Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard

Item: Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard
Rating: 5
Author: Syed Rakib Ali

2 reviews

Product Id: 02.02.006.294

Regular Price

Tk 0

Out Of Stock

See similar model

Quick Overview

Chipset - AMD B550
Sockets Supported - AM4
Supported CPU - AMD Ryzen 3rd Generation Processors with Radeon Graphics processors
Generation - Not Applicable
Memory Slot - 4
Memory Max. - 128GB
Back-Connect Design - No

Payment Method Shipping & Charge Order Procedure

Brand

Asus

Model

Asus TUF GAMING B550M-PLUS

Chipset

AMD B550

Sockets Supported

AM4

Built-in Processor

Generation

Not Applicable

Back-Connect Design

Memory Type

DDR4

Memory Slot

Memory Max.

128GB

Optane Memory Support

Graphics

Integrated

Graphics Chipset

Integrated With Processor

M.2/SSD Expansion Slot

WiFi

Bluetooth

Form Factor

Micro-ATX

Supported Operating System

Windows 10

Body Color

Black

Warranty Details

3 Years Replacement Warranty

General

Brand

Asus

Model

Asus TUF GAMING B550M-PLUS

Body Color

Black

CPU

Chipset Brand

AMD

Chipset

AMD B550

Sockets Supported

AM4

Built-in Processor

Supported CPU

AMD Ryzen 3rd Generation Processors with Radeon Graphics processors

Generation

Not Applicable

Memory Support

Memory Type

DDR4

Memory MHz

4800(O.C.)/ 4600(O.C)/ 4466(O.C.)/ 4400(O.C)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3333(O.C.)/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133MHz

Memory Channel

Dual

Memory Slot

Memory Slot (Additional Info)

4 x DIMM

Memory Max.

128GB

Memory Max. (Additional Info)

128GB

Optane Memory Support

Storage

Storage Interface

6.0Gb/s

M.2/SSD Expansion Slot

M.2/SSD Expansion Slot Details

2 x M.2 Socket 3 (1 x M.2 (M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) / 1 x M.2 (M Key, Type 2242/2260/2280/22110 (PCIE 3.0 x4 and SATA modes))

Graphics

Integrated

Graphics Chipset

Integrated With Processor

Multi-GPU Support

2-Way AMD CrossFireX

PCI Express Slot

1 x PCIe 4.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x4 mode), 1 x PCIe 3.0 x1

Audio & Video

Audio Chipset

Realtek ALC S1200A

Audio Channel

7.1

Network & Connectivity

LAN Chipset

Realtek RTL8125B

LAN Speed (Mbps)

2.5Gbps

WiFi

Bluetooth

Ports

USB Port

2 x USB 3.2 Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C), 2 x USB 2.0, 4 x USB 3.2 Gen 1 (blue) (one port can be switched to USB BIOS FlashBack)

VGA Port

DVI Port

HDMI Port

DisplayPort (DP)

Yes

IDE Port

SATA Port

4 x SATA

Thunderbolt

TPM Port

Yes

COM Port

Yes

Technical Info

Back-Connect Design

Cable Management

Front

DirectX Support

Heatsink

Yes

FireWire

CrossFire Support

Yes

Sli Support

Raid Support

0, 1, 10

RGB Support

ARGB

RGB Sync

Aura Sync

RGB Connector

2 x Aura RGB Strip Headers, 1 x Addressable Gen 2 header

Approx. Power Consumption

60W

Form Factor

Micro-ATX

Bios Information

BIOS Type

256 Mb Flash ROM

BIOS Model

UEFI AMI BIOS

Compatibility

Supported Operating System

Windows 10

Compatible Products

Sockets Supported AM4: AMD Ryzen 3rd Generation

Warranty

Warranty Details

3 Years Replacement Warranty

Additional Info

Feature

AMD B550 (Ryzen AM4) micro ATX gaming motherboard with PCIe 4.0, dual M.2, 10 DrMOS power stages, 2.5 Gb Ethernet, HDMI, DisplayPort, SATA 6 Gbps, USB 3.2 Gen 2 Type-A and Type-C, and Aura Sync RGB lighting support, AMD AM4 socket, Ready for 3rd Gen AMD Ryzen and 3rd Gen AMD Ryzen with Radeon Graphics Processors, Enhanced power solution, 8+2 DrMOS power stages, ProCool connector, military-grade TUF components, and Digi+ VRM for maximum durability, Comprehensive cooling, VRM heatsinks, PCH fanless heatsink, M.2 heatsink, hybrid fan headers and Fan Xpert 2+ utility, Next-gen connectivity, PCIe 4.0 M.2, USB 3.2 Gen 2 Type-A and Type-C support, Made for online gaming, 2.5 Gb Ethernet, TUF LANGuard and TurboLAN technology, Realtek S1200A codec, Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in, AI noise-canceling microphone, Provides crystal-clear in-game voice communication

Others

1 x DisplayPort 1.2, HDMI 2.1, 2 x Chassis Fan connector(s), 2 x Aura RGB Strip Headers, 1 x Addressable Gen 2 header(s), 1 x SPI TPM header, 1 x Front panel audio connector(s) (AAFP), 1 x Clear CMOS jumper(s), 1 x System panel connector, 1 x COM port header, 1 x Speaker connector, 1 x BIOS FlashBack Button(s), 5 x Audio jack(s), 1 x Optical S/PDIF out

