2 x M.2 (1 x PCIe 5.0 M.2 Slot, 1 x PCIe 4.0 M.2 Slot)
Graphics
Graphics
Integrated
Graphics Chipset
Intel HD Graphics Support
Multi-GPU Support
No
PCI Express Slot
1 x PCIe 5.0 x16 with PCIe UD Slot, 1 x PCIe 4.0 x4 slot
Audio & Video
Audio Chipset
Realtek Audio CODEC, High Definition Audio
Audio Channel
7.1
Network & Connectivity
LAN Chipset
Realtek 2.5GbE LAN chip
LAN Speed (Mbps)
100/ 1000/ 2500Mbps
WiFi
Yes
WiFi Technology
Wi-Fi 6
Bluetooth
Bluetooth 5.3
Ports
USB Port
3 x USB 3.2 Gen 1 ports, 3 x USB 2.0/1.1 ports
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
SATA Port
4
Thunderbolt
No
TPM Port
1
Technical Info
Back-Connect Design
No
Cable Management
Front
Heatsink
Yes
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0, 1, 5, 10
RGB Support
ARGB
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Type
1 x 256 Mbit flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Compatibility
Supported Operating System
Windows 10, Windows 11
Compatible Products
LGA1851 socket: Support for Intel Core Ultra Processors
Warranty
Warranty Details
3 year
Additional Info
Feature
Unique Features: Support for Q-Flash, Support for Q-Flash Plus, Support for Smart Backup, Bundled Software: Norton Internet Security (OEM version), LAN bandwidth management software
Others
Internal I/O Connectors: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x CPU fan/water cooling pump header, 1 x system fan header, 1 x system fan/water cooling pump header, 3 x addressable RGB Gen2 LED strip headers, 2 x M.2 Socket 3 connectors, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x S/PDIF Out header, 1 x USB Type-C header, with USB 3.2 Gen 1 support, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only), 1 x serial port header, 1 x Q-Flash Plus button, 1 x reset jumper, 1 x Clear CMOS jumper, I/O Controller: iTE I/O Controller Chip
Country Of Origin
Taiwan
Made in/ Assemble
China
