Roll-fed or fan-fold; die cut or continuous with or without black mark; tag stock; continuous receipt paper; wristbands
Tape Size
104 mm
Maximum Tape Width
104 mm
Memory
8MB
Storage
16MB
Interface (Built-in)
USB
Housing Dimensions
267 x 202 x 192mm
Weight (Kg)
2.5 kg
Warranty Details
1 Year (Without Adapter)
General
Brand
Zebra
Model
Zebra ZD230TA
Type
Barcode Label Printer
Part No
ZD23A42-30GG0GNZ
Technical Info
Cutter
Manual
Resolution
203 dpi
Print Performance
Printing Method
Thermal Transfer & Direct Thermal
Max. Print Speed
152 mm/sec
Max. Print Width
104mm for 203 dpi, 106 mm for 300 dpi
Direct Printing
Unmentioned
Paper Information
Paper/Media Types
Roll-fed or fan-fold; die cut or continuous with or without black mark; tag stock; continuous receipt paper; wristbands
Paper Thickness
Minimum: 0.06mm, Maximum: 0.1905mm
Paper Sensor
Movable black mark sensor, limited range from center to left side; fixed off-center gap sensor; ribbon sensor; head open sensor
Tape Size
104 mm
Maximum Tape Width
104 mm
Max. Label Length
990mm
Storage & Interface
Memory
8MB
Memory Type
Flash
Storage
16MB
Storage Type
SDRAM
Interface (Built-in)
USB
Main Features
Font Styles
16 resident expandable ZPL II bitmap fonts; Three resident scalable ZPL fonts; Five resident expandable EPL2 fonts; Native open-type font support; Unicode compliant for multi-language, on demand thermal printing; 2 MB user available non-volatile memory, 2 MB user available SDRAM
ZPL and EPL programming languages, Single LED status indicator, Single button for feed/pause, OpenACCESS for easy media loading, Dual-wall frame construction.
Others
Firmware: ZPL II; EPL 2; XML, Label Length: Minimum: 25.4 mm, Media Width: 25.4 mm to 112 mm, Media Roll Size: Maximum outer diameter: 127 mm Core inner diameter: 12.7 mm and 25.4 mm standard and 38.1 mm using optional adapters, Ribbon Types: Wax; wax/resin; resin, Ribbon Outside and Inside Diameter: Outer: 34 mm, 63.5 mm, Inner: 12.7 mm, 25.4 mm, Ribbon Length: 74 m to 300 m, Ribbon Ratio: 1:4 ribbon to media (300 m), 1:1 ribbon to media (74 m), Ribbon Width: 33.02 mm to 110 mm, Electrical: ENERGY STAR qualified, Regulatory: CCC; BSMI; KCC; BIS.
Country Of Origin
USA
Made in/ Assemble
Mexico/Singapore/China/Vietnam (or Country may vary by Shipment)
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
