Others
Angle Adjustment Pan: 0 to 360 Degree, tilt: 0 to 90 Degree, rotate: 0 to 360 Degree, Min. Illumination: Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light, FOV: 75 Degree, vertical FOV: 40 Degree, diagonal FOV: 89 Degree, Depth Of Field: 4 mm: 2.7 m to infinity, DORI: 4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m, Illuminator: Supplement Light Type: White Light, Supplement Light Range: Up to 30 m, Smart Supplement Light: Yes, Main Stream: 50 Hz: 20 fps (2560 x 1440), 25 fps (1920 x 1080, 1280 x 720), 60 Hz: 20 fps (2560 x 1440), 24 fps (1920 x 1080, 1280 x 720), Sub-Stream: 50 Hz: 25 fps (1280 x 720, 640 x 480, 640 x 360), 60 Hz: 24 fps (1280 x 720, 640 x 480, 640 x 360), Video Bit Rate: 32 Kbps to 8 Mbps, H.264 Type: Baseline Profile,Main Profile,High Profile, H.265 Type: Main Profile, Bit Rate Control: CBR,VBR, Region Of Interest (ROI): 1 fixed region(s) for main stream, Audio Type: Mono sound, Audio Sampling Rate: 8 kHz/16 kHz, Audio Bit Rate: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC), API: Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK, User/Host: Up to 32 users, 3 user levels: administrator, operator, and user, Client: iVMS-4200,Hik-Connect, Web Browser: Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Day/Night Switch: Day,Night,Auto,Schedule, Reset Key, Linkage: Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture, Protection: IP67.
Specialty
Environment Noise Filtering, Image Enhancement: BLC,HLC,3D DNR, Image Settings: Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser, Privacy Mask: 4 programmable polygon privacy masks, Motion, human and vehicle detection.
