N.B. Image may differ with actual product's layout, color, size & dimension. No claim will be accepted for image mismatch. Product data used in this website is based solely on its manufacturer provided information, authenticity and accuracy are their responsibility only.
1 x M.2 slot (Key M) type 2242/2280 supports PCIe 4.0 x4 mode
M.2/SSD Slot Gen
Up to Gen 4
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
Multi-GPU Support
No
PCI Express Slot
1 x PCIe 3.0 x16 slot, 1 x PCIe 3.0 x1 slot
Audio & Video
Audio Chipset
Realtek ALC897 Codec
Audio Channel
5.1
Network & Connectivity
LAN Chipset
Realtek RTL8111H
LAN Speed (Mbps)
10/100/1000Mbps
WiFi
Yes
WiFi Technology
Wi-Fi 5
Bluetooth
Yes
Ports
USB Port
4 x USB 2.0 Type-A, 2 x USB 3.2 Gen1 Type-A
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
3 x SATA
Thunderbolt
No
TPM Port
No
COM Port
Yes
Technical Info
Back-Connect Design
No
Cable Management
Front
Heatsink
No
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0 , 1 , 5, 10 (SATA)
RGB Support
No
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Compatibility
Supported Operating System
Windows 11/10
Compatible Products
Compatible with AM4 Socket AMD Ryzen 5000G/ 5000/ 4000/ 3000 Series Processors
Warranty
Warranty Details
3 Year Replacement
Additional Info
Feature
Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz, HDMI port supports up to 4K@30Hz,
Others
INTERNAL I/O: (1x 24-pin Power Connector(ATX_PWR) 1x 8-pin Power Connector(CPU_PWR) 1x CPU Fan 1x System Fan 1x M.2 slots (Key-M) 3x SATA 6Gb/s ports 1x 4-Pin SPEAKER 1x Front Audio 1x COM_A Port 1x 9-Pin DEBUG_CON 1x CLR CMOS)
Country Of Origin
China
Made in/ Assemble
China
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
Details
QUESTION & ANSWER
Customer Questions
Q:
RGB header ache cooler ar jonno
Asked By Shafiul
A:
প্রিয় গ্রাহক মডেলটিতে আরজিবি হেডার নেই ধন্যবাদ
Answered By Ryans Computers Ltd.
, 17 Oct 2025
Q:
My monitor has only VGA port and DVI port but no HDMI port Can I connect this motherboard
Asked By Nematullah
A:
Dear Customer, In that case, you can use the motherboard using these converters. https://www.ryans.com/ugreen-dvi-male-to-hdmi-female-black-converter--20124 https://www.ryans.com/category/converter-vga-converter?sort=D&attr=2135(a_s_i)5017(a_s_i)0(a_s_o)2137(a_s_i)5025(a_s_i)0(a_s_o)&osp=1&st=0 Thank You.
Answered By Ryans Computers Ltd.
, 09 Oct 2025
Q:
Dp port available?
Asked By Nahid
A:
Dear customer, yes, there is a DP port available,. thank you.
Answered By Ryans Computers Ltd.
, 15 Sep 2025
