Feature
Operating Channels: Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165; Channel 1-233 (5925-7125 MHz); Channel Bandwidth: 20/40/80/160 MHz; Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency. Fast Roam PMKID caching; Cisco CCKM; 802.11r; OKC Security and Encryption: WEP (40 or 104 bit); Enhanced Open (OWE); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) - EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP256) - EAP-TLS; TC27 WWAN models only: WPA3 Enterprise EAP-SIM, EAP-AKA, EAP-AKA Prime Certifications Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6; Wi-Fi Enhanced Open; WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Agile Multiband; WMM; WMM-Power Save; WMM Admission Control; Voice-Enterprise; Wi-Fi Direct; QoS Management; OCE Light Sensor Automatically adjusts display backlight brightness Motion Sensor 3-axis accelerometer with MEMS Gyro Proximity, Sensor: Automatically detects when the user places the handset against head during a phone call to disable display output and touch input. Magnetometer eCompass to detect direction Pressure Sensr Altitude for locating (TC27 North America only), Data Capture; Scanning SE55 1D/2D Advanced Range Scan Engine with IntelliFocus technology; SE4710 1D/2D Scan Engine Camera Rear camera 16 MP; front camera 5 MP NFC NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards, NFC Forum tags 2,3,4,5; Host Card Emulation, Contactless Payment
Others
Display 6.0 in. color Full High Definition+ (1080 x 2160); LED backlight; 450 Nits; Corning Gorilla Glass, Imager Window: Corning Gorilla Glass, Touch Panel: Multi-mode capacitive touch with bare or light gloved fingertip input, Expansion Slot: User accessible MicroSD card supports up to 2 TB, SIM: TC27 only: 1 Nano SIM and 1 eSIM (except China), Network Connections: TC22: WLAN, WPAN; TC27: WWAN, WLAN, WPAN Notifications Audible tone, multi-color LEDs; vibration, Keypad On-screen keypad, Audio: Two microphones with noise cancellation; dual speakers for loudness; Bluetooth, wireless headset support; high quality, speaker phone; PTT headset (Zebra USB-C), support; HD Voice, including Super-wideband, (SWB), Wideband (WB) and Fullband (FB), Buttons Dual dedicated scan buttons; programmable button for PTT or other use; volume up/down; power Interface Ports USB 3.1 (Bottom Type C) Super Speed (host and client); 2-pin or 8-pin rear connector, CPU: Qualcomm 5430 hex-core, 2.1 GHz, Memory 6 GB RAM/64 GB UFS Flash, Operating Temp.: -10 Degree C to 50 Degree C, Storage Temp.: -40 Degree C to 70 Degree C, Humidity 5% - 95% non-condensing, Drop Spec. Multiple 5 ft./1.5 m drops to concrete over, operating temp (-10 Degree C to 50 Degree C) with protective boot per MIL-STD-810H, Multiple 4.5 ft/1.3 m drops to tile over, concrete over operating temp (-10 Degree C to 50 Degree C) per MIL-STD 810H, Tumble Spec. 500 tumbles, 1.6 ft./0.5 m; 500 tumbles, 3.3, ft./1.0 m with optional protective boot, WLAN Radio IEEE 802.11 a/ b/ g/ n/ ac/ d/ h/ i/ r/ k/ v/ w/ mc/ ax; 2x2 MU-MIMO, Wi-Fi 6E (802.11ax), Wi-Fi, certified; Wi-Fi 6 Certified
