Huawei eKitEngine AP761 Wireless Dual Band Wi-Fi 6 Outdoor Access Point

Item: Huawei eKitEngine AP761 Wireless Dual Band Wi-Fi 6 Outdoor Access Point
Rating: 5
Author: Verified Buyer

Product Id: 29.02.487.47

Coming Soon

Quick Overview

Network Standards - IEEE 802.11a/b/g/n/ac/ac
Data Transfer Rates - Unmentioned
Band - Dual
Interface(s) - 1 x 10M/100M/GE electrical, 1 x SFP optical port
Antenna (Type & Qty) - 2 x Internal
Color - White

Payment Method Shipping & Charge Order Procedure

Brand

Huawei

Model

Huawei eKitEngine AP761

Network Standards

IEEE 802.11a/b/g/n/ac/ac

Data Transfer Rates

Unmentioned

Band

Dual

Interface(s)

1 x 10M/100M/GE electrical, 1 x SFP optical port

Number of WAN Port

Unmentioned

Number of LAN Port

Unmentioned

Bluetooth

Yes

Antenna (Type & Qty)

2 x Internal

MU-MIMO Support

Yes

Multi-User MIMO

Yes

Power Method

PoE power supply: in compliance with IEEE 802.3at/af

Max. Power Consumption

17.7W

Outdoor Use

Yes

Mounting

Unmentioned

Color

White

Dimensions

69 x 200 x 200mm

Weight (gm)

1910gm

Warranty

3 Year (Without Adapter)

General

Brand

Huawei

Model

Huawei eKitEngine AP761

Hardware

Network Standards

IEEE 802.11a/b/g/n/ac/ac

Data Transfer Rates

Unmentioned

Interface

Interface(s)

1 x 10M/100M/GE electrical, 1 x SFP optical port

Number of WAN Port

Unmentioned

Number of LAN Port

Unmentioned

Wireless

Band

Dual

Frequency

2.4 GHz, 5 GHz

Bluetooth

Yes

Antenna (Type & Qty)

2 x Internal

Antenna Gain

2.4 GHz: 10 dBi, 5 GHz: 11 dBi

Antenna Placement

Built-in directional antennas

MU-MIMO Support

Yes

Multi-User MIMO

Yes

Management

SSID Numbers

<=16

Web-Based Management

NMS, and login through HTTP or HTTPS

Performance

Waterproof Level/Grade

IP68

IP Rating

IP68

OFDM/OFDMA

Yes

Technical Info

Outdoor Use

Yes

DHCP

Yes

Electrical

Power Method

PoE power supply: in compliance with IEEE 802.3at/af

Max. Power Consumption

17.7W

Environmental

Operating Temperature

-40 Degree C to +65 Degree C

Operating Humidity

0%–100%

Storing/Storage Temperature

-40 Degree C to +85 Degree C

Physical Description

LED Indicators

Indicate the power-on, startup, running, alarm, and fault states of the system

Mounting

Unmentioned

Dimensions

69 x 200 x 200mm

Color

White

Weight (gm)

1910gm

Warranty

3 Year (Without Adapter)

Additional Info

Others

Altitude -60 m to +5000 m, Atmospheric pressure 53 kPa to 106 kPa, Maximum number of STAs <= 1024 (512/radio), Maximum transmit power 2.4 GHz: 28 dBm (combined power), 5 GHz: 27 dBm (combined power), Power adjustment increment 1 dBm.

