Gigabyte B760M D2H DDR4 12th/13th Gen Intel LGA1700 Socket Motherboard
Product Id: 02.01.018.461
Brand
Gigabyte
Regular Price Tk 16,380
Monthly EMI Tk 1,365
Special Price Tk 15,200
Quick Overview
- Chipset - Intel B760
- Memory Max. - 64GB
- Memory Slot - 2
- Sockets Supported - LGA1700
- Supported CPU - 13th/14th and 12th Generation Intel Core, Pentium Gold and Celeron Processors
- Generation - 12th/13th/14th
General
Brand
Gigabyte
Model
Gigabyte B760M D2H
Body Color
Black
CPU
Chipset Brand
Intel
Chipset
Intel B760
Sockets Supported
LGA1700
Built-in Processor
No
Supported CPU
13th/14th and 12th Generation Intel Core, Pentium Gold and Celeron Processors
Generation
12th/13th/14th
Memory Support
Memory Type
DDR4
Memory MHz
5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s non-ECC Un-buffered DIMM
Memory Channel
Dual
Memory Slot
2
Memory Slot (Additional Info)
2 x DDR4 DIMM
Memory Max.
64GB
Memory Max. (Additional Info)
Up to 64GB (32 GB single DIMM capacity)
Optane Memory Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
2
M.2/SSD Expansion Slot Details
1 x M.2, type 2280 SATA and PCIe 3.0 x4/x2 SSD
Graphics
Graphics
Integrated
Graphics Chipset
Intel HD Graphics support
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16, 2 x PCI Express x1
Audio & Video
Audio Chipset
Realtek Audio CODEC
Audio Channel
7.1
Network & Connectivity
LAN Chipset
Realtek 2.5GbE LAN
LAN Speed (Mbps)
10/ 100/ 1000/ 2500Mbps
WiFi
No
WiFi Technology
No
Bluetooth
No
Ports
USB Port
4 x USB 3.2 Gen 1, 2 x USB 2.0/1.1
VGA Port
1
DVI Port
No
HDMI Port
1
DisplayPort (DP)
No
IDE Port
No
SATA Port
4
Thunderbolt
No
TPM Port
1
COM Port
No
Technical Info
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 5, 10
RGB Support
RGB
RGB Connector
1 x RGB LED strip header
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Type
1 x 128 Mbit flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Compatibility
Supported Operating System
Windows 10, 11
Compatible Products
13th/14th and 12th Generation Intel Core, Pentium Gold and Celeron Processors
Warranty
Warranty
3 Year
Warranty Details
3 year
Additional Info
Feature
Unparalleled Performance Hybrid 6+2+1 Phases Digital VRM Solution, Dual Channel DDR4 2 DIMMs XMP Memory Module Support, Next Generation Storage 2 PCIe 4.0 x4 M.2 Connectors, EZ-Latch PCIe 4.0x16 Slot with Quick Release Design, Fast Networks 2.5GbE LAN, Extended Connectivity HDMI, D-Sub, Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP, Q-Flash Plus Update BIOS Without Installing the CPU, Memory and Graphics Card.
Others
6+2+1 Phases Hybrid Digital VRM Design, PERSONALIZATION, Support for Q-Flash, Support for Q-Flash Plus
Country Of Origin
Taiwan
Made in/ Assemble
China
