Yamaha PA2120 Power Amplifier

Product Id: 10.11.944.30

Brand Yamaha

Regular Price Tk 72,260 Monthly EMI Tk 6,022
Special Price Tk 66,800

Delivery in 7 days

Quick Overview

  • Channel - Unmentioned
  • Connectivity Mode - Wired
  • USB Port - No
General
Brand
Yamaha

Model
Yamaha PA2120

Type
Amplifier


Audio Details
Channel
Unmentioned

RMS/Channel (Watt)
Unmentioned

RMS/Subwoofer (Watt)
Unmentioned

Output Power
1kHz (THD+N=1%: 3 ohm): 100W x 2 (20ms Burst), 1kHz (THD+N=1%: 4 ohm): 120W x 2 (20ms Burst), 1kHz (THD+N=1%: 8 ohm): 100W x 2 (20ms Burst), High impedance: 100V line: 120W x 2 or 200W x 1, High impedance: 70V line: 120W x 2 or 200W x 1.

Frequency (Hz - KHz)
0dB, -2.5dB, +1.0dB (Line in to THRU OUT, 20Hz to 20kHz), 0dB, -3.0dB, +1.0dB (Line in to Speaker out, 50Hz to 20kHz, 1W, 3/4/8), 0dB, -3.0dB, +1.0dB (Line in to Speaker out, 90Hz to 20kHz, 1W, 70V/100V, 120W/200W)


Connectivity
Connectivity Mode
Wired

USB Port
No


Technical Info
Microphone
No

Input Interface
Input A-B:MONO RCA pin x 2 (unbalanced) or 3.5mm Euro block (6-pin, balanced)

Output Interface
Barrier strip x 2 pairs


Performance
Lighting Effect
No

Waterproof
No

Dustproof
No

Shockproof
No


Power
Approx. Power Consumption
60W


Physical Description
Dimensions
480 x 45 x 379mm

Weight (Kg)
4.8 kg

Color
Black


Warranty
Warranty Details
No warranty


Additional Info
Others
Certificate: ENERGY STAR, Total harmonic distortion: 0.2% (Line in to Speaker out, Half power @1kHz, 3/4/8), 0.2% (Line in to Speaker out, Half Power @1kHz, 70V/100V, 120W/200W), Line Out: THRU OUT: MONO RCA pin (unbalanced) x2, Control ports: RJ-45 (for DCP4V4S, DCP1V4S , DCP4S), Remote (3.5mm Euro block 3-pin), Input Level: Line input (unbalanced): -10dBV (Sensitivity), -10dBV (Nominal), +10dBV (Max before clip) / Line input (balanced): +4dBu (Sensitivity), +4dBu (Nominal), +24dBu (Max before clip), Output Level: -10dBV (THRU OUT, Nominal), Processors: Speaker EQ (VXS:Full Range, VXC, VXS10S/ST), HPF (150Hz), LPF (150Hz, 200Hz), Protection circuit: Power switch on/off: Mute the output*, Output voltage protection: Compress the output*, DC-fault: Power supply shutdown (Restored automatically), Amplifier protection: Thermal: Limit the output Mute Shutdown, Over current: Mute the output, Integrated power limit: Compress the output (Restored automatically), Power supply protection: Thermal: Power supply shutdown, Over voltage: Power supply shutdown, Over current: Limit the output Power supply shutdown (Restored automatically), Amplifier class: Class D, Cooling: Conventional cooling, bottom to up airflow, Power requirements: 100V, 120V, 230V - 240V, 50Hz / 60Hz, Certificate: ENERGY STAR, Others: Operating Temperature: 0 to + 40 degree C, Storage Temperature: -20 degree C to + 60 degree C, Rack-mountable when ensuring sufficient ventilation above and below the unit.

Specialty
Designed for Effortless Everyday Use, Yamaha DSP Features for Enhanced Music and Microphone Operation, Safe and Efficient in Any Environment.

Country Of Origin
Japan


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
