 2 MIMO (2.4 GHz and 5 GHz) authentication protocols , WEP, WPA, WPA2, PSK and 802.1X EAP, WIFI Station: IEEE 802.11 a/b/g/n/ac/ax 1 x 1 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP
Feature
UHD 4K display with resolution of 3840 x 2160. Anti-glare and anti-blocking design to ensure smooth interaction. Dual systems of Android and Windows (optional) saving cost and easy to use, video conference software are recommended to run under Windows system. Quick response, at most 40-point touch controls and smooth writing experience. Multi-button design in front, convenient for classroom use. Compatible with OPS/OPS-C devices, realizing smooth switch between built-in systems.
Country Of Origin
China
Made in/ Assemble
China
