4 x M.2 Slot (1 x M.2 Type 2280/2260 supports up to PCIe 5.0 x4, 1 x M.2 type 22110/2280/2260 supports up to PCIe 4.0 x4, 1 x M.2 type 280/2260/2242 supports up to PCIe 4.0 x4, 1 x M.2 type 2280/2260/2242 PCIe 4.0 x4 / SATA)
Graphics
Graphics
Integrated
Graphics Chipset
Integrated With Processor
Multi-GPU Support
No
PCI Express Slot
3 x PCI-E x16 slot, 1 x PCI-E x1 slot
Audio & Video
Audio Chipset
Realtek ALC897
Audio Channel
7.1
Network & Connectivity
LAN Chipset
Realtek RTL8126
LAN Speed (Mbps)
100/1000/2500/5000 Mbps
WiFi
No
Bluetooth
No
Ports
USB Port
4 x USB 2.0 Type-A, 2 x USB 5Gbps Type-A, 1 x USB 10Gbps Type-A, 1 x USB 10Gbps Type-C, 1 x USB 20Gbps Type-C
VGA Port
No
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
IDE Port
No
SATA Port
4 x SATA
Thunderbolt
1
TPM Port
Yes
COM Port
No
Technical Info
Back-Connect Design
No
Cable Management
Front
Heatsink
Yes
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0 , 1 , 5, 10 (SATA), 0 , 1 , 5 , 10 (M.2)
RGB Support
ARGB
RGB Connector
3 x Addressable V2 RGB LED connector (JARGB_V2), 1 x RGB LED connector(JRGB)
Approx. Power Consumption
70W
Form Factor
ATX
Compatibility
Supported Operating System
Windows 11
Compatible Products
Compatible with LGA1851 Core Ultra Processors (Series 2)
Warranty
Warranty Details
3 year
Additional Info
Feature
Ready for AI PC, 5G Network Solution, EZ M.2 Shield Frozr II, EZ PCIe Clip II, Latest DDR5 Memory, Lightning Gen 5, Extended Heatsink Design, Pre-installed I/O Shielding, Frozr AI Cooling.
Others
1 x Thunderbolt 4 (Supports up to 40Gbps transfer rate with Thunderbolt devices Supports up to 20Gbps transfer rate with USB4 devices Supports up to 10Gbps transfer rate with USB 3.2 devices Supports up to 5V/3A,15W power charging Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices Supports up to 8K display), Internal Connector: (1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 1x TPM pin header(Support TPM 2.0)).
Country Of Origin
Taiwan
Made in/ Assemble
China
N.B. Specification may differ
with actual product. In that case, Ryans will execute full refund within 5 days.
