N.B. Image may differ with actual product's layout, color, size & dimension. No claim will be accepted for image mismatch. Product data used in this website is based solely on its manufacturer provided information, authenticity and accuracy are their responsibility only.
Intel Dual Band Wireless-AC 3168, Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed.
Bluetooth
Bluetooth 4.2
Ports
USB Port
2 x USB 3.2 Gen 1 5Gbps Type-A, 2 x USB 2.0, 2 x USB 3.2 Gen 1 5Gbps Type-A
VGA Port
1
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
No
TPM Port
Yes
COM Port
No
Technical Info
Back-Connect Design
No
Cable Management
Front
DirectX Support
12
Heatsink
Yes
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 10
RGB Support
RGB
RGB Sync
Mystic Light
RGB Connector
2 x 4-pin RGB LED connectors
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Compatibility
Supported Operating System
Windows 10
Warranty
Warranty
3 year
Additional Info
Feature
Lightning Fast Experience, PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr, Premium Thermal Solution, 7W/mK pad, additional choke thermal pad and M.2 Shield Frozr are built for high performance system and non-stop works, Powerful Design, Core Boost, Digital PWM IC, 2oz Thickened Copper PCB, Creator Genie, DDR4 Boost, Audio Boost
Others
1 x DisplayPort, 1x 4-pin CPU fan connector, 1x 4-pin water-pump fan connector, 3x 4-pin system fan connectors, 1x Front panel audio connector, 2x System panel connectors, 1x Serial port connector, 1x Chassis Intrusion connector, 2x 3-pin RAINBOW LED connectors, 1xTPM module connector, 1x Clear CMOS jumper, Flash BIOS Button, Wi-Fi Antenna connectors, 3x Audio jacks, 8 mounting holes, WIRELESS LAN & BLUETOOTH: Intel Dual Band Wireless-AC 3168, Dual Mode Bluetooth 2.1,2.1+EDR,3.0,4.0,BLE,4.2
Country Of Origin
Taiwan
Made in/ Assemble
China
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
Details
QUESTION & ANSWER
Customer Questions
Q:
Can i use 5800x on this motherboard?
Asked By
A:
Dear Customer, Yes, you can use 5800x on MSI B550M PRO-VDH Wi-Fi AMD Motherboard Thank you.
Answered By Ryans Computers Ltd.
, 27 Jun 2026
Q:
Ei motherboard ki ryzen 4600g use kora jabe
Asked By
A:
প্রিয় গ্রাহক জি ব্যবহার করতে পারবেন ধন্যবাদ
Answered By Ryans Computers Ltd.
, 09 May 2026
Q:
এই মাদারবোর্ডে কি AMD RYZEN 7 5700 X সাপোর্ট করবে ?
আর এটাতে কি Windows 11 সাপোর্ট করবে ?
Asked By Foyad
A:
প্রিয় গ্রাহক, এই মাদারবোর্ডে আপনি 5700x প্রসেসর ব্যবহার করতে পারবেন এবং উইন্ডোজ ১১ ব্যবহার করতে পারবেন।
ধন্যবাদ।
Answered By Ryans Computers Ltd.
, 22 Aug 2025
Q:
এই মাদারবোর্ড টি কি AMD Ryzen 7 5700G 8 Core Desktop Processor এর সাথে সাপোর্ট করবে? এবং Windows 11 সাপোর্ট করবে?
Asked By Mahtab
A:
প্রিয় গ্রাহক, জি, প্রসেসরটি মাদারবোর্ডে সাপোর্ট করবে এবং উইন্ডোজ ইলেভেনে ব্যবহার করতে পারবেন। ধন্যবাদ ।
Answered By Ryans Computers Ltd.
, 16 Jun 2025
Q:
Is the motherboard available?
Asked By Z
A:
Dear sir, Sorry we don't have it in stock at the moment
Answered By Ryans Computers Ltd.
, 19 Jan 2025
Q:
Can I install windows 11 in this motherboard?
Asked By Hossain
A:
Dear customer, This motherboard will only support Windows 10. Thanks.
Answered By Ryans Computers Ltd.
, 11 Jan 2025
Q:
does it support windows 11?
Asked By
A:
Dear customer, This motherboard will only support Windows 10. Thanks.
Answered By Ryans Computers Ltd.
, 15 Dec 2024
Q:
Can you use Ryzen 5 5600x with this motherboard out of the box or you have to update bios ?
Asked By Mohammad Intesar
A:
Dear customer, You can use the specified processor on this motherboard. Thanks
Answered By Ryans Computers Ltd.
, 09 Dec 2024
Q:
is it has lan port facilities?
Asked By Asfa Khan
A:
Dear sir ,Yes, the MSI B550M PRO-VDH Wi-Fi AMD Motherboard includes a LAN port.
LAN Chipset
Realtek 8111HN
LAN Speed (Mbps)
10/100/1000
Answered By Ryans Computers Ltd.
, 07 Dec 2024
Q:
Is there any argb header in this motherboard
Asked By Zayn
A:
Dear customer, The MSI B550M PRO-VDH Wi-Fi AMD Motherboard does not have an ARGB (Addressable RGB) header. It features one 4-pin RGB header,
Answered By Ryans Computers Ltd.
, 19 Oct 2024
