N.B. Image may differ with actual product's layout, color, size & dimension. No claim will be accepted for image mismatch. Product data used in this website is based solely on its manufacturer provided information, authenticity and accuracy are their responsibility only.
1 x RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
POE Interface
No
Auxiliary Interface
Number HDD Interface (SATA)
1 SATA
Max HDD Support (GB,TB)
10TB
Max. Storage Support
10TB
eSATA
No
USB Port
2 x USB 2.0
Technical Info
Display Split
1/4
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
60 Mbps
Interoperability
ONVIF, CGI
Compatibility
Smart Phone Supported
iOS, Android
Power Info
Power Supply
DC 12V/1.5A
Approx. Power Consumption
4.25 W (without disk)
Physical Description
Color
Black
Dimensions
246.2 x 148.2 x 45 mm
Weight (Kg)
0.59 kg
Package Includes
VIGI Network Video Recorder, Power Adapter, HDD Screws, Mouse, Rubber Feet, Quick Installation Guide
Warranty
Warranty
2 year
Additional Info
Feature
General Alarm: Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame, Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm, Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off, 4-Channel Live View and 4K HDMI Video Output, 2-ch @ 8MP/ 4-ch @ 4MP Decoding Capability, 4-Channel Synchronous Playback, 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth, 1 SATA Interface, H.265+ Compression Technology, HDMI and VGA Simultaneous Output, Remote Monitoring
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
Details
QUESTION & ANSWER
Customer Questions
Q:
Can we connect TP Link Tapo C545D dual lens camera with this VIGI NVR1004H 4 Channel NVR ?
Asked By Mamun
A:
Dear Customer, Yes, you can connect the TP-Link Tapo C545D dual-lens camera to the TP-Link VIGI NVR1004H 4-Channel NVR, but only through the ONVIF protocol. Thank you.
Answered By Ryans Computers Ltd.
, 13 May 2026
