Huawei S110-16LP2SR 18 Port Unmanaged eKit SOHO Switch

Product Id: 29.05.487.11

Brand Huawei

Regular Price Tk 21,540 Monthly EMI Tk 1,795
Special Price Tk 20,000

Delivery in 1 days

Quick Overview

  • Form Factor - 1U Rack-mountable
  • Port - 11 - 20 Port
  • Type - Network Switch
  • Manageability - Unmanaged
  • PoE - Yes
General
Brand
Huawei

Model
Huawei S110-16LP2SR

Type
Network Switch


Ports & Slots
Port
11 - 20 Port

Number of Total Port
18 Port

Gigabit Port
18

SFP Port
2

SFP+ Port
16


Technical Info
PoE
Yes

Manageability
Unmanaged

Interface(s)
16 x 10/100/1000Mbps PoE+ & 2 x 10/100/1000Mbps SFP

Connector Type
16 x 10/100/1000 Mbps RJ45, 2 x 10/100/1000Mbps SFP

MTBF
506411.82 Hours


Physical Description
Fan/Fanless
Fanless

Indicators
PWR , Port Indicator (Steady on, Blinking)

Body Material
Metal

Body Color
Grey

Form Factor
1U Rack-mountable

Dimension
43.6 x 442 x 260mm

Weight
3.0 kg


Power
Power Supply
100 - 240 V AC; 50/60 Hz

Approx. Power Consumption
22W (Typical), Without PoE: 22 W, Full PoE load: 160 W (PoE: 124 W) (Max.), 12W (Static)


Warranty
Warranty Details
1 Year (Without Adapter)


Additional Info
Others
Typical heat dissipation: 75.07 BTU/hour, MTTR: 2 hours, Availability: > 0.99999, Noise at normal temperature (acoustic power): Noise-free (no fans), < 30, Noise at normal temperature (acoustic pressure): Noise-free (no fans), < 20, Working mode: Standard mode, Port isolation, Uplink aggregation, Flow control disabling, MAC address entry: 8K, Long-term operating temperature: 0 Degree C to 40 Degree C at an altitude of 0 -1800m (0-5906 ft.), Restriction on the operating temperature variation rate: When the altitude is 1800 - 5000 m (5906-16404 ft.), the highest operating temperature reduces by 1 Degree C every time the altitude increases by 220 m (722 ft.), Storage temperature: -40 Degree C to 70 Degree C, Long-term operating relative humidity: 5% RH to 95% RH (non-condensing), Long-term operating altitude: 0 - 5000 m (0 - 16404 ft.), Storage altitude: 0 - 5000 m (0 - 16404 ft.), Power supply mode: AC built-in, Rated input voltage: AC input: 100 - 240 V AC; 50/60 Hz, Input voltage range: AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz, Maximum input current: 3 A, Service port surge protection: Common mode: -+4 kV, Power supply surge protection: Differential mode: -+6 kV; common mode: -+6 kV, Ingress protection level (dustproof/waterproof): IP20, Heat dissipation mode: Natural heat dissipation, Certification: EMC certification, Safety certification, Manufacturing certification

Country Of Origin
China

Made in/ Assemble
China


N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
