MSI B550-A PRO DDR4 AMD AM4 Socket Motherboard

Item: MSI B550-A PRO DDR4 AMD AM4 Socket Motherboard
Rating: 5
Author: Verified Buyer

1 reviews

Product Id: 02.02.033.253

This item is discontinued.

Quick Overview

Form Factor - ATX
Chipset - AMD B550
Sockets Supported - AM4
Supported CPU - AMD Ryzen 3rd Generation Processors and New Generation AMD Ryzen processors
Generation - Not Applicable
Memory Slot - 4
Memory Max. - 128GB
Back-Connect Design - No
Body Color - Black

Payment Method Shipping & Charge Order Procedure

Brand

MSI

Model

MSI B550-A PRO

Chipset

AMD B550

Sockets Supported

AM4

Built-in Processor

Generation

Not Applicable

Back-Connect Design

Memory Type

DDR4

Memory Slot

Memory Max.

128GB

Optane Memory Support

Graphics

Integrated

Graphics Chipset

Integrated With Processor

M.2/SSD Expansion Slot

WiFi

Bluetooth

Form Factor

ATX

Supported Operating System

Windows 10

Body Color

Black

Warranty

3 year

General

Brand

MSI

Model

MSI B550-A PRO

Body Color

Black

CPU

Chipset Brand

AMD

Chipset

AMD B550

Sockets Supported

AM4

Built-in Processor

Supported CPU

AMD Ryzen 3rd Generation Processors and New Generation AMD Ryzen processors

Generation

Not Applicable

Memory Support

Memory Type

DDR4

Memory MHz

4400/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667/ 2400/ 2133/ 1866 MHz by JEDEC and A-XMP OC MODE

Memory Channel

Dual

Memory Slot

Memory Max.

128GB

Optane Memory Support

Storage

Storage Interface

6.0Gb/s

M.2/SSD Expansion Slot

M.2/SSD Expansion Slot Details

2 x M.2 (1 x M.2 (Supports PCIe 4.0/ 3.0 x4, Supports SATA 6Gb/s, Supports 2242/ 2260/ 2280/ 22110 storage devices), 1 x M.2 (Supports PCIe 3.0x4, Supports 2242/ 2260/ 2280 storage devices))

M.2/SSD Slot Gen

Up to Gen 4

Graphics

Integrated

Graphics Chipset

Integrated With Processor

Multi-GPU Support

2-Way AMD CrossFire

PCI Express Slot

1x PCIe 4.0/ 3.0 x16 slot (PCI_E1), 1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed, 2x PCIe 3.0 x1 slots

Audio & Video

Audio Chipset

Realtek ALC892

Audio Channel

7.1

Network & Connectivity

LAN Chipset

Realtek 8111H

LAN Speed (Mbps)

10/100/1000

WiFi

Bluetooth

Ports

USB Port

1 x USB 3.2 Gen 2 Type-C, 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 2 Type-A, 3 x USB3.2 Gen 1 Type-A, 6 x USB2.0

VGA Port

DVI Port

HDMI Port

DisplayPort (DP)

IDE Port

SATA Port

6 x SATA

Thunderbolt

TPM Port

Yes

COM Port

Technical Info

Back-Connect Design

Cable Management

Front

DirectX Support

Heatsink

Yes

FireWire

CrossFire Support

Yes

Sli Support

Raid Support

0, 1, 10

RGB Support

RGB

RGB Sync

Mystic Light

RGB Connector

1 x 4-pin RGB LED connector

Approx. Power Consumption

70W

Form Factor

ATX

Compatibility

Supported Operating System

Windows 10

Warranty

3 year

Additional Info

Feature

Lightning Fast Experience, PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 Gen 2, Premium Thermal Solution, Extended Heatsink Design with additional choke thermal pad and 7W/mK pad, and M.2 Shield Frozr are built for high performance system and non-stop works, Powerful Design, Core Boost, Digital PWM IC, 2oz Thickened Copper PCB, Creator Genie, DDR4 Boost, Audio Boost, Multi-GPU With Steel armor PCI-E slots. Supports 2-Way AMD Crossfire

Others

1 x DisplayPort, 1x 4-pin CPU fan connector, 1x 4-pin water-pump fan connector, 6x 4-pin system fan connectors, 1x Front panel audio connector, 2x System panel connectors, 1x Chassis Intrusion connector, 1x 4-pin RGB LED connector, 2x 3-pin RAINBOW LED connectors, 1xTPM module connector, 1x Clear CMOS jumper, HD Audio Connectors, 9 mounting holes

Country Of Origin

Taiwan

Made in/ Assemble

China

Details

Features of MSI B550-A PRO Motherboard In Bangladesh

MSI B550-A PRO

B550-A PRO

Powered by AMD Ryzen AM4 processors, the MSI B550-A PRO combines stable functionality and high-quality assembly to solve professional workflows. Extended Heatsink Design and Core boost keep critical components operating reliably. PCIe 4.0 slots and M.2 with Shield Frozr provides the latest in device connectivity.

Support for 3rd Gen AMD Ryzen processors and future AMD Ryzen processors with BIOS update
Supports dual channel DDR4 memory up to 128 GB (4400 MHz)
Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 GEN 2
Core Boost technology combines optimized power circuit layouts and digital power regulation which allows for precise and steady current delivery to the CPU
AUDIO BOOST rewards your ears with studio grade sound quality for immersive gaming experiences
Premium Thermal Solution: Heatsink thermal pad rated for 7W/mk and PCB with 2oz thickened copper
Flash BIOS Button lets users flash the BIOS even without a CPU or memory

LIGHTNING GEN 4 SOLUTION

Strike fast with MSI Lightning Gen 4 PCI-E. Attach ultra fast PCI-E 4.0 devices and enjoy up to 64GB/s unidirectional transfer bandwidth.

EXTENDED HEATSINK

An all-metal extended heatsink enlarges the heat dissipation surface allowing the CPU power system to reliably drive even high-end processors.

CORE BOOST

Core Boost combines a reserved zone of optimized circuits and premium power delivery components to create a highly efficient power system capable of precise current output to the CPU.

PCB WITH 2OZ THICKENED COPPER

An enhanced PCB material design with 2oz thickened copper increases conductivity, improving heat dissipation and high-performance reliability.

EASY TO ARRANGE YOUR CABLES

Tuck away SATA and USB cables neatly with MSI Atypical PCB edge.

FORTIFY WITH PCI-E STEEL ARMOR

MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.

What is the price of MSI B550-A PRO Motherboard In Bangladesh?

The price of MSI B550-A PRO Motherboard not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy MSI B550-A PRO Motherboard from our website or visit our showrooms nearby.
