NZXT H510i Compact Mid Tower Black-Red Gaming Casing #CA-H510I-BR

Item: NZXT H510i Compact Mid Tower Black-Red Gaming Casing #CA-H510I-BR
Rating: 5
Author: Verified Buyer

1 reviews

Product Id: 07.02.681.52

Out Of Stock

Quick Overview

Case Type - Mid Tower
Supported Motherboard Type (Max.) - Up to ATX
Optical Drive Bay - No
Cooling Fan (Built-In) - 2
Lighting Fan - No
Power Supply (Built-In) - No
Back-Connect Supported - No
Color - Black & Red

Color variations

Black & Red
Tk 0

Payment Method Shipping & Charge Order Procedure

Brand

NZXT

Model

NZXT H510i

Series

H Series

Case Type

Mid Tower

Supported Motherboard Type (Max.)

Up to ATX

Front/Top USB port

1 x USB3.1 Gen 2 Type-C, 1 x USB3.1 Gen 1 Type-A

Front/Top Audio Port

1 x Headset audio Jack

Expansion Slots

Optical Drive Bay

Cooling Fan (Built-In)

Additional Fan Slot

Power Supply (Built-In)

Power Supply Type

ATX (not included)

Power Supply Mounted

Bottom

Back-Connect Supported

Transparent Side Window

Yes

Dust Cover

All air intakes

Color

Black & Red

Dimensions

435 x 210 x 428mm (without feet), 460 x 210 x 428mm (with feet)

Weight (Kg)

6.8Kg

Warranty

No warranty

General

Brand

NZXT

Model

NZXT H510i

Series

H Series

Case Type

Mid Tower

Part No

CA-H510I-BR

Technical Info

Supported Motherboard Type

ATX, Micro ATX, Mini ITX

Lighting Support (Front/Top/Side)

Supported LED Strip

Yes

Fan / Light Controller

Yes

Illumination

Sync with Motherboard

Back-Connect Supported

Graphics-Card Length

Up to 381mm w/o front watercooler installed, up to 325mm with front watercooler installed

Supported CPU Cooler

Air Cooler or Liquid Cooler

CPU Cooler Height

Up to 165mm

Cable Management Depth

19 - 23mm

Ports & Slots

Front/Top USB port

1 x USB3.1 Gen 2 Type-C, 1 x USB3.1 Gen 1 Type-A

Front/Top Audio Port

1 x Headset audio Jack

5.25 Inch Drive Bay

3.5 Inch Drive Bay

2+1

2.5 Inch Drive Bay

2+1

1.8 Inch Drive Bay

Expansion Slots

Optical Drive Bay

Memory Card Slot

Fan & Radiator Details

Cooling Fan (Built-In)

Additional Fan Slot

Pre-Installed Fan Size

2 x 120mm

Supported Fan Size

Front: 2 x 120mm / 2 x 140mm, Top: 1 x 120mm / 1 x 140mm, Rear: 1 x 120mm

Lighting Fan

Radiator Support Front/Top/Rear

Front: 2x 140 or 2x 120mm with Pull, Rear: 1x 120mm

Radiator Support Max.

Up to 140mm

Power

Power Supply (Built-In)

Power Supply Type

ATX (not included)

Power Supply Mounted

Bottom

Approx. Power Consumption

10W

Physical Description

Transparent Side Window

Yes

Case Windowed

Tempered Glass

Buttons

Power

Material

SGCC Steel, Tempered Glass

Dust Cover

All air intakes

Color

Black & Red

Dimensions

435 x 210 x 428mm (without feet), 460 x 210 x 428mm (with feet)

Weight (Kg)

6.8Kg

Handle

Warranty

No warranty

Additional Info

Others

Filters: All Air Intakes, Smart Device V2: 3x Fan channels with Max 10W per channel output, 2x RGB LED port support up to 4x HUE 2 addressable LED strips or 5x Aer RGB or Aer RGB 2 fans, Built-in noise detection module, LED Strip(s): 2 integrated addressable LED strip, Vertical GPU Mount: 2 Slots

Specialty

Compact Mid Tower Gaming Casing with Smart Device 2, Compact Mid-Tower with Lighting and Fan Control, The new Smart Device V2 includes a faster microprocessor for NZXT CAM-powered control of two HUE 2 RGB lighting channels and three fan channels that support either voltage regulated or PWM fans, The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcase your stunning build

Details

Features of NZXT H510i Casing In Bangladesh

NZXT H510i

THE H-SERIES PC CASES

We’ve made the iconic H Series PC cases even better. Our best-selling case lineup includes new features to improve connectivity, make it even easier to build and look even more amazing. You’ll still find the elements builders loved in the original H Series, including our patented cable management system, removable fan/radiator mounting brackets, and easy-to-use drive trays, alongside new updates like a front-panel USB-C connector, a tempered glass side panel that installs with a single thumbscrew and an upgraded Smart Device V2 on the I versions.

H510i
Compact ATX Mid Tower

The H510 and H510i compact mid-tower ATX cases are both stunning and an excellent value. Perfect when you want a small-footprint ATX case without sacrificing features. A removable radiator mounting bracket, flush tempered glass window, multiple fan filters, and front USB 3.1 Gen 2 type-C are just some of the amenities.

SMARTER (i VERSION ONLY)

The H series features design improvements including a re-designed SSD tray, flush tempered glass mounting, and numerous fine adjustments for a smarter build experience. The new Smart Device V2 includes a faster microprocessor providing NZXT CAM-powered control of two HUE 2 RGB lighting channels, and three fan channels that support either voltage regulated or PWM fans.

MORE MODERN

With a USB 3.1 Gen2-compatible USB-C connector on the front panel, it’s easier than ever to connect smartphones, high-speed external storage, or the latest peripherals to your PC.

STILL BEAUTIFUL

The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcase your stunning build.

ENJOYABLE BUILDS FOR ALL

Cable management can often take more time than assembly. We designed a cable routing kit with pre-installed channels and straps, for intuitive and easy wiring.

What is the price of NZXT H510i Casing In Bangladesh?

The price of NZXT H510i Casing not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy NZXT H510i Casing from our website or visit our showrooms nearby.
