N.B. Image may differ with actual product's layout, color, size & dimension. No claim will be accepted for image mismatch.

Huawei AP263 Wi-Fi 6 Wireless Wall Plate eKit Access Point

Product Id: 29.02.487.36

Brand Huawei

Regular Price Tk 23,220 Monthly EMI Tk 1,935
Special Price Tk 21,500

Delivery in 1 days

Quick Overview

  • Data Transfer Rates - Unmentioned
  • Network Standards - 802.11b/g/n/ax, 802.11a/n/ac/ac Wave 2/ax
  • Antenna (Type & Qty) - 4 x Internal
  • Interface(s) - 1 x GE/PoE_IN, 1 x GE, 1 x USB 2.0 Type-A
  • Band - Dual
General
Brand
Huawei

Model
Huawei AP263


Hardware
Network Standards
802.11b/g/n/ax, 802.11a/n/ac/ac Wave 2/ax

Data Transfer Rates
Unmentioned

WAN Network Standard
10/100/1000

LAN Network Standard
10/100/1000

Storage (MB/GB/TB)
256MB

Storage Type
NAND Flash


Interface
Interface(s)
1 x GE/PoE_IN, 1 x GE, 1 x USB 2.0 Type-A

Number of WAN Port
1

Number of LAN Port
1


Wireless
Band
Dual

Frequency
2.4GHz, 5GHz

Bluetooth
Yes

Antenna (Type & Qty)
4 x Internal

Antenna Gain
2.4G: 2 dBi/chain (peak value), 1 dBi (combined gain). 5G: 3 dBi/chain (peak value), 1 dBi (combined gain).

Antenna Placement
Internal

MU-MIMO Support
2x2

Transmission Power
2.4G: 20 dBm/chain, 23 dBm (combined power). 5G: 20 dBm/chain, 23 dBm (combined power). BLE: < 10 dBm. Singal radio transmit power [dBm]: 2.4G: -10 dBm to 20 dBm/chain, 5G: -10 dBm to 20 dBm/chain. MTTR [hour]: 0.5 hour. Frequency stability [ppm]: +/-20.


Performance
Protection
PoE port: Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B. Common mode (8 wires to ground): 6 kV (1.2/50 us, 42 ohms), criterion B.


Technical Info
MTBF
69.7 Year


Electrical
DC Input Power
12V

Power Adapter Input
12V DC

Max. Power Consumption
12W

Passive PoE Power Supply
802.3at/af


Environmental
Operating Temperature
0 - 40 Degree C

Operating Humidity
5% - 95% RH

Storage Temperature
-40 - +70 Degree C


Physical Description
Button
Reset Button

LED Indicators
System Indicator

Mounting
Yes

Mount Options
Desk, Wall, Ceiling, Junction Box.

Dimensions
160 x 86 x 38mm (without packaging)

Weight (gm)
320 gm


Warranty
Warranty Details
1 Year (Without Adapter)


Additional Info
Others
Bluetooth Version: Bluetooth 5.0, 11ax indoor, 2+2 dual bands, smart antenna, USB, BLE. GE/PoE_IN - RJ45: 10/100/1000M auto-sensing Ethernet electrical port that connects to the wired Ethernet and supports PoE input. GE - RJ45: Ethernet electrical port that supports 10/100/1000M auto-sensing and connects to the wired Ethernet. USB: Connects to an IoT terminal to implement IoT applications - IoT module. Power supply mode; DC adapter/PoE. Long-term operating altitude [m(ft.)]: -60 m to +5000 m (-196.85 ft to +16404.20 ft). Atmospheric pressure [kPa]: 53kPa - 106kPa ETSI 300 019-2-3. Radio number: 2. MIMO spatial streams: Radio 0 (2.4 GHz): 2x2. Radio 1 (5 GHz): 2x2.


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
