Brand

MSI

Model

MSI MAG Z790 TOMAHAWK (Wi-Fi 6E)

Chipset

Intel Z790

Sockets Supported

LGA1700

Built-in Processor

Generation

12th/13th/14th

Back-Connect Design

Memory Type

DDR5

Memory Slot

Memory Max.

192GB

Optane Memory Support

Graphics

Integrated

Graphics Chipset

Integrated With Processor

M.2/SSD Expansion Slot

WiFi

Yes

Bluetooth

Bluetooth 5.3

Form Factor

ATX

Supported Operating System

Windows 10, 11

Body Color

Black

Warranty

3 year

General

Brand

MSI

Model

MSI MAG Z790 TOMAHAWK (Wi-Fi 6E)

Body Color

Black

CPU

Chipset Brand

Intel

Chipset

Intel Z790

Sockets Supported

LGA1700

Built-in Processor

Supported CPU

12th/13th/14th Gen Intel Core Processors, Pentium Gold and Celeron Processors

Generation

12th/13th/14th

Memory Support

Memory Type

DDR5

Memory MHz

7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz non-ECC, un-buffered memory

Memory Channel

Dual

Memory Slot

Memory Slot (Additional Info)

4 x DDR5

Memory Max.

192GB

Optane Memory Support

Storage

Storage Interface

6.0Gb/s

M.2/SSD Expansion Slot

M.2/SSD Expansion Slot Details

4 x M.2, ((1 x M.2, 1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices),(1 x M.2, 2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices), (1 x M.2, 3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices), (1 x M.2, 4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices))

M.2/SSD Slot Gen

Up to Gen 4

Graphics

Integrated

Graphics Chipset

Integrated With Processor

Multi-GPU Support

PCI Express Slot

2 x PCI-E x16 slot, 1 x PCI-E x1 slot

Audio & Video

Audio Chipset

Realtek ALC4080 Codec

Audio Channel

7.1

Network & Connectivity

LAN Chipset

Intel 2.5Gbps LAN

WiFi

Yes

WiFi Technology

Intel Wi-Fi 6E

Bluetooth

Bluetooth 5.3

Ports

USB Port

2 x USB 3.2 Gen 1 5Gbps Type-A, 2 x USB 3.2 Gen 2 10Gbps Type-A, 1 x USB 3.2 Gen 2 10Gbps Type-C, 1 x USB 3.2 Gen 2x2 20Gbps Type-C

VGA Port

DVI Port

HDMI Port

DisplayPort (DP)

IDE Port

SATA Port

Thunderbolt

TPM Port

COM Port

Technical Info

Back-Connect Design

Cable Management

Front

DirectX Support

Heatsink

Yes

FireWire

CrossFire Support

Sli Support

Raid Support

0, 1, 5, 10

RGB Support

RGB

RGB Connector

1x RGB LED connector(JRGB)

Approx. Power Consumption

70W

Form Factor

ATX

Compatibility

Supported Operating System

Windows 10, 11

Compatible Products

12th/13th/14th Gen Intel Core Processors, Celeron Processors, Pentium Gold G7400, Core i3 12100F, Core i3 12100, Core i3 12100, Core i3 13100, Core i5 12400, Core i5 12500

Warranty

3 year

Additional Info

Feature

Lightning Gen 5: The latest PCIe 5.0 solution with up to 128GB/s bandwidth for maximum transfer speed. Quadruple M.2 Connectors: Onboard quadruple M.2 connectors for the maximum storage performance. Latest DDR5 Memory: A huge step of DDR performance enhancement with the latest DDR5 memory and MSI Memory Boost technology. Wi-Fi 6E: The latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS color technology, delivering speeds up to 2400Mbps. 2.5G Network Solution: Featuring premium 2.5G LAN to deliver better network experience. Lightning USB 20G: Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1. M.2 Shield FROZR: M.2 thermal accessory keeps M.2 SSDs safe while preventing throttling, making them run faster.

Others

Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility. Core Boost: With premium layout and fully digital power design to support more cores and provide better performance. Audio Boost 5: Isolated audio with a high quality audio processor for the most immersive gaming experience 6 Layer PCB with 2oz Thickened Copper: An Enhanced PCB design provides higher performance and long- lasting system stability without any compromise.

Country Of Origin

Taiwan

Made in/ Assemble

China

Details

Features of MSI MAG Z790 TOMAHAWK (Wi-Fi 6E) Motherboard In Bangladesh

unite as one

The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.

EXCLUSIVE FEATURES

PREMIUM THERMAL SOLUTION

HIGH-SPEED TRANSMISSION

2.5G Network Solution

Wi-Fi 6E

Memory Boost

Lightning Gen 5

OPTIMIZED FOR WATER COOLING

Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit.

DIY 2.0 – INTEGRATING WITH THE SYSTEM ENVIRONMENT

With MSI you benefit from great compatibility and a worry-free user experience when using Microsoft Windows 11. With a true dedication to performance, our R&D team has made sure everything works as intended when using the latest version of Microsoft Windows on any MSI product.

FAST AND FUTURE-READY STORAGE

MSI MPG series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.

DOUBLE BANDWIDTH WITH LIGHTNING USB 3.2 GEN 2X2 20G

Using USB 3.2 devices has never been faster! MAG Z790 series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 20Gb/s when connecting the Rear USB Type-C.

EASY OVERCLOCKING WITH XMP PROFILE

The XMP (Extreme Memory Profiles) in MSI BIOS are tested and certified by MSI OC LAB. It is easy to enable with auto power settings to get the best memory speed and stability.

What is the price of MSI MAG Z790 TOMAHAWK (Wi-Fi 6E) Motherboard In Bangladesh?

The price of MSI MAG Z790 TOMAHAWK (Wi-Fi 6E) Motherboard starts from 39,700 . The price may vary due to your customization and product availability. You can buy MSI MAG Z790 TOMAHAWK (Wi-Fi 6E) Motherboard from our website or visit our showrooms nearby.
