2 x M.2 ( 1x M2 (supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices), 1x M2 (supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices))
M.2/SSD Slot Gen
Up to Gen 3
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
PCI Express Slot
1 x PCIe 3.0 x16 (from CPU), 2 x PCIe x1 (from PCH)
Audio & Video
Audio Chipset
Realtek ALC892
Audio Channel
7.1
Network & Connectivity
LAN Chipset
Realtek RTL8111H Gigabit
WiFi
No
Bluetooth
No
Ports
USB Port
6 x USB 3.2 Gen 1 Type A, 6 x USB 2.0
VGA Port
1
DVI Port
1
HDMI Port
1
DisplayPort (DP)
No
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
No
TPM Port
Yes
Technical Info
Back-Connect Design
No
Cable Management
Front
DirectX Support
12
Heatsink
Yes
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 5, 10
RGB Support
RGB
RGB Sync
Mystic light
RGB Connector
1 x 4-pin RGB LED connector
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Type
1 x 128 Mb flash
BIOS Model
UEFI AMI BIOS
BIOS Version
ACPI 6.2, SM BIOS 3.2
Compatibility
Supported Operating System
Windows 10
Warranty
Warranty
3 year
Additional Info
Feature
Supports 10th Gen Intel Core / Pentium Celeron processors for LGA 1200 socket, Supports DDR4 Memory, up to 2933 MHz(Max), Enhanced Power Design: 5+1+1 Duet Rail Power System, Core Boost, DDR4 Boost, Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop gaming experience, Gigabit LAN with LAN Manager: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection, Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs, Audio Boost: Reward your ears with studio grade sound quality
Others
1x 24-pin ATX main power connector, 1x 8-pin ATX 12V power connector, 1x 4-pin CPU fan connector, 1x 4-pin water pump connector, 2x 4-pin system fan connectors, 1x front panel audio connector, 2x system panel connectors, 1x parallel port connector, 1x serial port connector, 1x Chassis Intrusion connector, 1x Clear CMOS jumper, 1x 3-pin RAINBOW LED connector, 1x TPM module connector
Country Of Origin
Taiwan
Made in/ Assemble
China
