1 x RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
Auxiliary Interface
Number HDD Interface (SATA)
1 SATA
Max HDD Support (GB,TB)
16TB
Max. Storage Support
16TB
eSATA
No
USB Port
2 x USB 2.0
Technical Info
Display Split
1/4
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
60 Mbps
Interoperability
ONVIF, CGI
Compatibility
Smart Phone Supported
Android, iOS
Power Info
Power Supply
53.5V DC/1.31A
Approx. Power Consumption
4.25 W (without disk)
Physical Description
Color
Black
Dimensions
246.2 x 148.2 x 45mm
Package Includes
VIGI Network Video Recorder, Power Adapter, HDD Screws, Mouse, Quick Installation Guide
Warranty
Warranty Details
1 year
Additional Info
Feature
4K HDMI Video Output & 16MP Decoding Capacity, Simplified Deployment with PoE+, 4-Channel Simultaneous Playback, H.265+, ONVIF Ensures Compatibility, Plug & Play, 24/7 Continuous Recording, Remote Monitoring, Two-Way Audio, 80 Mbps Video Access Bandwidth, Record Mode: Manual Recording, Scheduling Recording, Motion Detection Recording, Playback Mode: Instant Playback, Regular Playback, Tag Playback, Event Playback, Backup Mode: Regular Backup, Video Clip Backup, Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off, General Alarm: Motion Detection, Video Tampering, Scene Change Detection, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Loitering Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Abnormal Sound Detection, Smart Frame, Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm
Others
Video Output Mode: HDMI/VGA Simultaneous Output, Web Browser: Chrome (57+), Firefox (52+), Edge (91+), Operating Temperature: -10 to 55 Degree C, Storage Temperature: -40 to 70 Degree C, Storage Humidity: 10%~90% RH Non-Condensing, Working Temperature: NVR: -10 to 55 Degree C, Power Adapter: 0 to 40 Degree C, Working Humidity: 10%~90% RH Non-Condensing, PoE: Standard: 802.3af/at, PoE Ports: Ports 1-4, PoE Budget: 53 W, Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
Country Of Origin
China
Made in/ Assemble
China
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
