Colorful Battle-AX B760M-PLUS D5 V20 DDR5 12th/13th/14th Gen LGA1700 Socket Motherboard
Product Id: 02.01.100.10
Brand
Colorful
Regular Price Tk 19,640
Monthly EMI Tk 1,637
Special Price Tk 18,300
Quick Overview
- Chipset - Intel B760
- Sockets Supported - LGA1700
- Supported CPU - 12th / 13th / 14th Gen Intel Core, Pentium and Celeron processors.
- Generation - 12th/13th/14th
- Memory Slot - 4
- Memory Max. - 192GB
General
Brand
Colorful
Model
Colorful Battle-AX B760M-PLUS D5 V20
Body Color
Black
CPU
Chipset Brand
Intel
Chipset
Intel B760
Sockets Supported
LGA1700
Built-in Processor
No
Supported CPU
12th / 13th / 14th Gen Intel Core, Pentium and Celeron processors.
Generation
12th/13th/14th
Memory Support
Memory Type
DDR5
Memory MHz
6800 (OC)/ 6600 (OC)/ 6400 (OC)/ 6200 (OC)/ 6000 (OC)/ 5800 (OC)/ 5600 (OC)/ 5400 (OC)/ 5200 (OC)/ 5000 (OC)/ 4800MHz
Memory Channel
Dual
Memory Slot
4
Memory Max.
192GB
Optane Memory Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
3
M.2/SSD Expansion Slot Details
3 x M.2 (1 x M.2 support 2242/2280 M.2 SSD (PCIe 4.0 x4, CPU channel), 2 x M.2 support 2242/2260/2280 M.2 SSD (PCIe 4.0 x4, PCH channel))
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
Multi-GPU Support
No
PCI Express Slot
1 x PCI-E 5.0 x16 Slot, 1 x PCI-E 3.0 x1 Slot
Audio & Video
Audio Channel
5.1
Network & Connectivity
LAN Chipset
RTL8125 2.5Gbit
LAN Speed (Mbps)
10/100/1000/2500Mbps
WiFi
No
Bluetooth
No
Ports
USB Port
2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A, 1 x USB Type-C
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
No
TPM Port
No
COM Port
No
Technical Info
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 5, 10
RGB Support
ARGB
RGB Connector
2 5V 3-pin ARGB pins, 2 12V 4-pin RGB pins
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Type
128 Mbit Flash ROM
BIOS Model
UEFI BIOS
Compatibility
Supported Operating System
Windows 7 / 8 / 8.1 / 10 / 11
Warranty
Warranty
3 Year
Warranty Details
3 year
Additional Info
Feature
BATTLE-AX series customized heat dissipation armor 12+1+1 phase reinforced power supply, Provide 3 PCIe 4.0 x4 M.2 SSD slots, Provide one USB 3.2 Gen 2 Type-C and one USB 3.2 Gen 1 Type-A high-speed rear interface, Equipped with Realtek 2.5G high-speed wired network card Support the iGame Center light efficiency control software, which can synchronously adjust the light efficiency of the radiator, cooling fan and memory, Equipped with CNVI WiFi/BT slot, supporting extended WiFi module Six protection technologies, more stable product operation 200 processes are strictly tested with guaranteed quality PCB atomization process comprehensively upgraded.
Country Of Origin
China
Made in/ Assemble
China
N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
Details
Features of Colorful Battle-AX B760M-PLUS D5 V20 Motherboard In Bangladesh
BATTLE-AX B760M-PLUS D5 V20
Feature Highlights:
- BATTLE-AX series customized heat dissipation armor
- 12+1+1 phase reinforced power supply
- Provide 3 PCIe 4.0 x4 M.2 SSD slots
- Provide one USB 3.2 Gen 2 Type-C and one USB 3.2 Gen 1 Type-A high-speed rear interface
- Equipped with Realtek 2.5G high-speed wired network card
- Support the iGame Center light efficiency control software, which can synchronously adjust the light efficiency of the radiator, cooling fan and memory
- Equipped with CNVI WiFi/BT slot, supporting extended WiFi module
- Six protection technologies, more stable product operation
- 200 processes are strictly tested with guaranteed quality
- PCB atomization process comprehensively upgraded
What is the price of Colorful Battle-AX B760M-PLUS D5 V20 Motherboard In Bangladesh?
The price of Colorful Battle-AX B760M-PLUS D5 V20 Motherboard starts from 18,300 . The price may vary due to your customization and product availability. You can buy Colorful Battle-AX B760M-PLUS D5 V20 Motherboard from our website or visit our showrooms nearby.
