N.B. Image may differ with actual product's layout, color, size & dimension. No claim will be accepted for image mismatch.
Thermaltake Smart BM2 750W Semi Modular 80 Plus Bronze Certified Power Supply #PS-SPD-0750MNFABE-1
Product Id: 55.01.269.137
Brand
Thermaltake
Quick Overview
- PSU Category - Semi Modular
- Type - ATX 12V v2.4
- Maximum Power - 750 Watt
- Fan Speed - 2300 RPM +- 10%
- Efficiency - 85% Efficiency
- Efficiency Rating - 80 Plus Bronze
- Protection - OVP ,OPP, OCP, OTP
Brand
Thermaltake
Model
Thermaltake Smart BM2
Series
Smart Series
PSU Category
Semi Modular
Type
ATX 12V v2.4
Maximum Power
750 Watt
Fan Size
140mm
Lighting Effect
No
Efficiency Rating
80 Plus Bronze
MTBF
100,000 hrs
Form Factor
ATX
Color
Black
Warranty Details
5 Year
N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
Details
Features of Thermaltake Smart BM2 Power Supply In Bangladesh
Smart BM2 750W
Smart BM2 750W - TT Premium Edition
Built to deliver 80 PLUS Bronze efficiency with up to 85% of it, the Smart BM2 series is available in 450W/550W/650W/750W. Constructed with a 140mm rifle bearing fan, Japanese main capacitors and other premium components, the Smart BM2 750W delivers a continuous and stable power output at 40℃, allowing near silent operation and reliable performance. With an ample 5-year warranty, the Smart BM2 750W is able to satisfy the market, where value-oriented users are looking for a new power supply with all the latest features.
Ultra Quiet 140mm Rifle Bearing Fan
The Smart BM2 750W adopts s 140mm silent Rifle Bearing fan with intelligent preset RPM control guarantying cooling performance and silent operation.
Semi Modular Flat Cable Design
Soft flat black cables come with sleeve cabling, designed to make cable installation an easy task while fully powering the system at optimal voltages.
Main Power Connector (24pin)
24pin Main connector (600mm) x 1
ATX 12V (4+4pin)
ATX 12V 8pin connector (600mm) x 1
4+4pin connector (150mm) x 1
SATA (5pin)
SATA connectors (500mm + 150mm + 150mm) x 3
SATA connectors (500mm + 150mm + 150mm) x 3
SATA connectors (500mm + 150mm + 150mm) x 3
PCI-E (6+2pin)
PCI-E 6+2pin connectors (500mm + 150mm) x 2
PCI-E 6+2pin connectors (500mm + 150mm) x 2
Peripheral
Peripheral connectors (500mm + 150mm + 150mm+ 150mm) x 4
Floppy Adapter
Peripheral to FDD adapter cable (150mm) x 1
Japanese Main Capacitor
High quality Japanese main capacitor greatly improves the power supplies durability and ensures the Smart BM2 750W to have highest stability and reliability.
DC to DC for Stable Output Voltage
With DC to DC design, the unit can optimize maximum energy harvest for your system. Such as efficiently change voltage level for 12V, 5V, and 3V and to match the loads to your power supply.
Brand - Thermaltake, Model - Thermaltake Smart BM2, Series - Smart Series, PSU Category - Semi Modular, Type - ATX 12V v2.4, Min. Power (Approx.) - 635W, Maximum Power - 750 Watt, Input Voltage - 100V - 240V, Input Frequency Range - 47Hz - 63Hz, Input Current - 10A, Fan Size - 140mm, Fan Bearing - Rifle Bearing, Fan Speed - 2300 RPM +- 10%, Efficiency - 85% Efficiency, 80 Plus/Efficiency Rating - 80 Plus Bronze, Protection - OVP, OCP, Over Voltage Protection (OVP) - Yes, Over Power Protection (OPP) - No, Over Current Protection (OCP) - Yes, Over Temperature Protection (OTP) - No, Short Circuit Protection (SCP) - No, Under Voltage Protection (UVP) - No, ATX Main Connectors - 1, EPS Connectors - 2, PCIe Connectors - 2, SATA Power Connectors - 6, 4-Pin Peripheral Connectors - 4, Floppy Connectors - 1, PFC (Power Factor Correction) - Active PFC, Peak Output Capacity - 900W, Power Good Signal - 100-500 msec, Hold Up Time - >12msec at 80% of full load, Operating Temperature - 0 degree C - +40 degree C, Operating Humidity - 20% - 90% non-condensing, Storage Temperature - -20 degree C - +70 degree C, Storage Humidity - 5% - 95% non-condensing, MTBF - 100,000 hrs, Form Factor - ATX, Dimension (W/H/D) - 150 x 86 x 160mm, Color - Black, Regulatory / Safety Approval - cTUVus, TUV, CE, FCC, S-mark, EAC, BSMI, C-TICK, CCC, Others - Power supply type: ATX 12V v2.4 and EPS v2.92, HOLD UP TIME: > 12msec at 80% of full load at 230Vac input, EFFICIENCY: Meet 80 PLUS Bronze at 115Vac input., Specialty - Ultra Quiet 140mm Rifle Bearing Fan, Semi Modular Flat Cable Design, Japanese Main Capacitor, High quality Japanese main capacitor greatly improves the power supplies durability and ensures the Smart BM2 Series to have highest stability and reliability, DC to DC for Stable Output Voltage, High Amperage Single +12V Rail, Part No - PS-SPD-0750MNFABE-1, Warranty - 5 Year, Country of Origin - Taiwan, Made in/ Assemble - China
What is the price of Thermaltake Smart BM2 Power Supply In Bangladesh?
The price of Thermaltake Smart BM2 Power Supply not mentioned for stock unavailability. The price may vary due to your customization and product availability. You can buy Thermaltake Smart BM2 Power Supply from our website or visit our showrooms nearby.
