NZXT H7 Flow (2022) Mid Tower White ATX Gaming Desktop Casing #CM-H71FW-01

Item: NZXT H7 Flow (2022) Mid Tower White ATX Gaming Desktop Casing #CM-H71FW-01
Rating: 5
Author: Verified Buyer

12 reviews

Product Id: 07.02.681.71

Out Of Stock

See similar model

Quick Overview

Case Type - Mid Tower
Supported Motherboard Type (Max.) - Up to ATX
Optical Drive Bay - No
Cooling Fan (Built-In) - 2
Lighting Fan - No
Power Supply (Built-In) - No
Back-Connect Supported - No
Color - White

Color variations

White
Tk 0

Payment Method Shipping & Charge Order Procedure

Brand

NZXT

Model

NZXT H7 Flow (2022)

Series

Gaming

Case Type

Mid Tower

Supported Motherboard Type (Max.)

Up to ATX

Front/Top USB port

2 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 2 Type-C

Front/Top Audio Port

1 x Audio Jack

Expansion Slots

Optical Drive Bay

Cooling Fan (Built-In)

Additional Fan Slot

Power Supply (Built-In)

Power Supply Type

ATX

Power Supply Mounted

Bottom

Back-Connect Supported

Transparent Side Window

Yes

Number of Buttons

Dust Cover

Color

White

Dimensions

505 x 480 x 230mm

Weight (Kg)

10.05 kg

Warranty

No warranty

General

Brand

NZXT

Model

NZXT H7 Flow (2022)

Series

Gaming

Case Type

Mid Tower

Part No

CM-H71FW-01

Technical Info

Supported Motherboard Type

Mini-ITX, Micro-ATX, ATX

Lighting Support (Front/Top/Side)

Supported LED Strip

Fan / Light Controller

Illumination

Back-Connect Supported

Graphics-Card Length

410mm

Supported CPU Cooler

Air Cooler or Liquid Cooler

CPU Cooler Height

185mm

PSU Length

200mm

Cable Management Depth

18-22mm

Thickness

57mm

Ports & Slots

Front/Top USB port

2 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 2 Type-C

Front/Top Audio Port

1 x Audio Jack

5.25 Inch Drive Bay

3.5 Inch Drive Bay

2.5 Inch Drive Bay

2+2

1.8 Inch Drive Bay

Expansion Slots

Optical Drive Bay

Memory Card Slot

Fan & Radiator Details

Cooling Fan (Built-In)

Additional Fan Slot

Pre-Installed Fan Size

1 x 120mm (Front), 1 x 120m (Rear)

Supported Fan Size

Front: 3 x 120mm/ 3 x 140mm, Top: 3 x 120mm/ 2 x 140mm, Rear: 1 x 120mm/ 1 x 140mm

Lighting Fan

Radiator Support Front/Top/Rear

Front: Up to 360mm with Push/Pull, Top: Up to 360mm, Rear: Up to 140mm

Radiator Support Max.

Up to 360mm

Power

Power Supply (Built-In)

Power Supply Type

ATX

Power Supply Mounted

Bottom

Approx. Power Consumption

10W

Physical Description

Transparent Side Window

Yes

Case Windowed

Tempered Glass

Buttons

1 x Power Button

Number of Buttons

Material

SGCC Steel and Tempered Glass

Dust Cover

Color

White

Dimensions

505 x 480 x 230mm

Weight (Kg)

10.05 kg

Handle

Warranty

No warranty

Additional Info

Others

FAN: Model: F120Q, Speed: 1200 +- 240RPM, Airflow: 62.18 CFM, Static: 1.05 mm - H2O, Noise: 25.1 dBA, Fan Connector: 3-pin.

Specialty

This mid-tower case is ready to bring the cool. Featuring a perforated front and top panel, alongside widened channels, hooks, straps, and toolless entry, this sleek case will keep any build cool and comfortable while offering plenty of space. Perforated front & top panels enable maximum thermal performance. Intuitive cable management system with wide channels, hooks, & straps.

Country Of Origin

USA

Made in/ Assemble

China

Details

Features of NZXT H7 Flow (2022) Casing In Bangladesh

Perforated front & top panels enable maximum thermal performance
Intuitive cable management system with wide channels, hooks, & straps
Tool-less access to front & side panels (tinted panels on black variant only)
Front & top support radiators up to 360mm
Includes two F Series Quiet 120mm Fans
Supports vertical GPU mounting (Sold Separately)
Three color options (Matte Black, Matte White, White & Black)
Two top-mounted USB 3.2 Type-A ports
One top-mounted USB 3.2 Type-C port

What is the price of NZXT H7 Flow (2022) Casing In Bangladesh?

The price of NZXT H7 Flow (2022) Casing not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy NZXT H7 Flow (2022) Casing from our website or visit our showrooms nearby.