Country Of Origin

Taiwan

Made in/ Assemble

China

Details

Features of Asus TUF GAMING B550M-PLUS Motherboard In Bangladesh

Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard in Bangladesh

Asus TUF GAMING B550M-PLUS motherboard is a renowned motherboard in Bangladesh. The Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard is an AMD mainboard. The motherboard used an AMD B550 chipset. AM4 Sockets Supported. In this motherboard, you can use an AMD Ryzen 3rd Generation Processors with Radeon Graphics processors. The Asus TUF GAMING B550M-PLUS mainboard has a Dual memory channel and 4 memory slot. It supports DDR4 4800(O.C.)/ 4600(O.C)/ 4466(O.C.)/ 4400(O.C)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3333(O.C.)/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133MHz ram. Maximum ram supports 128GB. Also, you can use 2 M.2/SSD Expansion Slot. Storage Interface is 6.0Gb/s. Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard comes with Graphics. PCI Express Slot are 1 x PCIe 4.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x4 mode), 1 x PCIe 3.0 x1. The here audio chipset used Realtek ALC S1200A. Audio Channel available are 7.1, so you can enjoy crystal clear sound. For Network and Connectivity purposes the Brand motherboard offers Realtek RTL8125B lan chipset and it’s speeds 2.5Gbps. USB port available One USB3.2 Gen 2 Type-C, One USB3.2 Gen 2 Type-A, Five USB3.2 Gen 1, Four USB2.0. Also, you will get VGA Port, DVI Port,HDMI Port, SATA Port and TPM Port. . It’s a mATX motherboard. Yes it’s a RGB support motherboard, also you can 2 x Aura RGB Strip Headers RGB connector. The Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard supported operating system is Windows 10. You will get a 3 Years Replacement Warranty brand warranty.

What is the Asus TUF GAMING B550M-PLUS motherboard Price in Bangladesh?

The Asus TUF GAMING B550M-PLUS motherboard Price in Bangladesh is given upper. Ryans computers offer Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard is the competitive price in BD. You can purchase it from our website or computer shop.

What is the price of Asus TUF GAMING B550M-PLUS Motherboard In Bangladesh?

The price of Asus TUF GAMING B550M-PLUS Motherboard not mentioned for stock unavailability.The price may vary due to your customization and product availability. You can buy Asus TUF GAMING B550M-PLUS Motherboard from our website or visit our showrooms nearby.
Looking to purchase office, corporate, or institutional equipment? Ryans Computers is here to help. We provide customized solutions tailored to your needs, backed by fast delivery and dependable after-sales service. Our expert Ryans Care team is always ready to support you with troubleshooting, technical assistance, and configuration services—so you can focus on what matters most.

QUESTION & ANSWER

Customer Questions

ai motherboard a argb fan ar jhono 3pin ba 4 pin 2ta pin ai used kora jaba?

Ask By Tamim

প্রিয় গ্রাহক, এই মাদারবোর্ডে এআরজিবি সাপোর্ট করবে এবং 1 x AURA Addressable Gen 2 header (4-Pin) রয়েছে

Answer By Ryans Computers Ltd. , 16 Oct 2024

Does it support RTX 3060 ?

Ask By Nazmul Karim

Dear customer Yes supported Thanks

Answer By Ryans Computers Ltd. , 09 Oct 2024

Ai motherboard a ki 2ta gpu used kora jaba?

Ask By Tamim

প্রিয় গ্রাহক, জ্বী ব্যবহার করা যাবে

Answer By Ryans Computers Ltd. , 17 Sep 2024

Current offline price of this product in khulna Branch?

Ask By Sabir

Dear Customer, The product price on website is our selling price Asus TUF GAMING B550M-PLUS DDR4 AMD Motherboard Price:19,100/=Right now

Answer By Ryans Computers Ltd. , 21 Aug 2024

Koi inch er sata ssd support possible?

Ask By Aongkon

Dear customer, M.2/SSD Expansion Slot Details: 2 x M.2 Socket 3 (1 x M.2 (M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) / 1 x M.2 (M Key, Type 2242/2260/2280/22110 (PCIE 3.0 x4 and SATA modes) Also you can choose anyone from this link https://www.ryans.com/category/internal-ssd Thank you.

Answer By Ryans Computers Ltd. , 12 Aug 2024

বর্তমানে এখন এটার দাম কত টাকা

Ask By Siam

প্রিয় গ্রাহক, Price = 9,100 /- (right now)

Answer By Ryans Computers Ltd. , 25 Jul 2024

Ryans and Ryans go same ? Because in daraz Ryans go selling it for 14200 taka , ur selling it for 19000 taka , is Ryans go from daraz seller part of this ryans ???

Ask By AIRDAR

Dear Sir, RyansGO is our daraz shop and this product is not available in daraz shop and our product price is fluctuated according to the market, Thanks for your query!

Answer By Ryans Computers Ltd. , 15 Apr 2024

Processor - AMD Ryzen 7 5700G Motherboard - ASUS Prime X570-P SSD - SK hynix Platinum P41 500GB Windows 11 support korbe ki ?

Ask By Shoreful Islam

প্রিয় গ্রাহক, জি! উইন্ডোজ ১১ সাপোর্ট করবে, ধন্যবাদ!

Answer By Ryans Computers Ltd. , 30 Dec 2023

বর্তমান দাম কতো টাকা?

Ask By Al Amin

প্রিয় গ্রাহক, বর্তমান মূল্য ১৯৫০০ টাকা, ধন্যবাদ!

Answer By Ryans Computers Ltd. , 02 Dec 2023

Can I use Ryzen 7 5800 X this motherboard?

Ask By Tabbib

Dear Sir, Yes! You can use Ryzen 7 5800X with this motherboard, Thanks for your query!
