Asrock B650M Pro RS (Wi-Fi 6E) DDR5 AMD Motherboard

Item: Asrock B650M Pro RS (Wi-Fi 6E) DDR5 AMD Motherboard
Rating: 5
Author: Abdur Rahim

11 reviews

Product Id: 02.02.504.134

Regular Price

Tk 0

Out Of Stock

See similar model

Quick Overview

Chipset - AMD B650
Sockets Supported - AM5
Supported CPU - Supports Ryzen 9000, 8000 and 7000 Series Processors
Generation - Not Applicable
Memory Slot - 4
Memory Max. - 256GB
Back-Connect Design - No

Payment Method Shipping & Charge Order Procedure

Brand

Asrock

Model

Asrock B650M Pro RS (Wi-Fi 6E)

Chipset

AMD B650

Sockets Supported

AM5

Built-in Processor

Generation

Not Applicable

Back-Connect Design

Memory Type

DDR5

Memory Slot

Memory Max.

256GB

Optane Memory Support

Graphics

Integrated

Graphics Chipset

Integrated With Processor

M.2/SSD Expansion Slot

WiFi

Yes

Bluetooth

Bluetooth 5.2

Form Factor

Micro-ATX

Supported Operating System

Windows 10 / 11

Body Color

Black & White

Warranty Details

3 year

General

Brand

Asrock

Model

Asrock B650M Pro RS (Wi-Fi 6E)

Body Color

Black & White

CPU

Chipset Brand

AMD

Chipset

AMD B650

Sockets Supported

AM5

Built-in Processor

Supported CPU

Supports Ryzen 9000, 8000 and 7000 Series Processors

Generation

Not Applicable

Memory Support

Memory Type

DDR5

Memory MHz

7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 ECC/Non-ECC & Un-buffered Memory

Memory Channel

Dual

Memory Slot

Memory Slot (Additional Info)

Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

Memory Max.

256GB

Optane Memory Support

Storage

Storage Interface

6.0Gb/s

M.2/SSD Expansion Slot

M.2/SSD Expansion Slot Details

3 x M.2 (1 x Blazing M.2 Socket (M2_1, Key M) type 2260/2280 supports PCIe Gen5x4 (128 Gb/s) mode, 1 x Hyper M.2 (M2_2, Key M) type 2260/2280 supports PCIe Gen4x4 (64 Gb/s) mode, 1 x M.2 (M2_3, Key M) type 2260/2280 supports PCIe Gen4x2 (32 Gb/s) mode)

Graphics

Integrated

Graphics Chipset

Integrated With Processor

Multi-GPU Support

Supports AMD CrossFire

PCI Express Slot

1 x PCIe 4.0 x16 Slot (PCIE1) supports x16 mode, 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode

Audio & Video

Audio Chipset

Realtek ALC897 Codec, Nahimic Audio

Audio Channel

7.1

Network & Connectivity

LAN Chipset

Dragon RTL8125BG

LAN Speed (Mbps)

10/100/1000/2500 Mb/s

WiFi

Yes

WiFi Technology

Wi-Fi 6E

Bluetooth

Bluetooth 5.2

Ports

USB Port

1 x USB 3.2 Gen2 Type-A, 2 x USB 3.2 Gen1 Type-A, 4 x USB 2.0 Type-A, 1 x USB 3.2 Gen2 Type-C

VGA Port

DVI Port

HDMI Port

DisplayPort (DP)

IDE Port

SATA Port

4 x SATA

Thunderbolt

TPM Port

Yes

COM Port

Technical Info

Back-Connect Design

Cable Management

Front

Heatsink

Yes

FireWire

CrossFire Support

Yes

Sli Support

Raid Support

0 , 1 , 10 (SATA), 0 , 1 , 10 (M.2)

RGB Support

ARGB

RGB Sync

ASRock Polychrome

RGB Connector

1 x RGB LED Header, 3 x Addressable LED Headers

Approx. Power Consumption

60W

Form Factor

Micro-ATX

Bios Information

BIOS Type

256Mb AMI UEFI Legal BIOS with GUI support

BIOS Model

AMI UEFI Legal BIOS

Compatibility

Supported Operating System

Windows 10 / 11

Compatible Products

Compatible with AM5 Socket AMD Ryzen 7000, 8000 & 9000 Series Processor.

