Ruijie RG-EST100-E 2.4GHz 500M Wireless Bridge

Item: Ruijie RG-EST100-E 2.4GHz 500M Wireless Bridge
Rating: 5
Author: Verified Buyer

Product Id: 29.02.925.90

Coming Soon

Quick Overview

Network Standards - IEEE 802.11b/g/n: 2.400 GHz to 2.483 GHz
Data Transfer Rates - 300 Mbps
Band - Single
Interface(s) - 2 x Number of fixed LAN, 2 x Number of 10/100BASE-T
Antenna (Type & Qty) - 2 x Internal
Color - White

Payment Method Shipping & Charge Order Procedure

Brand

Ruijie

Model

Ruijie RG-EST100-E

Network Standards

IEEE 802.11b/g/n: 2.400 GHz to 2.483 GHz

Data Transfer Rates

300 Mbps

Band

Single

Interface(s)

2 x Number of fixed LAN, 2 x Number of 10/100BASE-T

Number of WAN Port

Unmentioned

Number of LAN Port

Bluetooth

Antenna (Type & Qty)

2 x Internal

Memory

64MB

Storage (MB/GB/TB)

8MB

Protection

Surge protection

Max. Power Consumption

Outdoor Use

Yes

Mounting

Yes

Color

White

Dimensions

68.7 x 42 x 165.5mm

Weight (gm)

140 gm

Warranty

3 Year (Without Adapter)

General

Brand

Ruijie

Model

Ruijie RG-EST100-E

Hardware

Network Standards

IEEE 802.11b/g/n: 2.400 GHz to 2.483 GHz

Data Transfer Rates

300 Mbps

Processor

CPU Single-core processor, 575/580 MHz clock frequency

Memory

64MB

Memory Type

DDR2

Storage (MB/GB/TB)

8MB

Interface

Interface(s)

2 x Number of fixed LAN, 2 x Number of 10/100BASE-T

Number of WAN Port

Unmentioned

Number of LAN Port

Wireless

Band

Single

Frequency

2.4 GHz

Bluetooth

Antenna (Type & Qty)

2 x Internal

Antenna Gain

8 dBi

Performance

Protection

Surge protection

IP Rating

IP55

Technical Info

Outdoor Use

Yes

DHCP

Yes

MTBF

MTBF 400,000 hours

Electrical

DC Input Power

12 V, 1 A

Max. Power Consumption

Passive PoE Power Supply

12 V DC 1 A

Environmental

Operating Temperature

-30 Degree C to +60 Degree C

Operating Humidity

5% RH to 95% RH (non-condensing)

Storing/Storage Temperature

-40 Degree C to +70 Degree C

Storing/Storage Humidity

5% RH to 95% RH (non-condensing)

Physical Description

Button

1 x Reset button

Mounting

Yes

Mount Options

Wall/Pole

Dimensions

68.7 x 42 x 165.5mm

Color

White

Weight (gm)

140 gm

Warranty

3 Year (Without Adapter)

Additional Info

Others

2 Built-in directional antenna, horizontal/vertical: 70 Degree, Operating altitude: -500 m to +5,000 m, Storage altitude: -500 m to +5,000 m, Natural cooling, Standard test: contact discharge=8 kV, air discharge=15 kV, Class B, Service port: -/+6 kV for common mode, Power connector: ±4 kV for common mode and ±2 kV differential mode, 1 x system status LED, 2 x Ethernet port LEDs, 3 x signal status LEDs, Applicable Scenarios CCTV, Rated input voltage: 100 V AC to 240 V AC, 50 Hz to 60 Hz, Outer Diameter: 5.50 mm -/+0.05 mm (0.22 in. -/+0.002 in.), Inner Diameter: 2.10 mm -/+ 0.05 mm, Radio design Single-radio, 2 spatial streams, Radio 1: 2.4 GHz, 2 spatial streams: 2 x 2, MIMO, Wi-Fi 4 (IEEE 802.11n) standard, compatible with IEEE 802.11b/g standards, 2.4 GHz Wi-Fi Wi-Fi 4 (IEEE 802.11b/g/n), 2.4 GHz channel width Auto/20/40 MHz, Transmission rate Maximum wireless data rate: 300 Mbps Radio 1: 2.4 GHz, 300 Mbps, Maximum transmit power (2.4 GHz) Combined power: 23 dBm (single stream power: 20 dBm). Receive sensitivity 802.11b: -91 dBm (1 Mbps), -88 dBm (5 Mbps), -85 dBm (11 Mbps) 802.11g: -89 dBm (6 Mbps), -80 dBm (24 Mbps), -76 dBm (36 Mbps), -71 dBm (54 Mbps) 802.11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, - 65 dBm@MCS15, Modulation 802.11b: BPSK, QPSK, CCK 802.11g/n: BPSK, QPSK, 16-QAM, 64-QAM, Highest QAM order 64, Interface rate 10/100 Mbps auto-negotiation, Maximum effective distance of onetouch pairing 20 m, Maximum bridge distance 0.5 km (0.31 miles), Bridge performance 60 Mbps/100 m (328.08 ft.) (HT20) 30 Mbps/500 m (0.31 miles) (HT20), RSSI -58 dBm/100 m (328.08 ft.) -68 dBm/500 m (0.31 miles), Recommended number of connected cameras (3 Mbps) 10/100 m (328.08 ft.) 5/500 m (0.31 miles), Recommended number of connected cameras (4–5 Mbps) 6/100 m (328.08 ft.) 3/500 m (0.31 miles), Recommended number of connected cameras (6–7 Mbps) 3/100 m (328.08 ft.) 1/500 m (0.31 miles).

Specialty

IPv4 ping, IPv4 traceroute, DHCP server, DHCP client, VLAN, Broadcast storm control, SON, Network-wide management SSID configuration, Ruijie Cloud management, Restarting devices through Ruijie, Reyee App Fault diagnosis, Restart cause prompt, eWeb login with the username and password, Local upgrade, Configuration backup, System language Chinese (Simplified), English System time settings, WLAN, BaseStation/CPE mode switching, Bridge SSID hiding, WPA2-PSK encryption, Recommended channel, Bridge speed test, Configuring a security key for network-wide bridges, Configuring a security key for a single bridge group, Configuring a security key for a single bridge, Bridge SSID, channel, and power configuration, Real-time signal strength, Optimal signal strength.

Country Of Origin

China

Made in/ Assemble

China

Details

Features of Ruijie RG-EST100-E Access Point In Bangladesh

What is the price of Ruijie RG-EST100-E Access Point In Bangladesh?

The price of Ruijie RG-EST100-E Access Point not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Ruijie RG-EST100-E Access Point from our website or visit our showrooms nearby.
