Others
Transmission media: Recommended: CAT5/5e UTP or better, Level of protection: Lightning protection for ports: 6kV, Lightning protection for power: 6kV, ESD: Air discharge: +/-10kV, contact discharge: +/-8kV. Packet forwarding rate: 41.70 Mpps, Buffer: 12 Mb, MAC address table: 16K, Jumbo frame: 10 K, PoE power supply management: Support, PoE budget : Single port: AF: 15.4W, AT: 30W, Whole device: 370W, Mounting: Desktop mounting: support, wall mounting: support. Rack mounting: non-support, Energy Efficient: Support, Environment : Operating temperature: 0 degrees C to 45 degrees C, storage temperature: -40 degrees C to 70 degrees C. Operating humidity: (10% - 90%) RH, non-condensing, Storage humidity: (5% - 90%) RH, non-condensing, Certification: FCC, CE, RoHS, L3 Features : Supports VLAN-based routing, Supports: IPv4/IPv6 static routing, Supports static: ARP, PoE power supply management: Supports port PoE configuration and power supply with priority. Supports PoE over-temperature protection, supports PoE scheduled management, supports intelligent management and PoE-powered device detection (port status, power assignment, and PoE-powered device status). Security features: ARP receiving limit, unknown MAC address discard, DoS attack defense, 802.1x security authentication, Radius security authentication, VLAN: IEEE 802.1Q VLAN, VLAN Layer-3 interfaces, Supports three port modes: Access, Trunk, and Hybrid. DHCP Server: DHCP Relay, DHCP Snooping, Supports Option 82 policy configuration, Port aggregation: Static aggregation, LACP dynamic aggregation, Spanning tree IEEE 802.1d STP (Spanning Tree Protocol), IEEE 802.1w RSTP (Rapid Spanning Tree Protocol), IEEE 802.1s MSTP (Multiple Spanning Tree Protocol), Supports edge port, Supports BPDU statistics, Multicast IGMP Snooping V1/V2/V3, Supports port fast leave, Port Mirroring Supports N: 1 port mirroring, Quality of Service SP (Strict Priority), SWRR (Simple Weighted Round Robin), WRR (Weighted Round Robin), Supports 802.1p port trust mode, supports DSCP port trust mode, Supports a maximum of 8-queue service quality mapping, ACL: Supports MAC ACL and IP ACL. Loading and upgrade: Supports FTP/TFTP/HTTP upgrade. Supports configuration import and export, Management and maintenance: Supports Telnet, Console, Supports SNMP V1/V2/V3, Supports WEB management and maintenance. Supports Ping/IPv6/Tracert/Connection Detection, CPU Monitoring, and Memory Monitoring.
