Feature
AC mode, Automatically identifying the Internet access mode and obtaining IP addresses, Automatically learning the PPPoE username and password of other routers, Configuration backup Local upgrade, Log upload, Online upgrade, Restoring factory defaults, Portal authentication, One-click authentication, Password authentication, SMS-based authentication, Voucher authentication supported by Ruijie Cloud portal page, Cloud portal authentication, Local portal authentication, QR code authentication, Custom portal page, Account-based authentication supported by Ruijie Cloud portal page, CHAP, MS-CHAPv1, MS-CHAPv2, Delivery through Ruijie Cloud portal page, 802.1X authentication, MAC address-based authentication, PPPoE server, RADIUS flow control authorization, PAP, RADIUS authentication, RADIUS client, RADIUS accounting based on time or traffic, RADIUS flow control authorization, RADIUS proxy server, RADIUS traffic quota authorization, RADIUS user group authorization, Third-party authentication Avoiding IP address conflicts on WAN interfaces, Multiple IP addresses on a WAN port, Load balancing, MAC address cloning, Multiple WAN interfaces on the same network segment, PPPoE clients, VLAN, WAN failover, Application priority, Application recognition, Behavior management, QoS, Time-based blocking policy, IP address-based blocking policy, Website filtering: custom URL, Traffic audit, URL audit log, Audit log server, Audit log storage, Uploading audit logs to a server, Application-based routing, Bandwidth aggregation, BGP, BGP4, BGP4+, IPv4 static route, IPv6 PBR, Route selection based on national address database, IPv6 static route, Load balancing based on flows, Load balancing based on source IP addresses, Load balancing based on the interface weight, Route selection by link quality, OSPFv2, OSPFv3, RIP, RIPng, 3322.org, ALG, ARP binding, Maximum number of ARP entries 2048, Cloudflare, DHCP client, DHCP server, Option 43, Option 138, Static/Dynamic NAT, DNS client, DNS proxy, DNS server, No-IP DNS, IPTV, IPv4 ping, IPv6, IPv6 ping, Remotely monitoring devices through Ruijie Reyee App, Restarting devices through Ruijie Reyee App, Upgrading device software version through Ruijie Reyee App, Fault diagnosis, TFTP client (IPv4 address), HTTPS login, NTP client, Disabling ping, Stateful ACL, IP-MAC binding, Network sharing prevention, Security log, Security zone, User group-based connection limiting.
Others
Total number of optical ports 2, Total number of RJ45 ports 8, Number of 10/100/1000BASE-T ports 4, Number of 10/100/1000/2500BASE-T ports 4, Number of 10GE SFP+ ports 2, Maximum number of LAN ports 9, Maximum number of WAN ports 9, Number of fixed LAN ports 1, Number of fixed WAN ports 1, Number of LAN/WAN ports 8, LEDs 1 x system status LED, 10 x Ethernet port LEDs, Cooling Natural cooling Fan Fanless design, Mounting options Rack, Surge protection Service port: -/+ 6 kV for common mode, Power connector: -/+ 6 kV for common mode and -/+ 6 kV for differential mode, Maximum number of concurrent sessions 150000, Recommended number of concurrent clients 700, Throughput 3000 Mbps Internet access mode, Static IP address, Static IPv6 address, Dynamic IP address, Dynamic IPv6 address, PPPoE, System language English, Chinese, Turkish, Arabic, Vietnamese, Thai, Indonesian, Latin American Spanish, Brazilian Portuguese, Russian, French, German, European Spanish, Italian, and Polish, Maximum number of VLANs 128, Number of MAC address entries to be filtered 512, SD-WAN performance 1100 Mbps, Multi-WAN link bundling efficiency (lab data) >= 80%, IPsec VPN bandwidth 1100 Mbps, Maximum number of branches in IPsec VPN networking 300, L2TP VPN bandwidth 1100 Mbps, Maximum number of branches in L2TP VPN networking 300, OpenVPN bandwidth 350 Mbps, Maximum number of branches in OpenVPN networking 300, PPTP VPN bandwidth 1700 Mbps, Maximum number of branches in PPTP VPN networking 300, Maximum number of APs (AC mode) 750, Maximum number of devices that can be managed 128.
