2 x M.2 (connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen 7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen 7000 Series Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs)
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16 (PCIEX16), 1 x PCI Express x16
Audio & Video
Audio Chipset
Realtek Audio CODEC
Audio Channel
2/4/5.1/7.1
Network & Connectivity
LAN Chipset
Realtek 2.5GbE LAN chip
LAN Speed (Mbps)
10/ 100/ 1000/ 2500Mbps
WiFi
Yes
WiFi Technology
Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.0)
Bluetooth
Bluetooth 5.3
Ports
USB Port
4 x USB 2.0/1.1, 5 x USB 3.2 Gen 1, 2 x USB 3.2 Gen 2 Type-A (red), 1 x USB 3.2 Gen 2 Type-C
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
No
TPM Port
1
COM Port
No
Technical Info
Back-Connect Design
No
Cable Management
Front
Heatsink
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 10
RGB Support
ARGB
RGB Connector
2 x addressable LED strip headers, 2 x RGB LED strip headers
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Type
1 x 256 Mbit flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Compatibility
Supported Operating System
Windows 11, 10
Compatible Products
AMD AM5 Socket Ryzen 9000, 8000 & 7000 Series Processors
Warranty
Warranty Details
3 year
Additional Info
Feature
Advanced Thermal Design & M.2 Thermal Guard To Ensure VRM Power Stability & 25110 M.2 SSD Performance, EZ-Latch PCIe x16 Slot & M.2 Connectors with Quick Release & Screwless Design, Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP, Q-Flash Plus Update BIOS Without Installing the CPU, Memory and Graphics Card, BIOS Engineering, AMD EXPO/ Intel XMP 3.0 User Profile, High Bandwidth, Daisy-Chained Routing, Shielded Memory Routing, VRM Thermal Armor Advanced, Audiophile Grade Capacitors.
Others
Back Panel Connectors: 1 x Q-Flash Plus button, 2 x SMA antenna connectors (2T2R)jk, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 2 x audio jacks, Internal I/O Connectors: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x CPU fan/water cooling pump header, 3 x system fan headers, 1 x system fan/water cooling pump header, 1 x CPU cooler LED strip/RGB LED strip header, 1 x front panel header, 1 x front panel header, 1 x serial port header, 1 x THB_U4 add-in card connector, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only), 1 x reset button, 1 x reset jumper, 1 x Clear CMOS jumper, H/W Monitoring: Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control.
Country Of Origin
Taiwan
Made in/ Assemble
China