Specialty

Fat/Fit AP mode: WLAN features: Compliance with IEEE 802.11ax and compatibility with IEEE 802.11a/b/g/n/ac/ac Wave 2 Maximum ratio combining (MRC) Space time block code (STBC) Cyclic delay diversity (CDD)/Cyclic shift diversity (CSD) Beamforming Multi-user multiple-input multiple-output (MU-MIMO) Orthogonal frequency division multiple access (OFDMA) Compliance with 1024-QAM and compatibility with 256-QAM/64-QAM/16- QAM/8QAM/QPSK/BPSK Target wake time (TWT) Low-density parity-check (LDPC) Frame aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx) 802.11 dynamic frequency selection (DFS) Short GI in 20 MHz, 40 MHz, and 80 MHz modes Priority mapping and scheduling that are compliant with Wi-Fi multimedia (WMM) to implement priority-based data processing and forwarding; automatic and manual rate adjustment (the rate is adjusted automatically by default). Signal sustain technology (SST) Unscheduled automatic power save delivery (U-APSD) Control and provisioning of wireless access points (CAPWAP) in Fit AP mode Extended service set (ESS) in Fit AP mode Advanced cellular coexistence (ACC), minimizing the impact of interference from cellular networks Multi-user CAC 802.11k and 802.11v smart roaming 802.11r fast roaming (<= 50 ms). Network features: Compliance with IEEE 802.3ab Auto-negotiation of the rate and duplex mode and automatic switchover between the Media Dependent Interface (MDI) and Media Dependent Interface Crossover (MDI-X) Compliance with IEEE 802.1Q. VLAN assignment by SSID VLAN trunk on uplink Ethernet ports Management channel of the AP's uplink port in tagged or untagged mode DHCP client, obtaining IP addresses through DHCP Application identification and QoS classification on the AP in local forwarding (direct forwarding) mode for better voice quality (identifiable common applications in the industry: Skype, QQ, and WeChat) STA isolation in the same VLAN IPv4/IPv6 access control list (ACL) Link layer discovery protocol (LLDP) Uninterrupted service forwarding upon CAPWAP tunnel disconnection in Fit AP mode Unified authentication on the WAC in Fit AP mode WAC dual-link backup in Fit AP mode. QoS features: Priority mapping and scheduling that are compliant with Wi-Fi multimedia (WMM) to implement priority-based data processing and forwarding WMM parameter management for each radio WMM power saving Priority mapping for uplink packets; flow-based mapping for downlink packets Queue mapping and scheduling User-based bandwidth limiting Adaptive bandwidth management (automatic bandwidth adjustment based on the user quantity and radio environment) for user experience improvement Airtime scheduling Air interface HQoS scheduling Intelligent multimedia scheduling algorithm. Security features: Open system authentication WEP authentication/encryption using a 64-bit, 128-bit, 152-bit, or 192-bit encryption key WPA2-PSK authentication and encryption (WPA2-Personal) WPA2-802.1X authentication and encryption (WPA2-Enterprise) WPA3-SAE authentication and encryption (WPA3-Personal) WPA3-802.1X authentication and encryption (WPA3-Personal) WPA-WPA2 hybrid authentication WPA2-WPA3 hybrid authentication WPA2-PPSK authentication and encryption in Fit AP mode WAPI authentication and encryption WIDS/WIPS, including rogue device detection and containment, attack detection and dynamic blacklist, and STA/AP blacklist and whitelist. 802.1X authentication, MAC address authentication, Portal authentication, etc. DHCP snooping Dynamic ARP inspection (DAI) IP Source Guard (IPSG) 802.11w Protected Management Frames (PMF) IPsec/DTLS encryption. Maintenance features: Unified management and maintenance on the WAC in Fit AP mode Automatic login, automatic configuration loading, and plug-and-play (PnP) in Fit AP mode Automatic batch upgrade in Fit AP mode Telnet STelnet using SSHv2 SFTP using SSHv2 Remote wireless O&M through Bluetooth console ports Web system-based AP management and login through HTTP or HTTPS in Fat AP mode Real-time configuration monitoring and fast fault locating using the NMS SNMPv1/v2/v3 in Fat AP mode System status alarm Network Time Protocol (NTP) in Fat AP mode. Cloud-based management mode: WLAN features: Compliance with IEEE 802.11a/b/g/n/ac/ac Wave 2/ax Maximum ratio combining (MRC) Space time block code (STBC) Cyclic delay diversity (CDD)/Cyclic shift diversity (CSD) Beamforming Multi-user multiple-input multiple-output (MU-MIMO), Orthogonal frequency division multiple access (OFDMA) Compliance with 1024-QAM and compatibility with 256-QAM/64-QAM/16- QAM/8QAM/QPSK/BPSK Target wake time (TWT) Low-density parity-check (LDPC) Frame aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx) 802.11 dynamic frequency selection (DFS) Short GI in 20 MHz, 40 MHz, and 80 MHz modes Priority mapping and scheduling that are compliant with Wi-Fi multimedia (WMM) to implement priority-based data processing and forwarding WLAN channel management and channel rate adjustment. Network features: Compliance with IEEE 802.3ab Auto-negotiation of the rate and duplex mode and automatic switchover between the Media Dependent Interface (MDI) and Media Dependent Interface Crossover (MDI-X) Compliance with IEEE 802.1Q VLAN assignment by SSID DHCP client, obtaining IP addresses through DHCP STA isolation in the same VLAN Access control list (ACL) Unified authentication on the cloud management platform NAT Telemetry in Fit AP mode, quickly collecting AP status and application experience parameters. QoS features: Priority mapping and scheduling that are compliant with Wi-Fi multimedia (WMM) to implement priority-based data processing and forwarding WMM parameter management for each radio WMM power saving Priority mapping for uplink packets; flow-based mapping for downlink packets Queue mapping and scheduling User-based bandwidth limiting Airtime scheduling Air interface HQoS scheduling. Security features: Open system authentication WEP authentication/encryption using a 64-bit, 128-bit, 152-bit or 192-bit encryption key WPA2-PSK authentication and encryption (WPA2-Personal) WPA2-802.1X authentication and encryption (WPA2-Enterprise) WPA3-SAE authentication and encryption (WPA3-Personal) WPA3-802.1X authentication and encryption (WPA3-Enterprise).

Details

Features of Huawei eKitEngine AP761 Access Point In Bangladesh

Brand - Huawei, Model - Huawei eKitEngine AP761, Warranty - 3 Year (Without Adapter), Additional: Warranty Info - 3 Year, Sales Rules - Rules are given on I-Note

What is the price of Huawei eKitEngine AP761 Access Point In Bangladesh?

The price of Huawei eKitEngine AP761 Access Point not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Huawei eKitEngine AP761 Access Point from our website or visit our showrooms nearby.
