Brand

Ubiquiti

Model

Ubiquiti UF-Loco-5

PON Interface

1 x SC/APC GPON

PON Port Connector Type

Unmentioned

PON Port Speed

2.488 Gbps Downstream, 1.244 Gbps Upstream

PON Port Interface Type

SC/APC

PON Port TX Power

1.5 to 5 dBm

Ethernet Interface

1 x 1000Mbps RJ45 LAN

Power Interface

24V Passive PoE (Pins +4, 5; -7, 8), Micro-USB: 5V, 1A

Network Management

Unmentioned

Management Function

In-Band Ethernet/PON

Power Supply

Dimension

76.5 x 76.5 x 26.4mm

Weight (Kg)

0.077Kg

Warranty

1 Year (Adapter No Warranty)

General

Brand

Ubiquiti

Model

Ubiquiti UF-Loco-5

PON Info

PON Type

GPON

PON Interface

1 x SC/APC GPON

PON Port Connector Type

Unmentioned

PON Port Speed

2.488 Gbps Downstream, 1.244 Gbps Upstream

PON Port Interface Type

SC/APC

PON Port Transmission Distance

20KM

PON Port Wavelength

Unmentioned

PON Port TX Power

1.5 to 5 dBm

PON Port Rx Sensitivity

-28 to -8dBm

Data Transmission PON Throughput

Downstream 2.488 Gbps; Upstream 1.244 Gbps

Technical Info

Ethernet Interface

1 x 1000Mbps RJ45 LAN

Data Transmission Ethernet

1000 Mbps

Power Interface

24V Passive PoE (Pins +4, 5; -7, 8), Micro-USB: 5V, 1A

Network Management

Unmentioned

Management Function

In-Band Ethernet/PON

Power Info

Power Supply

Approx. Power Consumption

3.5W

Operating Temperature

-10 to 45 degree C

Operating Humidity

10 to 90% Noncondensing

Working Temperature

-10 to 45 degree C

Storing/Storage Humidity

10 to 90% Noncondensing

Physical Description

Dimension

76.5 x 76.5 x 26.4mm

Weight (Kg)

0.077Kg

Warranty

1 Year (Adapter No Warranty)

Additional Info

Feature

Digital LED For Status Reporting, Wall Mountable(Indoor)

Specialty

High-Performance GPON CPE, LED diodes for easy diagnostics, Up to 2.4 Gbps Downstream and 1.2 Gbps Upstream, Supports up to 20 km GPON Links, Powerful Layer 2/3 Management Features, GPON WAN Port, RJ45 Gigabit LAN Port, SC/APC Fiber Connector.

Others

Supported Voltage Range 20V to 28V, Processor Specs: MIPS32, 240 MHz, Memory Information: 128 MB DDR3, Buttons: 1 x Reset, Certifications: CE, FCC, IC.

Made in/ Assemble

China

Details

Features of Ubiquiti UF-Loco-5 Optical Network Unit (ONU) In Bangladesh

Brand - Ubiquiti, Model - Ubiquiti UF-Loco-5, PON Type - GPON, PON Interface - 1 x SC/APC GPON, PON Port Connector Type - Unmentioned, PON Port Speed - 2.488 Gbps Downstream, 1.244 Gbps Upstream, PON Port Interface Type - SC/APC, PON Port Transmission Distance - 20KM, PON Port Wavelength - Unmentioned, PON Port TX Power - 1.5 to 5 dBm, PON Port Rx Sensitivity - -28 to -8dBm, Data Transmission PON Throughput - Downstream 2.488 Gbps; Upstream 1.244 Gbps, Ethernet Interface - 1 x 1000Mbps RJ45 LAN, Data Transmission Ethernet - 1000 Mbps, Power Interface - 24V Passive PoE (Pins +4, 5; -7, 8), Micro-USB: 5V, 1A, Network Management - Unmentioned, Management Function - In-Band Ethernet/PON, Power Supply - 5V, Approx. Power Consumption - 3.5W, Operating Temperature - -10 to 45 degree C, Operating Humidity - 10 to 90% Noncondensing, Working Temperature - -10 to 45 degree C, Storage Humidity - 10 to 90% Noncondensing, Dimension - 76.5 x 76.5 x 26.4mm, Weight (Kg) - 0.077Kg, Features - Digital LED For Status Reporting, Wall Mountable(Indoor), Specialty - High-Performance GPON CPE, LED diodes for easy diagnostics, Up to 2.4 Gbps Downstream and 1.2 Gbps Upstream, Supports up to 20 km GPON Links, Powerful Layer 2/3 Management Features, GPON WAN Port, RJ45 Gigabit LAN Port, SC/APC Fiber Connector., Others - Supported Voltage Range 20V to 28V, Processor Specs: MIPS32, 240 MHz, Memory Information: 128 MB DDR3, Buttons: 1 x Reset, Certifications: CE, FCC, IC., Warranty - 1 Year (Adapter No Warranty), Made in/ Assemble - China

What is the price of Ubiquiti UF-Loco-5 Optical Network Unit (ONU) In Bangladesh?

The price of Ubiquiti UF-Loco-5 Optical Network Unit (ONU) starts from 20,500 . The price may vary due to your customization and product availability. You can buy Ubiquiti UF-Loco-5 Optical Network Unit (ONU) from our website or visit our showrooms nearby.
