NZXT H5 Flow Mesh Mid Tower White ATX Gaming Desktop Casing #CC-H52FW-01

Item: NZXT H5 Flow Mesh Mid Tower White ATX Gaming Desktop Casing #CC-H52FW-01
Rating: 5
Author: Verified Buyer

6 reviews

Product Id: 07.02.681.97

Out Of Stock

See similar model

Quick Overview

Case Type - Mid Tower
Optical Drive Bay - No
Cooling Fan (Built-In) - 2
Lighting Fan - No
Power Supply (Built-In) - No
Back-Connect Supported - No
Color - White

Color variations

White
Tk 0

Payment Method Shipping & Charge Order Procedure

Brand

NZXT

Model

NZXT H5 Flow

Series

Flow

Case Type

Mid Tower

Supported Motherboard Type (Max.)

Up to E-ATX

Front/Top USB port

1 x USB 3.2 Type-A, 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps)

Front/Top Audio Port

1 x Headset audio Jack

Expansion Slots

Optical Drive Bay

Cooling Fan (Built-In)

Additional Fan Slot

Power Supply (Built-In)

Power Supply Mounted

Bottom

Back-Connect Supported

Transparent Side Window

Yes

Number of Buttons

Dust Cover

Top, front, and side panels

Color

White

Dimensions

465 x 225 x 430mm

Weight (Kg)

7.28 kg

Warranty Details

No warranty

General

Brand

NZXT

Model

NZXT H5 Flow

Series

Flow

Case Type

Mid Tower

Part No

CC-H52FW-01

Technical Info

Supported Motherboard Type

E-ATX, ATX, Micro-ATX, Mini-ITX

Supported LED Strip

Fan / Light Controller

Back-Connect Supported

Graphics-Card Length

410mm

Supported CPU Cooler

Air Cooler or Liquid Cooler

CPU Cooler Height

170mm

PSU Length

200mm

Cable Management Depth

Up to 28.7mm

Ports & Slots

Front/Top USB port

1 x USB 3.2 Type-A, 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps)

Front/Top Audio Port

1 x Headset audio Jack

3.5 Inch Drive Bay

2.5 Inch Drive Bay

Expansion Slots

Optical Drive Bay

Memory Card Slot

Fan & Radiator Details

Cooling Fan (Built-In)

Additional Fan Slot

Pre-Installed Fan Size

120mm

Supported Fan Size

Front: 3 x 120mm/ 2 x 140mm, Top: 2 x 120 mm/ 2 x 140 mm, Bottom: 2 x 120 mm, Rear: 1 x 120 mm

Lighting Fan

Radiator Support Front/Top/Rear

Top : Up to 240mm (280 mm with low-profile memory

Radiator Support Max.

Up to 240mm

Power

Power Supply (Built-In)

Power Supply Mounted

Bottom

Approx. Power Consumption

10W

Physical Description

Transparent Side Window

Yes

Case Windowed

Tempered Glass Side Window

Buttons

Power

Number of Buttons

Material

SGCC Steel

Dust Cover

Top, front, and side panels

Color

White

Dimensions

465 x 225 x 430mm

Weight (Kg)

7.28 kg

Handle

Warranty

Warranty Details

No warranty

Additional Info

Others

Ultra-Clear Tempered Glass (White), Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness:Up to 55 mm, Fan Specs: Model:F120Q (Case Version), Speed: 1,350 +/- 150 RPM, Airflow: 60.2 CFM, Static: 1.05 mm-H2O, Noise: 24.1 dBA, Fan Connector: 3-pin, Inside the Box: H5 Flow x 1, F120Q (CV) x 2, Installation accessories x 1, User guide x 1

Specialty

Supports up to a 360mm radiator in front and a 240mm radiator up top for powerful liquid cooling potential. Ultra-fine mesh on the top, front, and side panels creates maximum airflow and filters dust. Equipped with two 120mm Quiet Airflow fans (CV) one in front, one in rear for solid out-of-the-box performance. Effortlessly route and conceal cables using the wide channels, hooks, and straps.

Country Of Origin

USA

Made in/ Assemble

China

Details

Features of NZXT H5 Flow Casing In Bangladesh

NZXT H5 Flow Mid Tower White ATX Gaming Desktop Casing

The NZXT H5 Flow is a sleek and modern mid-tower casing designed specifically for gamers and PC builders who prioritize airflow and aesthetics. This case not only enhances the visual appeal of your setup but also ensures optimal cooling performance. The H5 Flow is part of NZXT's Flow series, which emphasizes high airflow capabilities, making it an excellent choice for high-performance builds.

Key Specifications

Model: NZXT H5 Flow RGB
Case Type: Mid Tower
Supported Motherboard Type: Up to E-ATX
Dimensions: 465 x 225 x 430 mm
Front/Top Audio Port: 1 x Headset audio jack
Expansion Slots: 7
Cooling Fan (Built-In): 4
Additional Fan Slots: 4
Transparent Side Window: Yes
Dust Cover: Top, front, and side panels

What Makes It Special?

The NZXT H5 Flow stands out due to several key features:

Enhanced Airflow Design: The case features a perforated front panel and mesh top, allowing for superior airflow, which is crucial for maintaining optimal temperatures during intense gaming sessions. This design helps to keep components cool, especially when using high-performance GPUs.
Versatile Cooling Options: With support for up to four additional fans and the ability to accommodate large radiators (up to 360mm in the front and 240mm on top), users can customize their cooling setup according to their needs. The inclusion of built-in RGB fans adds both functionality and style.
Spacious Interior: The H5 Flow provides ample space for cable management and component installation. It supports a variety of motherboard sizes, including E-ATX, making it suitable for a wide range of builds.
User-Friendly Features: Tool-less access to the front and side panels simplifies upgrades and maintenance. The intuitive cable management system with wide channels helps keep the interior tidy.

Who Should Buy It?

The NZXT H5 Flow is ideal for:

Gamers looking for a stylish yet functional case that supports high-performance components while maintaining excellent cooling.
PC Builders who appreciate aesthetics without compromising on airflow and thermal performance. Its clean white design fits well in modern setups.
Enthusiasts who plan to overclock their CPUs or GPUs, as the enhanced cooling options will help manage heat effectively.

What is the price of NZXT H5 Flow Casing In Bangladesh?

The price of NZXT H5 Flow Casing not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy NZXT H5 Flow Casing from our website or visit our showrooms nearby.
