Others
Access Control: Source/Destination IP Based Access Control, Filtering: WEB Group Filtering, URL Filtering, Web Security, ARP Inspection: Sending GARP Packets, ARP Scanning, IP-MAC Binding. Attack Defense: TCP/UDP/ICMP Flood Defense, Block TCP Scan (Stealth FIN/Xmas/Null), Block Ping from WAN, Standards: IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, Network Media: 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100 STP (Max 100 m), 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100 STP (Max 100 m), 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m), Fan Quantity: Fanless, Flash: 128 MB NAND, DRAM: 512 MB DDR4, LED: PWR, SYS, SFP, USB, WAN(1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act), Protection: 4 kV surge protection, Enclosure: Steel, Mounting Desktop/ Wall-Mounting/Rack-Mounting, Max. Power Consumption: 7.5 W (with USB 3.0 connected), 4.5 W (without USB 3.0 connected). IPS Throughput: TCP: 229 Mbps; UDP: 188 Mbps, DPI Throughput: TCP: 933 Mbps; UDP: 927 Mbps, WireGuard VPN: 341.3 Mbps, Concurrent Session: 150,000, New Sessions /Second: 5,300, NAT (Static IP): 945.3 Mbps / 940.5 Mbps, NAT(DHCP): 939.6 Mbps / 940.9 Mbps, NAT(PPPoE): 943.6 Mbps / 940.9 Mbps, NAT (L2TP): 880.1 Mbps / 859.0 Mbps, NAT (PPTP): 855.0 Mbps / 907.2 Mbps. IPsec VPN: Throughput: ESP-SHA1-AES256: 617.1 Mbps, ESP-SHA256-AES256: 592.8 Mbps, ESP-SHA384-AES256: 592.4 Mbps, ESP-SHA512-AES256: 604.5 Mbps.OpenVPN: 139.1 Mbps, L2TP VPN Throughput: Unencrypted: 977.4 Mbps, Encrypted: 334.6 Mbps, PPTP VPN Throughput: Unencrypted: 1064.1 Mbps Encrypted: 206.8 Mbps SSL VPN Throughput: 131.6 Mbps, 66 Byte Packet Forwarding Rate: 1,453,489 pps / 1,453,488 pps, 1,518 Byte Packet forwarding rate: 81,279 pps / 81,275 pps. MAC Clone Modify WAN/LAN MAC Address. DHCP: DHCP Server, DHCPv6 PD Server (only in Standalone Mode), DHCP Options Customization, DHCP Address Reservation, Multi-IP Interfaces, Multi-Net DHCP, IPv6: StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode, 802.1Q VLAN, IGMP v2/v3 Proxy, Custom Mode, Bridge Mode. Access Control: IP/Port/Protocol/Domain Name Filtering. Bandwidth Control IP-based Bandwidth Control. Load Balance: Intelligent Load Balance, Application Optimized Routing, Link Backup (Timing, Failover), Online Detection, NAT: One-to-One NAT, Multi-Net NAT, Port Forwarding, Port Triggering, NAT-DMZ, FTP/H.323/SIP/IPSec/PPTP ALG, UPnP, Session Limit: IP-based Session Limit, VPN: GRE, SD-WAN, SSL VPN, IPsec VPN: 100 IPSec VPN Tunnels, LAN-to-LAN, Client-to-LAN, Main, Aggressive Negotiation Mode, DES, 3DES, AES128, AES192, AES256 Encryption Algorithm, IPsec Failover, IKE v1/v2, MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm, NAT Traversal (NAT-T), Dead Peer Detection (DPD), Perfect Forward Secrecy (PFS). PPTP VPN: PPTP VPN Server, PPTP VPN Client (10), 50 Tunnels, PPTP with MPPE Encryption, L2TP VPN: L2TP VPN Server, L2TP VPN Client (10), 50 Tunnels, L2TP over IPSec, OpenVPN: OpenVPN Server, OpenVPN Client (5), 55 OpenVPN Tunnels, Certificate + Account Mode, Full Mode, WireGuard VPN, 20 Tunnels. Web Authentication: No Authentication, Simple Password, Hotspot(Local User /Voucher/ SMS/Radius), External Radius Sever, External Portal Sever, LDAP. Centralized Management: Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller, Maintenance : Web Management Interface, Remote Management: Export & Import Configuration, SNMP v1/v2c/v3, Diagnostics (Ping & Traceroute), NTP Synchronize, Port Mirroring, CLI (only in Standalone Mode), Syslog Support, Management Features: Automatic Device Discovery, Batch Configuration, Batch Firmware Upgrading, Intelligent Network Monitoring, Abnormal Event Warnings, Unified Configuration, Reboot Schedule, Package Content: ER7206, Power Adapter, Quick Installation Guide, Rackmount Kit.