Warranty

Warranty Details

3 year

Additional Info

Feature

PCIe Gen5 (M.2), Rock-Solid Durability 8+2+1 Power Phase, 50A Dr.MOS, Pre-Installed I/O Shield, BIOS Flashback Button, ASRock Auto Driver Installer, EZ Troubleshooter, Integrated AMD RDNA graphics (Actual support may vary by CPU), HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz, DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz, Supports Dragon 2.5G LAN Software.

Others

Connector: (1 x SPI TPM Header - 1 x Power LED and Speaker Header - 1 x RGB LED Header - 3 x Addressable LED Headers - 1 x CPU Fan Connector (4-pin) - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card)), Accessories: (1 x User Manual - 2 x SATA Data Cables - 2 x ASRock WiFi 2.4/5/6 GHz Antennas - 3 x Screws for M.2 Sockets - 1 x Standoff for M.2 Socket).

Country Of Origin

Taiwan

Made in/ Assemble

China

Details

Features of Asrock B650M Pro RS (Wi-Fi 6E) Motherboard In Bangladesh

Boost your system with the Asrock B650M Pro RS (Wi-Fi 6E) DDR5 AMD Motherboard. It is available at Ryan's Computers in Bangladesh. This motherboard supports DDR5 RAM, giving you the power to handle larger file sizes and improve data transmission speeds.

With Wi-Fi 6E, enjoy faster internet connections and reduced packet loss, perfect for real-time tasks. It also supports AMD Expo for easy memory tuning, making it a solid choice for high-performance desktop processors. Get ready to unleash speed and experience smooth computing with this feature-packed motherboard

Superior Speed and Connectivity

The Asrock B650M Pro RS has features that gives high - speed performance.

DDR5 Memory: This enables faster speed data transfer rates. It improves multitasking and handles challenging tasks better.
Wi-Fi 6E: Enjoy ultra-fast and stable wireless networks. This is important for gaming and streaming.
PCIe 5.0 Slots: Great for premium graphics cards and storage devices. They offer quicker speed at the time of transferring data.
USB 3.2 Gen 2 Ports: Allows for rapid data transfer, Good for connecting high-speed devices
Smart Power Delivery: This feature boosts performance during heavy tasks. It also helps with power efficiency.

Solid Build and Effective Cooling

The Asrock B650M Pro RS features strong components and effective cooling solutions.

Reinforced PCIe Slots: These are designed to handle heavy GPUs. They provide extra strength for graphics-intensive applications.
Premium Capacitors: They deliver a stable power supply. This enhances the system's overall reliability.
Integrated Heatsinks: These prevent overheating. They protect components from thermal damage.
Surge Protection: This feature safeguards the system against power surges and static discharges. It helps maintain reliability over a long period of time.
Fan Headers: These enable better cooling control. This is important for keeping performance high during demanding tasks.

Versatile Practical Use Cases

The Asrock B650M Pro RS works well for many different applications.

Gaming Builds: It is great for gamers who need fast data processing and wireless connectivity.
Content Creation: This motherboard helps creators who work with large files. It gives the speed and quality needed for high-performance tasks.
Office Setups: It offers the speed and support needed for professional performance.
Upgrading Systems: This is perfect for users wanting to upgrade to the latest AMD Ryzen processors.
Future-Proofing: It supports upcoming technologies. This makes it a smart choice for future upgrades.

Get Your Asrock B650M Pro RS at Ryans Computers

In conclusion, the Asrock B650M Pro RS (Wi-Fi 6E) DDR5 AMD Motherboard gives excellent speed and connectivity. It is a top choice for tech lovers.

Its unique features and strong design make it perfect for many uses. From gaming to professional workloads this mother board is your right choice. For those in Bangladesh, you can find this powerful motherboard at Ryan's Computers. Visit Ryan's Computers today to upgrade your computing experience.

What is the price of Asrock B650M Pro RS (Wi-Fi 6E) Motherboard In Bangladesh?

The price of Asrock B650M Pro RS (Wi-Fi 6E) Motherboard not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Asrock B650M Pro RS (Wi-Fi 6E) Motherboard from our website or visit our showrooms nearby.
Looking to purchase office, corporate, or institutional equipment? Ryans Computers is here to help. We provide customized solutions tailored to your needs, backed by fast delivery and dependable after-sales service. Our expert Ryans Care team is always ready to support you with troubleshooting, technical assistance, and configuration services—so you can focus on what matters most.
