Brand

Hikvision

Model

Hikvision iDS-7216HQHI-M2/XT

Type

DVR

Number of Input Channel

16 Channel

Video Output (VGA)

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Video Output (HDMI)

1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Max. Video Recording Res.

1080p

Audio Input Channel (RCA)

1-ch(up to 16-ch is optional), RCA (2.0 Vp-p, 1 Kohm), 16-ch via coaxial cable

Two way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Dual Stream Support

Yes

Number HDD Interface (SATA)

Max HDD Support (GB,TB)

Up to 12 TB capacity for each disk

USB Port

Front panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0

Approx. Power Consumption

<=40W

Color

Black

Dimensions

384 x 317 x 52mm

Weight (Kg)

<= 2 kg

Warranty

2 Year (Without Adapter)

General

Brand

Hikvision

Model

Hikvision iDS-7216HQHI-M2/XT

Type

DVR

Video Info

Number of Input Channel

16 Channel

Video Input Channel (BNC)

16 Channel

Video Compression/Format

H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Video Output (VGA)

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Video Output (HDMI)

1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Max. Video Recording Res.

1080p

Video Bit Rate

32 Kbps to 6 Mbps

IP Video Input

8-ch (up to 24-ch), each up to 6MP

Analog & HD-TVI Video Input

16-ch BNC interface (1.0 Vp-p, 75 ohm), supporting coaxitron connection

Audio Info

Audio Input Channel (RCA)

1-ch(up to 16-ch is optional), RCA (2.0 Vp-p, 1 Kohm), 16-ch via coaxial cable

Audio Compression

G.711u

Audio Output Channel

1-ch, RCA (Linear, 1 Kohm)

Two way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Audio Bit Rate

64 Kbps

Recording & Decoding

Frame Rate

15fps/ 20fps/ 25fps/ 30fps

Stream Type

Video, Video & Audio

Dual Stream Support

Yes

Decoding Capability

up to 24-ch 1080P@30fps

Synchronous Playback

16-ch

Network

Network Protocol

TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP

Network Interface (RJ45)

1 x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface

POE Interface

Remote Connections

128

Auxiliary Interface

Number HDD Interface (SATA)

Max HDD Support (GB,TB)

Up to 12 TB capacity for each disk

Max. Storage Support

24TB

Serial Interface

RS-485 (half-duplex)

USB Port

Front panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0

Technical Info

CVBS Input

PAL/NTSC

Power Info

Power Supply

12 VDC, 3.3 A

Approx. Power Consumption

<=40W

Physical Description

Color

Black

Dimensions

384 x 317 x 52mm

Weight (Kg)

<= 2 kg

Warranty

2 Year (Without Adapter)

Additional Info

Feature

16 channels and 2 HDD 1U AcuSense DVR, Support 4-ch Facial Recognition or 8-ch advanced model Perimeter Protection based on Deep Learning algorithm. 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP). Support All channels Motion Detection Technology. Up to 24 channels IP camera inputs, each channel up to 6MP.

Others

Human/Vehicle Analysis Up to 8-ch (advanced model), Facial Detection and Capture Face picture detection, face picture search, 4-ch face picture capture, Face Picture Library: Up to 16 face picture libraries; HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash. Face Picture Comparison 4-ch face picture comparison alarm (HD analog camera). Motion Detection 2.0: Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480, HDTVI Input 3K(2960 x 1665)@25/20fps, 3K(3328x1504)@20fps,2K(2304x1296)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30fps,1080P@25/30 fps, 720P@25/30fps, AHD Input 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps, HDCVI Input 3K(2880×1620)@20/25 fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30 fps, Video Output Mode HDMI/VGA simultaneous output. Encoding Resolution When 1080p Lite mode is not enabled: 2K/3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 2K/3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF, Total Bandwidth 256 Mbps, Working Temperature -10 to 55 Degree C, Working Humidity 10% to 90%.

Country Of Origin

China

Made in/ Assemble

China

Details

Features of Hikvision iDS-7216HQHI-M2/XT DVR/NVR/XVR In Bangladesh

What is the price of Hikvision iDS-7216HQHI-M2/XT DVR/NVR/XVR In Bangladesh?

The price of Hikvision iDS-7216HQHI-M2/XT DVR/NVR/XVR starts from 17,500 . The price may vary due to your customization and product availability. You can buy Hikvision iDS-7216HQHI-M2/XT DVR/NVR/XVR from our website or visit our showrooms nearby.
