Supported CPU - AMD Ryzen 5000 Series/ 2nd and 3rd Gen AMD Ryzen/ Ryzen 4000 G-Series / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors
AMD Ryzen 5000 Series/ 2nd and 3rd Gen AMD Ryzen/ Ryzen 4000 G-Series / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors
Generation
Not Applicable
Memory Support
Memory Type
DDR4
Memory MHz
3rd Gen (1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 Mhz by A-XMP OC MODE), 1st and 2nd Gen (1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 Mhz by A-XMP OC MODE)
Memory Channel
Dual
Memory Slot
4
Memory Max.
128GB
Optane Memory Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
2
M.2/SSD Expansion Slot Details
2 x M.2 slots (PCIe 4.0 x4 or PCIe 3.0 x4 and 2242/2260/2280 storage devices), (PCIe 4.0 x4 or 3.0 x4 and SATA 6Gb/s 2242/ 2260/ 2280/ 22110 storage devices)
Intel Wi-Fi 6 AX200, Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
Bluetooth
Bluetooth 5.1
Ports
USB Port
1 x USB 3.2 Gen 2 Type-C, 3 x USB 3.2 Gen 2 Type-A, 6 x USB 3.2 Gen 1 Type-A, 6 x USB 2.0
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
No
IDE Port
No
SATA Port
6 x SATA
Thunderbolt
No
TPM Port
Yes
Technical Info
Back-Connect Design
No
Cable Management
Front
DirectX Support
12
Heatsink
Yes
CrossFire Support
Yes
Sli Support
No
Raid Support
0, 1, 10
RGB Support
RGB
RGB Sync
Mystic light
RGB Connector
1x 4-pin RGB LED connector
Approx. Power Consumption
90W
Form Factor
ATX
Compatibility
Supported Operating System
Windows 10
Warranty
Warranty
3 year
Additional Info
Feature
Inspired by the curve and shape of supercars, offers colorful customization with MSI Mystic Light RGB and Ambient Link, tuned for better performance by Core boost, DDR4 Boost, M.2 Shield Frozr, Wi-Fi 6, Frozr Heatsink Design, Lightning Gen4, Pre-installed I/O Shielding, Lightning Fast Game experience, PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr, StoreMI, AMD Turbo USB 3.2 GEN2, MYSTIC LIGHT, 16.8 million colors / 29 effects controlled in one click. MYSTIC LIGHT EXTENSION supports both RGB and RAINBOW LED strip, Frozr Heatsink Design, Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers, Set Core Power Free, Extended Heatsink Design, Core Boost, Digital PWM IC, 8+4 pin CPU power connector, Game Boost, DDR4 Boost, AUDIO BOOST 4 with NAHIMIC 3
Others
2 x M.2 slots, 1x 4-pin CPU fan connector, 1x 4-pin water-pump connector, 4x 4-pin system fan connectors, 1x Front panel audio connector, 2x System panel connectors, 1x TPM module connector, 1x Clear CMOS jumper, 1x Chassis Intrusion connector, 1x 4-pin RGB LED connector, 2x 3-pin RAINBOW LED connectors, 1x 3-pin CORSAIR connector, 1x 2-pin LED Demo Connect, 4x EZ Debug LEDs, Wireless / Bluetooth, Audio Connectors, Flash BIOS Button, 9 mounting holes, WIFI & BLUETOOTH: Intel Wi-Fi 6 AX200 - The Wireless module is pre-install in the M2_WIFI1 (Key-E) slot, Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps, Supports Bluetooth 5
