Gigabyte B760M GAMING DDR5 12th/13th/14th Gen Intel LGA1700 Socket Motherboard

Item: Gigabyte B760M GAMING DDR5 12th/13th/14th Gen Intel LGA1700 Socket Motherboard
Rating: 5
Author: Verified Buyer

5 reviews

Product Id: 02.01.018.529

Out Of Stock

See similar model

Quick Overview

Form Factor - Micro-ATX
Chipset - Intel B760
Sockets Supported - LGA1700
Supported CPU - Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
Generation - 12th/13th/14th
Memory Slot - 2
Memory Max. - 128GB
Back-Connect Design - No
Body Color - Black

Payment Method Shipping & Charge Order Procedure

Brand

Gigabyte

Model

Gigabyte B760M GAMING

Chipset

Intel B760

Sockets Supported

LGA1700

Built-in Processor

Generation

12th/13th/14th

Back-Connect Design

Memory Type

DDR5

Memory Slot

Memory Max.

128GB

Optane Memory Support

Graphics

Integrated

Graphics Chipset

Integrated With Processor

M.2/SSD Expansion Slot

WiFi

Bluetooth

Form Factor

Micro-ATX

Supported Operating System

Windows 10, 11

Body Color

Black

Warranty

3 year

General

Brand

Gigabyte

Model

Gigabyte B760M GAMING

Body Color

Black

CPU

Chipset Brand

Intel

Chipset

Intel B760

Sockets Supported

LGA1700

Built-in Processor

Supported CPU

Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors

Generation

12th/13th/14th

Memory Support

Memory Type

DDR5

Memory MHz

8000(O.C.)/ 7800(O.C.)/ 7600(O.C.)/ 7400(O.C.)/ 7200(O.C.)/ 7000(O.C.)/ 6800(O.C.)/ 6600(O.C.)/ 6400(O.C.)/ 6200(O.C.)/ 6000(O.C.)/ 5800(O.C.)/ 5600(O.C.)/ 5400(O.C.)/ 5200(O.C.)/ 4800/ 4000MHz

Memory Channel

Dual

Memory Slot

Memory Slot (Additional Info)

2 x DIMM

Memory Max.

128GB

Optane Memory Support

Storage

Storage Interface

6.0Gb/s

M.2/SSD Expansion Slot

M.2/SSD Expansion Slot Details

2 x M.2 Slot (1 x M.2 M key type 2280 support PCIe 4.0 x4/x2 SSD, 1 x M.2 M key type 2280 support PCIe 4.0 x4/x2 SSD)

M.2/SSD Slot Gen

Up to Gen 4

Graphics

Integrated

Graphics Chipset

Integrated With Processor

Multi-GPU Support

PCI Express Slot

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16, 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1.

Audio & Video

Audio Chipset

Realtek Audio CODEC, High Definition Audio

Audio Channel

2/4/5.1/7.1

Network & Connectivity

LAN Chipset

Realtek 2.5GbE LAN

LAN Speed (Mbps)

10/100/1000/2500Mbps

WiFi

Bluetooth

Ports

USB Port

1 x USB 3.2 Gen 1 Type-C, 3 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0/1.1 Type-A

VGA Port

DVI Port

HDMI Port

DisplayPort (DP)

IDE Port

SATA Port

4 x SATA

Thunderbolt

TPM Port

Yes

COM Port

Technical Info

Back-Connect Design

Cable Management

Front

Heatsink

FireWire

CrossFire Support

Sli Support

Raid Support

0, 1, 5, 10

RGB Support

RGB

RGB Connector

1 x RGB LED strip headers

Approx. Power Consumption

60W

Form Factor

Micro-ATX

Bios Information

BIOS Type

1 x 128 Mbit flash

BIOS Model

AMI UEFI BIOS

BIOS Version

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Compatibility

Supported Operating System

Windows 10, 11

Compatible Products

Compatible with LGA1700 Socket 12th, 13th & 14th Gen Intel Processor.

Warranty

3 year

Additional Info

Feature

Hybrid 6+2+1 Phases Digital VRM Solution, XMP Memory Module Support, Update BIOS Without Installing the CPU, Memory and Graphics Card.

Others

Internal I/O Connectors: (1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x addressable LED strip headers 1 x RGB LED strip headers 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper), Back Panel Connectors: (1 x PS/2 keyboard/mouse port 3 x audio jacks), I/O Controller: iTE I/O Controller Chip.

Country Of Origin

Taiwan

Made in/ Assemble

China

Details

Features of Gigabyte B760M GAMING Motherboard In Bangladesh

The NPC MF2208-IPS is a 22-inch Full HD monitor designed to deliver crisp and vibrant visuals. Featuring an IPS panel, it ensures excellent color accuracy and wide viewing angles. With HDMI and DisplayPort connectivity, this sleek black monitor is versatile and fits seamlessly into any workspace.

Features:

22 Inch FHD Display: Enjoy sharp, high-definition images with Full HD resolution.
IPS Panel Technology: Provides wide viewing angles and accurate color reproduction.
HDMI and DisplayPort Inputs: Offers flexible connectivity for various devices.
Sleek Black Design: Modern aesthetics to complement any desktop setup.
Adjustable Stand: Allows for ergonomic adjustments to optimize your viewing angle.

Benefits:

Clear Images: Full HD resolution ensures detailed and sharp visuals.
Accurate Colors: IPS technology enhances color consistency and viewing angles.
Versatile Connectivity: HDMI and DP ports cater to different devices and setups.
Stylish Look: The slim black design adds a touch of sophistication to your space.
Ergonomic Comfort: Adjustable stand helps reduce neck strain and enhances comfort.

How to Maintain:

Regular Dusting: Wipe the screen with a microfiber cloth to keep it clean.
Check Connections: Ensure all cables are properly connected and secure.
Adjust Settings: Set brightness and contrast according to your comfort.
Prevent Glare: Position the monitor away from direct light sources.
Proper Ventilation: Maintain airflow around the monitor to avoid overheating.

Enhance your viewing experience with the NPC MF2208-IPS 22 Inch FHD Monitor. Visit Ryans Computers to get this top-notch monitor today. Elevate your workspace with superior display quality and style!

What is the price of Gigabyte B760M GAMING Motherboard In Bangladesh?

The price of Gigabyte B760M GAMING Motherboard not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Gigabyte B760M GAMING Motherboard from our website or visit our showrooms nearby.
